SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply
SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply
Scan code: LN110844 Manufacturer code: SST-FX500-G
Call for price
  • Thumbnail 1 : SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply
  • Thumbnail 2 : SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply
  • Thumbnail 3 : SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply
  • Thumbnail 4 : SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply

SilverStone 500 Watt FX500-G Flex Fully Wired PSU/Power Supply

500W SilverStone FX500-G Flex Series, Fully Wired, 80 PLUS Gold, Single Rail, 41.67A, 40mm Fan, Flex ATX
MORE INFO
MORE INFO

Scan code: LN110844 Manufacturer code: SST-FX500-G
Call for price

Email me when the availability or price changes

  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • UPS and DPD Pickup Pickup from local convenience store | £4.99 Collect your parcel from your newsagents, petrol stations and convenience stores
  • SCANPROTECT Protect against installation damage for 28 days.
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan.

Suggested Alternatives

Product Overview

SilverStone FX Flex Series Fully Wired Power Supply

Designed for 80 PLUS Gold level of efficiency to reduce wasted heat and save on electricity, the FX500-G features a powerful single +12V rail design, perfect for future high-end component upgrades or overclocking, ±3% regulation and low ripple & noise performance for high stability and soft and flexible thin cables designed to ease cable management process. The Japanese primary capacitor ensures reliable power and long-life, while the built-in 40mm fan offers excellent airflow and low noise, perfect for home or office use. Advanced protections for saftey and security include over power, over voltage, short circuit and over temperature protection.

Features

• Support standard Flex ATX form factor.
• High efficiency with 80 PLUS Gold certification.
• Japanese primary capacitor.
• 500W continuous power output at 40C operating temperature rated for 24/7 operation.
• Class-leading single +12V rail.
• PCIe 8pin and PCIe 6pin connectors support.
• ±3% regulation and low ripple & noise performance for high stability.
• Active PFC.

Specifications
Form Factor FlexATX
Edition FX500
Wattage 500 W
Energy Efficiency Certification 80 PLUS Gold
Max. Efficiency (at 230Vac) 87 ~ 90 (20% to 100% loading) %
Cooling Fan
Fans 1 x 40mm
Internal +12V Rails Single Rail
Rail 1 +12V 41.67 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 41.67 A
Modular No
Modularity Fully Wired
SLI/CrossFire No
EPS 12V Yes
Motherboard Connector 20+4-pin
Connectors
  • 1 x 4+4-pin CPU +12V (EPS)
  • 1 x 4-pin FDD Adapter
  • 3 x 4-pin Molex
  • 2 x 6+2-pin PCIe
  • 4 x SATA
Dimensions 81.5 x 40.5 x 150 mm (WxHxD)
Package Type Retail
Warranty
Additional Information
Scan Code LN110844
Model Number SST-FX500-G
GTIN 4710679810379
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Direct
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
Manufacturer:
Scan/ScanView
Telephone:
08718716733
