EVGA 500B 500W PSU/Power Supply - 100-B1-0500-KR
Delivery
DPD £5.48 Delivered by DPD Tue 27 Sep. Delivered to your specified address. Receive SMS with one-hour delivery window.
UPS Access Point £4.79 Collect from local shops Collect your parcel from your newsagents, petrol stations and convenience stores.
Collect Instore Free Collect Instore Place your order online and collect from our Bolton store with Q-Collect.
Weekend, timed and European delivery options are available at checkout

100-B1-0500-KR - 500W EVGA 500B, 80 PLUS Bronze, Non Modular, Single Rail, 40A +12V, ATX PSU

EVGA 500B 500W PSU/Power SupplyEVGA 500B 500W PSU/Power SupplyEVGA 500B 500W PSU/Power SupplyEVGA 500B 500W PSU/Power Supply
EVGA 500B 500W PSU/Power Supply

Suggested Replacements

Sort by:

Page style:

1

500W EVGA 100-W1-0500-KR, 80PLUS White, Single Rail, ATX, PSU
  • High End Rating
  • Rated 4.8 out of 5 by 12 people Customer Review

£33.32 ex VAT

£39.98 inc VAT

Product Overview

EVGA 500B 80PLUS BRONZE

EVGA 430W

500B - Best Value

With price and performance in mind, the EVGA 500B is the best value power supply for your next build on a budget. With 80 Plus Bronze standard, over 80% efficiency under typical loads, the EVGA 500B is a great choice. Combining 500W of continuous power and Single +12V High AMP rail design, gain maximum power and efficiency while staying protected with a series of over volt/over current protections all bundled into one!

Power Chart

AC Input
DC Output
Max Output
Combined
Output

Large 40 amp single + 12V Rail

100 - 240 VAC / 10 - 5A / 50 - 60Hz
+3.3V +5V +12V +5Vsb -12V
24A 20A 40A 3A 0.3A
120W 480W 15W 3.6W
500W @ +50C

Industrial grade testing all load and regulation testing done at 50C

Features

Single +12V Rail
A single +12V rail offers the best power output, rail stability and compatibility with the latest hardware. EVGA SuperNOVA 500B provides up to 40A on a single rail.

Continuous Power
The EVGA 500B PSU’s are rated in continuous power, rather than peak. This ensures the longevity and stability at the officiall rated wattage, rather than rating off am unsustainable peak wattage.

80PLUS Efficiency
80 Plus certification ensures your power supply isn’t wasting power and turning it into exess heat. Under typical load this power supply is 85% efficient or higher.

Features
• Exceptional 3 Year warrenty and unparalleled EVGA customer support
• 80PLUS Bronze Certified, with up to 85% efficiency under typical loads
• High amperage single-rail design for maximum power and efficiency
• Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Technical Specification
General
Manufacturer:
EVGA
Size:
ATX
Edition:

Wattage:
500 W
80 PLUS Certification:
80 PLUS Bronze
Max. Efficiency:
85 %
Cooling:
Fan
Fans:

Internal +12V Rails:
Single Rail
Rail 1 +12V:
40 A
Rail 2 +12V:
N/A
Rail 3 +12V:
N/A
Rail 4 +12V:
N/A
Rail 5 +12V:
N/A
Rail 6 +12V:
N/A
Max. Combined Output +12V:
40 A
Modular:
No
Modularity:
Non Modular
SLI/CrossFire:
No
EPS 12V:
Yes
Motherboard Connector:
20+4 Pin
Connectors:
  • 1 x 4+4pin CPU +12V
  • 3 x 4pin Molex
  • 2 x 6+2pin PCI-E Power
  • 1 x FDD Power
  • 6 x SATA Power
Dimensions:
150 x 85 x 140 mm (WxHxD)
Warranty

For further information regarding Scan's warranty procedure please click here

Details
Duration:
36 months
Type:
Direct
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
EVGA
Telephone:
01788 247 298
Recommend This Product

To tell a friend about this product please fill out your name and enter their email address.

  • Send
Find Similar Products

Find similar products with the same specifications as 500W EVGA 500B, 80 PLUS Bronze, Non Modular, Single Rail, 40A +12V, ATX PSU . Please choose from the list below.

ATX

Please tick the check box above

Please tick the check box above

500 W

Please tick the check box above

80 PLUS Bronze

Please tick the check box above

85 %

Please tick the check box above

Fan

Please tick the check box above

Please tick the check box above

Single Rail

Please tick the check box above

40 A

Please tick the check box above

N/A

Please tick the check box above

N/A

Please tick the check box above

N/A

Please tick the check box above

N/A

Please tick the check box above

N/A

Please tick the check box above

40 A

Please tick the check box above

No

Please tick the check box above

Non Modular

Please tick the check box above

No

Please tick the check box above

Yes

Please tick the check box above

20+4 Pin

Please tick the check box above

1 x 4+4pin CPU +12V
3 x 4pin Molex
2 x 6+2pin PCI-E Power
1 x FDD Power
6 x SATA Power

Please tick the check box above

150 x 85 x 140 mm (WxHxD)

Please tick the check box above
Customer Reviews
Rated 4.8 out of 5 by 6 reviewers.
Rated 5 out of 5 by Works as expected This power supply does exactly what it says on the tin, and although upon inspection of the insides some parts looked bent out of place it turned out that I was just unaware of how it was supposed to look. 20 July 2015
Rated 5 out of 5 by Does what it says on the tin So far so good. Easy to install and very quiet. Looks like a quality product. 11 July 2014
Rated 4 out of 5 by Great value for money Great product, great performance. The value for money is amazing 12 June 2014
Rated 5 out of 5 by It does the job Nice product..for the value of money it gives you exactly what you need. enouf power + reliability . Definitely is a good choice for a medium build. 28 May 2014
Rated 5 out of 5 by super thx very good super thx very good super thx very good super thx 26 April 2014
Rated 5 out of 5 by Good quality, works well Haven't had any problems yet with this. First time putting a computer together and had no problems with it. Pretty quiet and works fabulously. 19 April 2014
