In-Win 2U RS212-07 Server Chassis Inc 800W Redundant PSU and Rail Kit

2U In-Win IW-RS212-07 Server Chassis, 12x 3.5"/2.5" SATA/SAS Hot-Swap Bays, Includes 800W CRPS Redundant PSU & Rail Kit
MORE INFO
MORE INFO

Scan code: LN151110 Manufacturer code: IW-RS212-07
£1,108.99
Item currently awaiting an ETA
Pre Order
Pre order

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • From £31.27 / month (APR 16.9%) or 0% for 4 months
    Monthly Payment: £38.84
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £1,108.99
    Total inc. interest: £1,397.98
    Monthly Payment: £31.27
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £1,108.99
    Total inc. interest: £1,500.89
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £29.47 / month (APR 19.9%)
  • paypal short logo blue 0% UP TO   MONTHS Spend £99 or more and choose PayPal at checkout. More info
  • SCANPROTECT Protect against installation damage for 28 days. More info

Suggested Alternatives

Product Overview

NVMe-Based Storage Rackmount

Featuring all-flash U.2 NVMe, the IW-RS212-07 supports Intel® Xeon Scalable family and is designed for use in a wide range of industrial applications.


Ultra-High Performance and a Variety of Business Applications

The IW-RS212-07 provides a high-performance solution for cloud computing, enterprise, software-defined storage, virtualization, data analytics, and much more.


Highly Flexible Scalability

The IW-RS212-07 has a myriad of storage configurations such as 12 x SAS/SATA or 8 x SAS/SATA + 4 x U.2 NVMe drives.
It also offers a choice of 2 x 2.5" SAS/SATA SSD drive bays at the rear of the chassis.
The converter drive tray is compatible with either a 2.5" or a 3.5" drive.


Mini-SAS HD & Slimline or OCuLink Backplane

InWin's backplane possesses great connectivity and is designed to support SAS/SATA, and NVMe for Slimline or OCuLink host interface.


Optimal Heat Distribution

InWin's hot-swappable fans, featuring anti-vibration and a low noise volume, have optimal heat dissipation by means of a strong air current.


Common Redundant Power Supply

Redundant power supply units ensure the rackmount's uptime and durability even if one of the PSUs fails.


Tool-less Features

InWin's tool-less items enable users to effortlessly assemble their rackmount.
- Ball-bearing slide rails.
- Top cover open button.
- 3.5" to 2.5" HDD tray.
- Hot-swap fan modules.

Features


• Intel® Xeon Scalable family compliant.
• Backplanes with Mini-SAS HD, OCuLink, or Slimline connectors (compatible with PCIe 4.0).
• 2.5"/3.5" hot-swap trays x 12 (optional NVMe trays x 4, distinguishes U.2 NVMe SSDs).
• Tool-less design for 2.5"/3.5" HDD tray.
• End-to-end 12Gbps SAS host, expander, and disk support.
• 2 x 2.5" SAS/SATA SSDs for system disks at the rear of the chassis.
• 800W, 80 Plus® Platinum CRPS.
• High-speed cooling fans for excellent thermal performance.
• Supports tool-less ball-bearing slide rails.

Specifications
Core Chassis Specifications
Case Edition IW-RS212-07
Case Form Factor 2U
Motherboard Form Factor
  • ATX
  • CEB
  • EEB
Back Connect Compatible No
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 12 x HDD Status LED
  • 1 x ID Button
  • 1 x ID LED
  • 4 x LAN Activity LEDs
  • 1 x NMI button
  • 1 x Power LED
  • 1 x Power On/Off button
  • 1 x Reset Button
  • 1 x System Status LED
  • 2 x USB 3.0
Drive Bays
  • 2 x 2.5" SATA/SAS Hot-Swap (External, Rear)
  • 12 x 2.5/3.5" SAS/SATA Hot-swap
Standard Expansion Slots 7
Vertical Expansion Slots
Fans & Filters
Fan Bays 4 x 80mm
Fans Included 4 x 80mm
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
Bottom Radiator Compatibility
Rear Radiator Compatibility
Side Radiator Compatibility
Clearances
Max CPU Cooler Height
Max GPU Card Length
Cable Routing Space
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included Yes
PSU Wattage (If Included)
PSU 80+ Rating (If Included) 80 PLUS Platinum
PSU Support 2U
PSU Mounting Location
Max PSU Length
Chassis Physical Specifications
Colour
Chassis Construction Materials
Dimensions 448 x 87.5 x 660 (WxHxD mm)
Weight 13.09 kg (Approx)
