The Pocket Lab Scientific Multi Sensor Device with Bluetooth

Product Overview What is PocketLab?

Accelerometer Gyroscope Magnetometer Pressure Temperature Altometer

PocketLab is a science lab that fits in the palm of your hand. PocketLab connects with a single button to a smart phone, tablet, Chromebook, or computer and instantly streams data that you can see and record. PocketLab measures motion, acceleration, angular velocity, magnetic field, pressure, altitude, and temperature. Using the PocketLab app, you can easily analyze your data, create graphs, and integrate your data with other software. PocketLab has the same features as lab equipment that costs thousands of dollars but is low cost and intuitive to use.

We believe anyone can be a scientist. PocketLab enables students, educators, and makers to explore the world around them. PocketLab brings science, technology, engineering, and math (STEM) to life like never before possible.

PocketLab measures motion, acceleration, angular velocity, magnetic field, pressure, altitude, and temperature. Using the PocketLab app, you can easily analyze your data, create graphs, and integrate your data with other software. PocketLab has the same features as lab equipment that costs thousands of dollars but is low cost and intuitive to use.

PocketLab connects with a single button to a smart phone, tablet, Chromebook, or computer and instantly streams data that you can see and record.

What can I do with PocketLab?
Here are just few examples of the hundreds of science activities you can do with PocketLab:

• Measure the position, velocity, and acceleration of a rubber band racer cart.
• Discover Newton's Laws of Motion by launching a rocket with a PocketLab payload.
• Learn about weather patterns by investigating changes in air pressure.
• Monitor your change in altitude during a hike.
• Measure the magnetic field generated by an electric current.


What's Included?
• 1x PocketLab Sensor.
• Free downloads of PocketLab and VelocityLab apps.
• More than 40 downloadable science projects and activities that use PocketLab. Features • Bluetooth Smart, Bluetooth Low Energy, Bluetooth 4.0 wireless connection.
• Approximately 150 ft wireless range (outdoor, direct line of sight, tested with iPad).
• Approximately 40-400 hours of operation on CR2032 coin cell battery depending on sensors in use and data rate.
• Durability: can withstand 6 ft drop with protective case.

Accelerometer
• Range: ± 8g
• Offset accuracy: ± 0.025 g
• Resolution: 0.004 g
• Bandwidth: 25 Hz low pass filter
• Sample rate: 1, 10, 20 or 33 samples/sec (high sample rate setting depends on FW version and capabilities of connected device)

Gyroscope
• Range: ±2000 o/sec
• Offset accuracy: user can zero, ±20 o/sec at initialization
• Resolution: 0.1 o /sec
• Bandwidth: 20 Hz low pass filter
• Sample rates: 1, 10, 20 or 33 samples/sec (high sample rate setting depends on FW version and capabilities of connected device)

Magnetometer
• Range: ± 2000 microTesla range
• Resolution: 0.4 microTesla resolution
• Sample rates: 1, 10 samples/sec

Pressure
• Range: 30 to 170 kPa
• Absolute accuracy: 0.1 kPa
• Resolution: 3 Pa (0.3 meters altitude equivalent)
• Sample rates: 1, 10, 20 samples/sec

Temperature
• Range: -20 to 85 oC range (limited by battery operating temp)
• Absolute accuracy: ± 0.5 oC at 25 oC
• Resolution: 0.01 oC
• Sample rates: 1, 10, 20 samples/sec

iOS
• iPhone 4s and newer
• iPad 3 and newer, iPad Air, iPad mini,
• iPod Touch 5th gen and newer

Android
• Android OS 4.4 and newer
• Bluetooth 4.0 hardware support required
• Tested devices: Samsung Galaxy S4, Note 2, Galaxy S7, Nexus 7 Tablet

Chromebook
• Bluetooth 4.0 hardware support required
• Tested devices: Dell Chromebook 11, CTL NL6, Google Pixel

Windows 10
• Bluetooth 4.0 hardware support required
• Windows 10 OS only, not compatible with Windows 7 or 8
• Not compatible with USB Bluetooth dongles
• Tested devices: Microsoft Surface Pro 4, Toshiba Click 10
