Product Overview

In-Win IW-R200N

Feature rich open-bay 2U short depth server chassis for ATX or CEB motherboards. Supports up to two external 5.25” drives and six internal 3.5” Hard drives.

Features

• 2U rackmount supports ATX or CEB motherboards.
• Supporting external 5.25” x 2 and internal 3.5” HDD x 6.
• Supports 80 x 25mm cooling fans x 3.
• Compatible with single PSU 500W, redundant 500W or CRPS 550W/800W.
• Expandable storage option with InWin Storage kit.
• Supporting 7 low-profile cards or optional full-height PCI slots x 3 with rear PCI card holder.
• Tool-less top cover for quick maintenance.
*Images for illustration purposes only.

Specifications
Core Chassis Specifications
Case Edition IW-R200N
Case Form Factor 2U Rackmount
Motherboard Form Factor
  • ATX
  • CEB
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x HDD Activity LED
  • 1 x LAN Activity LEDs
  • 1 x Power Status LED
  • 1 x Power Switch
  • 1 x RJ45
  • 1 x System Reset button
  • 2 x USB 2.0
Drive Bays
  • 6 x 3.5" Internal
  • 2 x 5.25" External
Standard Expansion Slots Low Profile PCI Slot x 7 or Full Height PCI Slot x 3 (via riser card)
Vertical Expansion Slots
Fans & Filters
Fan Bays 3 x 80mm
Fans Included None
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility
Bottom Radiator Compatibility
Rear Radiator Compatibility
Side Radiator Compatibility
Clearances
Max CPU Cooler Height
Max GPU Card Length
Cable Routing Space
Side Panels
Window/s No
Window Configuration
Window Construction
LED Lighting Functionality
LED Lighting No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included) 500 W
PSU 80+ Rating (If Included)
PSU Support ATX / 2U / 2U Redundant
PSU Mounting Location Bottom Mount, Rear
Max PSU Length
Chassis Physical Specifications
Colour
Chassis Contruction Materials SGCC
Dimensions 432.4 x 88 x 607 (WxHxD mm)
Weight 8.36 kg (Approx)
