MSI MAG A650BN 650W 80+ Bronze Power Supply

650W MSI MAG A650BN, Fully Wired, 80PLUS Bronze, Single Rail, 54A, 120mm Fan, ATX PSU

Scan code: LN121882 Manufacturer code: MAG A650BN

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores
  • paypal short logo blue 0% UP TO   MONTHS Spend £99 or more and choose PayPal at checkout. More info
  • SCANPROTECT Protect against installation damage for 28 days. More info

Suggested Alternatives

MAG A650BN 650W 80+ Bronze Power Supply from MSI

 MAG A650BN

Your Power, Right AwayEnjoy a safe, reliable and efficient source of power with the MAG A650BN power supply. Featuring an 80 PLUS Bronze certification, DC to DC circuit design, 12V single rail, active PFC and a low-noise fan. This PSU is a perfect choice for entry-level systems and new gamers. Once installed, you can immediately enjoy reliable, excellent performance without additional settings.

650Watts

80 PLUS BronzeEfficiency Rating

ATXForm Factor

Efficient & Excellent

back

80 PLUS BRONZE CERTIFIEDThe efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.

Play with Near-Silent Operation

back

120MM LOW NOISE FANThe fan’s sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.

Stable Power for Ideal Longevity

back

DC TO DC CIRCUIT DESIGNAdopted DC-DC circuit design reduces the instability of output voltage, and adds stability to the supply of power.

Built to Protect your Power

back

COMPREHENSIVE CIRCUIT PROTECTIONSupports OCP, OVP, SCP, OPP, OTP protection mechanisms and provides comprehensive protection.

Crafted to Last for Years to Come

back

5-YEAR LIMITED WARRANTYThe MAG A650BN is proudly backed by a 5-year limited warranty, guaranteeing long term reliable operation.

Specifications
Form Factor ATX
Edition MAG A650BN
Wattage 650 W
Energy Efficiency Certification 80 PLUS Bronze
Max. Efficiency (at 230Vac) 85 %
Cooling Fan
Fans 1 x 120mm
Internal +12V Rails Single Rail
Rail 1 +12V 54 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 54 A
Modular No
Modularity Fully Wired
SLI/CrossFire No
EPS 12V Yes
Motherboard Connector 20+4-pin
Connectors
  • 1 x 4+4-pin CPU +12V (EPS)
  • 1 x 4-pin FDD Power
  • 2 x 4-pin Molex
  • 2 x 6+2-pin PCIe
  • 5 x SATA
Dimensions 150 x 86 x 140 (WxHxD)
Package Type Retail
Warranty 5 Year
Additional Information
Scan Code LN121882
Model Number MAG A650BN
GTIN 4719072870478
