End Of Life
Scan code: LN90075 Manufacturer code: GP-GSTFS30256GTTD

Gigabyte UD PRO 2.5" 7mm 3D Nand SSD/Solid State Drive SATA 6Gb

256GB Gigabyte UD PRO, 2.5" SSD, SATA 3.0 (6Gb/s), TLC 3D NAND, 256MB Cache, 530MB/s Read, 500MB/s Write, 70k/40k IOPS

Thumbnail 1 : Gigabyte UD PRO 2.5" 7mm 3D Nand SSD/Solid State Drive SATA 6Gb Thumbnail 2 : Gigabyte UD PRO 2.5" 7mm 3D Nand SSD/Solid State Drive SATA 6Gb Thumbnail 3 : Gigabyte UD PRO 2.5" 7mm 3D Nand SSD/Solid State Drive SATA 6Gb
Scan code: LN90075 Manufacturer code: GP-GSTFS30256GTTD
End Of Life This product is no longer available to purchase
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Industry Leading 3D NAND Flash

GIGABYTE UD PRO series SSDs adopt 3D TLC NAND flash, which has higher bit capacity, R/W speed performance, endurance and reliability compared to 2D TLC flash. Moreover, with an optimised controller and firmware, GIGABYTE UD PRO series SSDs provide excellent performance for a smooth PC experience.


External DDR3L SDRAM Cache

The UD PRO SSD is equipped with high speed DDR3L SDRAM cache and does not need to reserve over-provisioning space, thus improving the random Read/Write performance. This means the users can use the full capacity of the drive. Moreover, external DRAM can be a buffer between controller and NAND flash for sustained performance when capacity is occupied by more and more data.


Reliability You Can Trust - 3 Years Limited Warranty

GIGABYTE UD PRO series SSDs possess both high data transferring speed and enhanced endurance, providing durable MTBF* of 1.8 million hours and 3 years or 100 TBW** limited warranty***.

Features
Interface: SATA 6.0Gb/s.
Form Factor: 2.5-inch internal SSD.
Total Capacity: 256GB.
Warranty: Limited 3-year or 100TBW.
NAND: Toshiba BiCS3 3D TLC.
External DDR Cache: 256MB.
Sequential Read MB/s: Up to 530 MB/s.
Sequential Write MB/s: Up to 500 MB/s.
Random Read IOPS: Up to 70k.
Random Write IOPS: Up to 40k.
Dimension (W x H x L): 69.85 x 7 x 100 mm.
Mean time between failure (MTBF): 1.8M hours.
Power Consumption (Active): Average: R : 1930mW; W : 2430mW.
Power Consumption (Idle): 170mW.
Temperature (Operating): 0°C to 70°C.
Temperature (Storage): -40°C to 85°C.
