Sapphire AMD RADEON RX VEGA 56 8GB HBM2 PULSE Graphics Card
Scan code: LN86804
Manufacturer code: 11276-02-40G
End Of Life
Sapphire AMD RADEON RX VEGA 56 8GB HBM2 PULSE Graphics Card
Sapphire Radeon RX Vega 56 PULSE 8GB HBM2 PCIe 3.0 Graphics Card, 14nm, 3584 Streams, 1208MHz, 1512MHz Boost, DP/HDMI
Scan code:
LN86804
Manufacturer code:
11276-02-40G
This product is no longer available to purchase.
Email me when the availability or price changes
- SCANPROTECT Protect against installation damage for 28 days.
Product Overview
High-End Gaming with Vega 56 GPU
The base of the new SAPPHIRE PULSE graphics card is a powerful Radeon RX Vega 56 chip featuring 3584 Stream Processors running with a factory-overclocked 1512 MHz Boost Clock. 8 GB of 2nd generation High Bandwidth Memory is clocked at 800 MHz (1600 Mbps Effective). Using a switch on the top of the card the user can choose a second UEFI BIOS with an efficiency preset, resulting in slightly lower clocks but also lower temperatures and power draw resulting in a quieter cooling.
• Factory overclocked to 1512 MHz boost clock.
• Efficient dual-fan cooling.
• Stylish PULSE backplate and radiator shroud design.
Dual-X Cooling
To effectively cool a factory-overclocked GPU, SAPPHIRE is using a large heatsink with a copper base and a set of four 8 mm heatpipes. The card’s heatsink actually extends past the short PCB for an increased heat dissipation area. A robust cooling module is also applied to the VRM section, with separate heatsink units connected by a single 6 mm heatpipe and aluminium base. There is also a high thermal conductivity pad on the backplate. Two efficient dual-ball bearing fans spin at a nominal speed of up to 1650 RPM, maintaining a great airflow and quiet operation. Intelligent Fan Control III system ensures the fans start precisely at 55 degrees Celsius, providing a passive, noiseless cooling in idle.
Thanks to SAPPHIRE Quick Connect 2 system, the fans are easily detachable for cleaning or swapping.
Original PULSE Design & Quality
The SAPPHIRE PULSE Radeon RX Vega 56 is a cohesively designed product, with the fan shroud, the aluminium backplate and the back heatsink frame all accentuating the series’ unique style. Making no compromises on components, the SAPPHIRE PULSE Radeon RX Vega 56 features latest generation of Black Diamond Chokes for reduced coil temperatures and better power efficiency. The external PCI-E power connectors have a fuse protection built into the circuit to better protect the card. Features GPU 3584 Stream Processors 14 nm
1512 MHz Engine Clock
1208 MHz Boost Engine Clock
Interface PCI-Express 3.0
Memory 2048 bit Memory Bus
HBM2 Memory Type
800 MHz, 1600 MHz Effective
8 GB Size
BIOS Support UEFI BIOS
Displays Maximum 4 Outputs
Output 1 x HDMI 2.0b
3 x DisplayPort 1.4
Resolution 5120×2880@60Hz Pixel DisplayPort Resolution
4096×2160@60Hz HDMI Resolution
API OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
Feature AMD CrossFire
FreeSync Technology
AMD Eyefinity
AMD Liquid VR Technology
AMD Xconnect ready
DirectX™ 12 Optimized
Radeon VR ready Premium
HDR Ready
Frame Rate Target Control
Dual-X Cooling
Intelligent Fan Control III
Fuse protection
Precision fan control
Robust VRM Cooling
Radeon Chill
Radeon Relive
Cooling Dual-X fans
Two ball bearing
Form Factor 2.5 Part Slot Occupied
282(L)X 125(W)X 50 (H) Dimension /mm
Power Consumption 180W
OS Windows 10 Windows 7
