HAVN HS 360 VGPU White Dual Chamber Mid Tower Tempered Glass PC Case

HAVN HS 360

The HAVN 360 VGPU Edition adds a Magnetic Airflow Divider above the graphics card, directing cool intake air towards the GPU and helping prevent warm exhaust air from recirculating into the graphics card area. Alongside its support for ATX, BTF ATX, M-ATX and Mini-ITX motherboards, GPUs up to 430mm long and 180mm wide, 170mm air coolers and ATX, SFX or SFX-L PSUs up to 230mm, it features flexible storage options, back-connect ATX support, refined fan and glass mounting systems, enlarged GPU installation slots and anti-vibration brackets.

Broad Hardware Support

The HAVN HS 360 supports ATX, BTF ATX, M-ATX and Mini-ITX motherboards, with CPU air cooler clearance up to 170mm. Graphics cards can measure up to 430mm in length and 180mm in width. The chassis supports ATX, SFX and SFX-L power supplies, with up to 230mm of PSU clearance.

Flexible Storage

The case provides two storage mounting areas. The right fan mount supports 2 × 3.5" or 4 × 2.5" drives, while the cable management tray supports 1 × 3.5" or 2 × 2.5" drives.

Magnetic Airflow Divider

The additional Magnetic Airflow Divider, positioned above the GPU in the VGPU Edition, directs fresh intake air towards the graphics card while minimising the recirculation of warm exhaust air. Testing shows GPU delta temperatures of 48.8°C, 47.8°C, 60.2°C and 52.7°C across the tested configurations, while CPU delta temperatures measured 34.3°C, 33.9°C, 33.5°C and 35.2°C. Adjustable anti-vibration GPU pads are mounted along the glass support strip and make contact with the GPU, allowing compatibility with graphics cards of different lengths. The pad features increased thickness on the GPU-contacting side to enhance vibration isolation and improve overall stability of the Airflow Divider.

Internal Display Support

VESA mounting support for 75 × 75 and 100 × 100 displays is provided on the internal front-right pillar, with support for displays measuring up to 425 × 140mm.

Reduced Visual Distortion

Compared to the HS 420, the HS 360 features a tighter corner radius, reduced from R11mm to R7.5mm, minimising visual distortion for a clearer panoramic view.

Back-Connect ATX Support

Built for the growing back-connect ecosystem, the HS 360 supports back-connect ATX motherboards, enabling cleaner cable management and a streamlined build experience.

Refined Fan Brackets

The enhanced fan bracket allows users to mount fans without interfering with internal components. Top and bottom fan brackets are precisely aligned to simplify custom water-cooling builds, creating a symmetrical appearance.

Refined Glass Mounting

The refined glass mounting system provides enhanced side-panel access with a wider opening, magnetic assistance and roller alignment for easier panel installation.

Easier GPU Installation

Optimised GPU mounting slots provide greater screw alignment tolerance, making screwdriver access easier during GPU installation.

Anti-Vibration Brackets

Every detachable bracket throughout the chassis features integrated anti-vibration rubber pads, minimising vibration and noise while maintaining effortless installation.

Enhanced Structural Strength

Latest in-house testing in the HAVN Lab demonstrates an approximately 36% increase in structural strength compared to the HS 420. The reinforced chassis improves overall rigidity, providing a more solid feel while offering enhanced support for the panoramic glass side panels.

Front I/O

The front I/O includes USB 3.2 Gen 2 Type-C, USB 3.2 Gen 1 Type-A, a combo audio jack and power button.

• Panoramic chassis with dedicated GPU airflow management, broad hardware support and flexible internal display and storage options.
• Supports ATX, BTF ATX, M-ATX and Mini-ITX motherboards.
• Accommodates GPUs up to 430mm long and 180mm wide.
• Supports air coolers up to 170mm and ATX, SFX or SFX-L PSUs up to 230mm.
• Magnetic Airflow Divider directs cool intake air towards the GPU and helps prevent warm exhaust recirculation.
• Adjustable anti-vibration GPU pads accommodate graphics cards of different lengths.
• Thicker GPU-contacting pad sections improve vibration isolation and stability.
• VESA support for 75 × 75 and 100 × 100 displays up to 425 × 140mm.
• Supports up to 2 × 3.5" or 4 × 2.5" drives via the right fan mount.
• Supports 1 × 3.5" or 2 × 2.5" drives via the cable management tray.
• Back-connect ATX motherboard support caters to compatible back-connect systems.
• USB 3.2 Gen 2 Type-C, USB 3.2 Gen 1 Type-A and combo audio jack provided.
• Anti-vibration rubber pads are fitted to detachable brackets.
• Approximately 36% increase in structural strength demonstrated in latest Alpha Lab testing compared with the HS 420.
