775W Thermaltake TPX-775M ThoughPower XT PSU
Scan code: LN40607
Manufacturer code: TPX-775MPCUK
End Of Life
775W Thermaltake TPX-775M ThoughPower XT PSU
775W ThermalTake TPX-775MPCUK, Modular, 89% Eff', 80 PLUS Bronze, SLI/CrossFire, EPS 12V, Fan, ATX v2.3, PSU
Scan code:
LN40607
Manufacturer code:
TPX-775MPCUK
This product is no longer available to purchase.
Email me when the availability or price changes
- 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.
Product Overview
Continuing its high-performance bloodline, the all-new Toughpower XT is meaner, badder and much more robust.
By utilizing the most advanced double-forward & DC to DC Converter design along with highest-grade Japanese capacitors & solid state capacitors with ability to withstand up to 105°C (221°F), Toughpower XT series power supply is able to deliver unprecedented performance with exceptional voltage regulation, power efficiency and long-lasting reliability that are unrivaled by any of current power supplies on the market.
S.P.T. Indicator: PSU status monitor with 3-mode LED ( standby / PG signal / temperature).
Fan Delay Cool Technology: allows 14cm fan to continue to operate 15-30 sec after system shuts- down to ensure all components are properly cooled.
12Vin1: single +12V rail design providing up to 56A.
Multi-GPU ready: 2 x PCI-E 6+2pin & 2 x PCI-E 6pin for PCI-Express graphic cards.
Active Power Factor Correction (PFC) with PF value of 0.95 at full load.
Auto switching circuitry for universal AC input from 90-264V.
High reliability: MTBF>120,000 hours.
DIMENSION: 5.9”(W) x 3.4”(H) x 6.3” (L);150mm(W) x 86mm(H) x 160mm(L)
Built-in industry grade protections : Over Current, Over Power, Over Voltage, Under Voltage, and Short- Circuit protection.
Safety / EMI Approvals: UL/CUL, FCC, TUV, CE, BSMI, and GOST certified. Features http://uk.thermaltake.com/products-model.aspx?id=C_00001571
By utilizing the most advanced double-forward & DC to DC Converter design along with highest-grade Japanese capacitors & solid state capacitors with ability to withstand up to 105°C (221°F), Toughpower XT series power supply is able to deliver unprecedented performance with exceptional voltage regulation, power efficiency and long-lasting reliability that are unrivaled by any of current power supplies on the market.
S.P.T. Indicator: PSU status monitor with 3-mode LED ( standby / PG signal / temperature).
Fan Delay Cool Technology: allows 14cm fan to continue to operate 15-30 sec after system shuts- down to ensure all components are properly cooled.
12Vin1: single +12V rail design providing up to 56A.
Multi-GPU ready: 2 x PCI-E 6+2pin & 2 x PCI-E 6pin for PCI-Express graphic cards.
Active Power Factor Correction (PFC) with PF value of 0.95 at full load.
Auto switching circuitry for universal AC input from 90-264V.
High reliability: MTBF>120,000 hours.
DIMENSION: 5.9”(W) x 3.4”(H) x 6.3” (L);150mm(W) x 86mm(H) x 160mm(L)
Built-in industry grade protections : Over Current, Over Power, Over Voltage, Under Voltage, and Short- Circuit protection.
Safety / EMI Approvals: UL/CUL, FCC, TUV, CE, BSMI, and GOST certified. Features http://uk.thermaltake.com/products-model.aspx?id=C_00001571
