Scan code: LN116980 Manufacturer code: DGS-1100-26MPV2

D-Link DGS-1100-26MPV2 26-Port PoE+ Gigabit Smart Managed Switch

26 Port D-Link DGS-1100-26MPV2 Gigabit Smart Managed Switch, 12x GbE PoE, 24x GbE, 2x Combo GbE/SFP, 370W Budget, Web UI

Thumbnail 1 : D-Link DGS-1100-26MPV2 26-Port PoE+ Gigabit Smart Managed Switch Thumbnail 2 : D-Link DGS-1100-26MPV2 26-Port PoE+ Gigabit Smart Managed Switch Thumbnail 3 : D-Link DGS-1100-26MPV2 26-Port PoE+ Gigabit Smart Managed Switch
Scan code: LN116980 Manufacturer code: DGS-1100-26MPV2
£377.99Item currently awaiting an ETA
Pre order
From £17.36 / month (APR 9.9%) or 0% for 4 months
Monthly Payment: £33.14
Instalment Rate: 9.9% p.a. (fixed)
Cost of purchase: £377.99
Total inc. interest: £397.70
Monthly Payment: £17.36
Instalment Rate: 9.9% p.a. (fixed)
Cost of purchase: £377.99
Total inc. interest: £416.42
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £9.44 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Simple. Easy. Smart.

DGS-1100 Smart Switch Series provides an affordable solution for environments that require simple network management.


Advanced Security Features

The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.


Simplify Network Management

D-Link’s free Network Assistant (DNA) utility displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools.


Surveillance Mode

Select Surveillance Mode in the Web UI to take advantage of easy-to-use surveillance features which also enable you to manage your surveillance network effortlessly. It automatically detects your security devices and segments them into a dedicated Auto Surveillance VLAN to handle video surveillance traffic securely and efficiently.


24-Ports PoE+ with 370W Budget

The DGS-1100-26MPV2 supports IEEE 802.3af/at Power over Ethernet on all eight copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet. While the switch has an overall budget of 370W.


Easy Troubleshooting

The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.

Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.


Green Technology

D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.

Features


• 24 x 10/100/1000 Mbps (PoE)
• 2 x Combo GbE/SFP
• Supports IEEE 802.3at PoE
• 370W PoE power budget
• Compact design for convenient placement
• Innovative D-Link Green energy saving features
• Complete web interface for comprehensive switch management

Specifications
Edition Smart Managed Switch
Form Factor Desktop
Total Network Ports
  • 24 x 10/100/1000 (Gigabit) RJ-45
  • 2 x 100/1000 (Gigabit) SFP/RJ-45 Combo
PoE Support Type Full PoE
No. of Ports Providing PoE 24 x 10/100/1000 (Gigabit) RJ-45
Other Non-Network Ports
Switching Capacity 52 Gbps
Non-Blocking Throughput
Forwarding Rate 38.69 Mpps
MAC Address Table Size 8k Entries
Network Capacity
Built-in Flash Memory 16MB
RAM Memory
Network Protocols
  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3az
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
Acoustic Noise 50.5 dB(A) (high speed) dB
Max. Power Consumption 454.1 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF) 317,777 hours
Power Supply Internal AC Power Supply
Material
Includes
Dimensions (WxHxD) 280 x 44 x 230 mm
Weight 2.00 kg
Additional Information
Scan Code LN116980
Model Number DGS-1100-26MPV2
GTIN 790069453342
