Seasonic PRIME TX 1300 ATX 3.0 1300Watt Full Modular 80+ Titanium PSU/Power Supply
1300W Seasonic PRIME TX-1300 , Full Modular, 80PLUS Titanium, SLI/CrossFire, Single Rail, 108.3A, 135mm Fan ATX3.0
PRIME TX 1300 Watt ATX 3.0 Fully Modular Power Supply from Seasonic
UNWAVERING POWER DELIVERY TO YOUR PCThe Seasonic PRIME TX 3.0 Series is built on top of all the great features of PRIME TX platform with added ATX 3.0 and PCIe 5.0 compatibility. Currently the 1600 W and 1300 W units are equipped with native 12VHPWR connectors, Digital Fan Control, and 105°C-rated Japanese electrolytic capacitors guarantee unwavering power delivery and long-term durability. All these qualities make these power supplies perfect to welcome the newest high power graphic cards and processors on the market.
1300Watts
80 PLUS TitaniumCertification
Intel ATX 12 VForm Factor
Excellent Efficiency for your Dream PC
80 PLUS® TITANIUMThe PRIME Titanium Series achieves the highest level of 80 PLUS® Titanium certification on the market with its 94 % efficiency at 50 % system load.
Build to Power the Latest Components
ATX 3.0 AND 16-PIN PCIE GEN 5 CABLE (12VHPWR)Seasonic's latest PRIME ATX 3.0 Series is designed and built to power new PC components requiring the new ATX 3.0 and PCIe 5.0 standards.
Control your Fans to your Needs
DIGITAL HYBRID FAN CONTROLSeasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.
Finely Crafted Fan Design
FLUID DYNAMIC FAN BEARING High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.
HOW IT WORKSWhen the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces. As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
Made Easier than Ever to Install
CABLE-FREE CONNECTION DESIGN Seasonic’s engineers have implemented a new design feature, where instead of cables; the back panel and the PCB (Printed Circuit Board) are connected by a copper plate. This breakthrough solution not only lowers the chance of production errors during manual insertion but it also improves output power quality.
PRIME TX Feature Summary
1.ATX 3.0 and 16-Pin PCIe 5.0 Cable (12VHPWR)
2.80 PLUS® Titanium Certified
3.Cybenetics ETA Titanium and Lambda A
4.Top-Quality 135 mm Fluid Dynamic Bearing Fan
5.Digital Hybrid Fan Control
6.Tight Voltage Regulation (12 V, 5 V and 3.3 V) [± 3 %]
7.Gold Plated High Current Terminal (MB, CPU and PCIe)
8.12 Years Warranty
