Travel A/V Adapter: 3-in-1 USB-C to VGA, DVI or HDMI - 4K

StarTech.com Travel A/V Adapter: 3-in-1 USB-C to VGA, DVI or HDMI - 4K

StarTech.com
Scan code: LN85207 Manufacturer code: CDPVGDVHDB Request call
£52.49
Spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
High End
Delivery options £5.48 By DPD On 24th Nov 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview This 3-in-1 travel adapter offers a portable solution for connecting your USB-C computer to a VGA, DVI, or HDMI® display.

The travel adapter is compatible with your DP alt mode computer. DP alt mode means your computer can pass a DisplayPort video signal through the USB-C port.

Stylish connectivity for your USB-C laptop
This travel adapter comes with a built-in black USB-C cable and works well with your Dell XPS™, MacBook and any device that supports USB-C DP alt mode.

All-in-one video connectivity, with travel in mind
Instead of carrying three separate video adapters in your laptop bag, this 3-in-1 adapter gives you all the video outputs you'll need. With VGA, DVI and HDMI outputs, this adapter lets you connect from your laptop's USB Type-C port to almost any boardroom or classroom display, without the inconvenience of carrying a separate adapter for each display type.

With support for multiple video outputs and a small-footprint design, this adapter is the ideal plug-and-play solution for travel or BYOD (Bring Your Own Device) applications around the office.

Innovative, built-in cable manager
The adapter features a built-in cable fastener. Simply tuck the cable into place along the side of the adapter for quick and secure storage while you’re traveling to ensure the adapter is neatly stored in your travel bag.

Astonishing picture quality
The HDMI output on this travel adapter supports Ultra HD 4K resolutions, providing four times the picture quality of high-definition 1080p. The HDMI output is also backward compatible with lower resolutions, such as 1080p and 720p, so the adapter is also perfect for your legacy video equipment. The VGA and DVI outputs also support high-definition maximum resolutions of up to 1920 x 1200, so you can still enjoy excellent video quality.

The travel adapter is compatible with USB Type-C Intel® Thunderbolt™ 3 devices that are capable of outputting a DisplayPort signal.

Applications
• Carry the adapter with you when you travel, and connect to almost any display.
• Connect your BYOD Dell XPS, Chromebook Pixel, MacBook or other USB-C laptop or tablet to a provided VGA, DVI or HDMI display at work.
• Connect a VGA, DVI or HDMI monitor to your USB-C laptop, to use as a secondary monitor. Features • 3-in-1 adapter - USB-C to VGA, USB-C to DVI and USB-C to HDMI.
• Maximum portability with built-in cable manager.
• Astonishing picture quality with support for UHD 4K.
• Plug-and-play installation.
• Small footprint.
• Lightweight design.
• Compatible with USB Type-C Thunderbolt 3 devices that are capable of outputting a DisplayPort signal.

Specification
Adapter Style: Adapters
Chipset ID:
- Cypress - CYPD2120-24LQXIT
- Cypress - CY7C65217
- Analogix - ANX9847FN-AA-R
- MegaChips - MCDP2850-BC
Converter Type: Travel A/V Adapters
Output Signal: HDMI, VGA, DVI-D (DVI Digital)
Performance
Audio Specifications: HDMI output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160 @ 30Hz
Supported Resolutions:
- HDMI output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
- DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector(s)
Connector A: 1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B:
- 1 - VGA (15 pin, High Density D-Sub) Female Output
- 1 - DVI-I (29 pin) Female Output
- 1 - HDMI (19 pin) Female Output
Special Notes / Requirements
Note:
- macOS 10.12.6 or later is required for your MacBook to support this product.
- Your USB-C equipped host laptop must support video (DP alt mode) to work with this adapter. The adapter does not support USB Power Delivery.
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
7 days
RTB Period:
12 months
