SilverStone Triton 1000Rz Black 1000 Watt Fully Modular 80+ Gold ATX3.1 PSU / Power Supply

SilverStone Triton 1000Rz Power Supply

The SilverStone Triton 1000Rz (TR1000R GM) is a high-end, compact ATX 3.1 power supply designed for demanding PC builds. It stands out for its advanced modularity, high efficiency, and support for the latest connectivity standards.

ATX 3.1 Compliance and Gen5 PCIe Connector

Equipped and fully compatible with the Intel ATX 3.1 specification, this power supply ensures stability, efficiency, and adaptability for the latest hardware. The inclusion of the Gen5 12V-2x6 PCIe connector provides seamless support for next-generation GPUs, meeting current and future power demands.

Cybenetics Gold Efficiency Certification

The power supply achieves high efficiency, backed by a Cybenetics Gold certification. This means reduced energy waste, lower operating costs, and optimized overall performance, making it an eco-friendly and cost-effective choice.

Fully Modular Design with Universal EPS / PCIe Connector Interface

SilverStone equips this PSU with a fully modular, third-generation interface and universal EPS/PCIe connectors. The included embossed cables offer impressive flexibility and enable easy cable management, making installation and upgrades simpler.

Compact Design and High Power Density

Unlike most 1000W power supplies, the Triton 1000Rz is only 140mm deep. Its compact size achieves higher power density but uses a 120mm cooling fan instead of the larger fans typically found in high-wattage models. This small form factor is ideal for builds with limited space but does increase cooling demands and output noise at peak loads.

Silent 120mm FDB Cooling Fan

The Triton 1000Rz uses a 120mm Fluid Dynamic Bearing (FDB) fan for cooling. This fan is designed to operate quietly under typical loads, providing adequate airflow while keeping noise levels low for home or office environments.

Japanese Electrolytic Capacitors

For reliability, the Triton 1000Rz uses high-quality Japanese electrolytic capacitors. This helps ensure long-term durability and stable operation, even under heavy loads.

PCIe 5.0 Ready and Extensive Connectors

The power supply offers PCIe 5.0 support, including up to 6 PCIe 6+2-pin connections, multiple SATA connectors, and a universal EPS interface. This makes it particularly suited for modern hardware and multi-GPU setups.

Noise and Thermal Performance

While the compact dimensions improve usability for smaller cases, reviewers note that the smaller 120mm fan must spin faster under high loads. This slightly raises overall output noise compared to larger PSU models. Nevertheless, the unit maintains Cybenetics Standard++ noise ratings, meaning it performs within acceptable acoustic ranges for most users.

Advanced Protections for Safety and Security

To safeguard your components and ensure long-term reliability, the Triton 1000Rz includes multiple protection mechanisms:

• Over Current Protection (OCP)
• Over Power Protection (OPP)
• Over Voltage Protection (OVP)
• Over Temperature Protection (OTP)
• Short Circuit Protection (SCP)

• Equipped and compatible Intel ATX 3.1 specification standard with Gen5 12V-2x6 PCIe connector.
• Latest PCIe Gen 5 standard to support up to 2X power excursion.
• Silent running 120mm FDB cooling fan.
• Black embossed cable design.
• Full Japanese electrolytic capacitors.
• High efficiency with Cybenetics Gold certification.
• 24/7 continuous power output with 40C operating temperature.
• Compact design with a 140mm depth for easy integration.
