End Of Life

Seasonic X-Series 750W Modular Power Supply

750W Seasonic X-Series, Full Modular, 80PLUS Gold, ATX, PSU

Seasonic
Scan code: LN47992 Manufacturer code: SS-750KM3 Request call
End Of Life
3xs Approved High End
Product Overview The new Seasonic X-Series is a slightly improved version of the initial X-Series, which was the very first fully modular multi-output, high-wattage ATX power supply that has ever obtained the 80PLUS® Gold certification.

Featuring a patent pending design of DC Connector Module with Integrated VRM, the X Series is set to achieve near-perfect DC to DC conversion and a fully modularized design without compromising efficiency. This top-class PSU delivers the complete package, ultra-high efficiency, greatly improved dynamic response, and customizable cable arrangement that can be tailored to meet any individual’s needs.

The Seasonic X Series adopts a clever Hybrid Silent Fan Control design, which offers three distinct operation modes, Fanless Mode, Silent Mode, and Cooling Mode. The control automatically adjusts the fan mode and its speed according to the ambient temperature level. This creative design not only optimizes heat dissipation, but also prolongs the lifespan of the system by reducing unnecessary fan rotation. To make the X Series even more robust and exciting, Seasonic offers Sanyo Denki San Ace PWM Silent Fan, the best fan there is in the industry with pulse-width modulation.

The X Series represents the Green PC technology that helps computer users save on their electricity bill. It achieves the 80PLUS® Gold standard that guarantees an above 87% efficiency rating across 20%, 50% and 100% loading along with a true power factor of >0.9. Moreover, the X Series is compliant with the Energy Star 5.0 rating and reduces energy consumption under standby, sleep and idle modes.
Features • 80PLUS® Gold Certified Super High Efficiency.
• Full Modular Cabling Design.
• Patented DC Connector Module with Integrated VRM [Voltage Regulator Module].
• DC to DC Converter Design.
• Seasonic Hybrid Silent Fan Control.
• Sanyo Denki San Ace Silent Fan.
• Conductive Polymer Aluminium Solid Capacitors.
• Highly Reliable 105℃ Japanese Brand Capacitors.
• Tight Voltage Regulation [±1%].
• Active Power Factor Correction [99% PF Typical].
• High +12V Output.
