Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
New
Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
Scan code: LN175449 Manufacturer code: RG-ES209MG-P
£189.98
Get it Tomorrow, 22 OctIn stock
  • Thumbnail 1 : Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
  • Thumbnail 2 : Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
  • Thumbnail 3 : Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
  • Thumbnail 4 : Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch
New

Ruijie RG-ES209MG-P 8-Port Layer 2 Smart Managed Switch

8 Port Ruijie RG-ES209MG-P Switch, Managed, Layer 2, PoE, Fanless, 8x 2.5GbE RJ45 / 1x SFP+

Scan code: LN175449 Manufacturer code: RG-ES209MG-P
£189.98
Order now and get it tomorrow, Thu 22nd Oct
Get it Tomorrow, 22 OctIn stock
Pay in 3 interest-free payments of £63.33

Email me when the availability or price changes

  • By DPD On 22nd Oct Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores

Finance this product

  • From £17.22 / month (APR 16.9%) for 12 months or 0% for 4 months
  • Spend over £390.00 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Product Overview

8-Port 2.5G Cloud-Managed PoE Switch

The Ruijie RG-ES209MG-P features eight 2.5G Ethernet ports and one 10G SFP+ uplink, delivering high-speed connectivity for modern business networks. With support for Wi-Fi 7 deployments, it provides greater internal network throughput to help maintain smooth performance during peak usage and make better use of available bandwidth.


High-Speed Connectivity and PoE

All eight Ethernet ports support IEEE 802.3af/at PoE, with a total power budget of 130W for connected devices. Port aggregation combines up to four ports to increase link capacity, supporting higher network speeds where additional bandwidth is needed.


Smart Network Management

Lifetime free management through Ruijie Cloud lets administrators monitor and manage the switch anytime, anywhere. Built-in features include PoE reboot for remotely restarting powered devices, DHCP snooping to help protect against rogue DHCP servers, VLAN configuration for network segmentation, and loop prevention to help maintain network stability.


Built for Wi-Fi 7 Networks

With 2.5G access ports and a 10G SFP+ uplink, the RG-ES209MG-P provides a high-speed wired foundation for Wi-Fi 7 networks. Increased internal throughput helps reduce wired network bottlenecks, supporting smoother connectivity as network demands grow.

Features

• 8-port 2.5G cloud-managed PoE switch with 1 × 10G SFP+ uplink.
• 2.5G Ethernet connectivity across all eight ports.
• 130W total PoE budget across eight IEEE 802.3af/at PoE ports.
• Link aggregation across up to four ports.
• Lifetime free Ruijie Cloud management, accessible anytime, anywhere.
• PoE reboot for connected devices.
• DHCP snooping and loop prevention.
• VLAN configuration for network segmentation.
• Support for 2.5G full-link network solutions and Wi-Fi 7 deployments.

Specifications
Edition Smart Managed Switch
Form Factor Desktop/Wall Mount
Total Network Ports
  • 8 x 100/1000/2.5G BASE-T RJ45
  • 1 x SFP+
PoE Support Type PoE
No. of Ports Providing PoE 8 x 100/1000/2.5G BASE-T RJ45
Other Non-Network Ports
Switching Capacity 60 Gbps
Non-Blocking Throughput
IDS/IPS Throughput
Forwarding Rate 45 Mpps
MAC Address Table Size 4000 Entries
Network Capacity
Networking Features
  • DHCP Client List
  • Loop Protection
Network Protocols
  • IEEE 802.3af
  • IEEE 802.3at
  • IPv4
  • IPv6
VPN Support
Security Features
Built-in Flash Memory
RAM Memory 1GB
Acoustic Noise
Max. Power Consumption 138.5 W
Max. PoE Wattage per Port 16.25 W
Mean Time Between Failures (MTBF) 200000 hours
Power Supply
  • External Power Supply (Included)
  • PoE
Material
Includes
Dimensions (WxHxD) 202 x 28 x 108 mm
Weight 0.66 kg
Additional Information
Scan Code LN175449
Model Number RG-ES209MG-P
GTIN 6976915003327
