Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch
Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch
Scan code: LN146720 Manufacturer code: USW-Pro-Max-24
£439.99Item currently awaiting an ETA
Pre Order
Pre order
  • Thumbnail 1 : Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch
  • Thumbnail 2 : Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch
  • Thumbnail 3 : Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch

Ubiquiti Pro Max 24 UniFi 24 Port Layer 3 Etherlighting Switch

24 Port Ubiquiti UniFi USW-PRO-MAX-24 Layer 3 Etherlighting Managed Switch, 2x 10GbE SFP+, 16x GbE, 8x GbE/2.5GbE
MORE INFO
MORE INFO

Scan code: LN146720 Manufacturer code: USW-Pro-Max-24
£439.99
Item currently awaiting an ETA
Pre Order
Pre order
Pay in 3 interest-free payments of £146.67

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • From £21.49 / month (APR 16.9%) for 24 months or 0% for 4 months
  • With a 10% deposit from just £10.99 / month (APR 15.9%)
  • SCANPROTECT Protect against installation damage for 28 days.

Suggested Alternatives

Product Overview

Ubiquiti USW-PRO-MAX-24

The Ubiquiti USW-PRO-MAX-24 is an ideal aggregation and access layer switch for any UniFi solution, combining innovative near-silent cooling with UniFi SmartPower RPS power redundancy. The USW-PRO-MAX also features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server.

Like the other network switches in Ubiquiti's PRO MAX range, such as the PRO MAX 48, the USW-PRO-MAX-24 also includes Etherlighting technology to indicate port location, speed/link, and native VLAN/network, making troubleshooting at a glance possible. Also included is a DC power backup in case of unexpected AC power failure, making the USW-PRO-MAX a great switch to prop up mission-critical networking infrastructure.

This unit is also compatible withthe UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Features


• 24-port, Layer 3 Etherlighting™ switch with 2.5 GbE.
• Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network.
• (16) GbE RJ45 ports.
• (8) 2.5 GbE RJ45 ports.
• (2) 10G SFP+ ports.
• DC power backup ready.
• Managed with UniFi Network 8.0.24 and later.

Specifications
Edition Desktop Switch
Form Factor 1U
Total Network Ports
  • 16 x 10/100/1000 (Gigabit) RJ-45
  • 8 x 10/100/1000/2.5G RJ-45
  • 2 x SFP+
PoE Support Type N/A
No. of Ports Providing PoE
Other Non-Network Ports
Switching Capacity 112 Gbps
Non-Blocking Throughput 56 Gbps
IDS/IPS Throughput
Forwarding Rate
MAC Address Table Size
Network Capacity
Networking Features
Network Protocols
VPN Support
Security Features
Built-in Flash Memory
RAM Memory
Acoustic Noise
Max. Power Consumption 50 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply Internal AC Power Supply
Material
Includes
Dimensions (WxHxD) 442 x 44 x 325 mm
Weight
Additional Information
Scan Code LN146720
Model Number USW-Pro-Max-24
GTIN 810084692738
Warranty
