End Of Life Sale
Scan code: LN23301 Manufacturer code: RS-500-AMBA-D3

Coolermaster RS-500-AMBA-D3 Silent Pro M 500W Modular Power Supply (PSU)

500W Coolermaster Silent Pro M500, Modular, 85%Eff', 80Plus Bronze, SLI/CrossFire, EPS 12V, 135mm Quiet Fan, ATX, PSU

Thumbnail 1 : Coolermaster RS-500-AMBA-D3 Silent Pro M 500W Modular Power Supply (PSU)
Coolermaster RS-500-AMBA-D3 Silent Pro M 500W Modular Power Supply (PSU) : image 1
Scan code: LN23301 Manufacturer code: RS-500-AMBA-D3
End Of Life This product is no longer available to purchase
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview Astutely building on the trustworthy Silent Pro series, Cooler Master now proudly presents the Silent Pro M500 power source unit. Whether creating your own personalized tower or upgrading your old power supply to meet the stringent demands of new, power hungry hardware, this PSU has the brawn and brilliant design to bring a satisfying grin to any computer aficionado.

Riding a singular 12V rail, the Silent Pro provides a generously abundant power source to any computing system, without the worry of balancing power loads on multiple rails.

The Silent Pro M500 is 80Plus Bronze certified with a stalwart efficiency rating of 85% and an active PFC keenly minimizing power loss by adjusting input power to the levels detected, which not only guards against energy loss, but also saves connected hardware from failure due to unknown power surges. A skillfully crafted aluminum-copper heatsink combined with a fin design ingeniously dissipates heat through thermal conductivity, lowering the temperature and thus extending the life of the fan and ultimately, your computer.

Integrating these impressive components with a 135mm intelligent fan harmoniously working with your PSU with an almost unmatched tranquility, and flat, modularized cabling providing facility of arrangement and strikingly improved heat dissipation, creates an immaculate case you will want to leave uncovered for all to admire.


Copper-Aluminum Heat Sink
This slick CM design incorporates an expansive flat surface area for superior heat conductivity out to the aero-dynamic fins, therefore removing heat at an unprecedented rate.

135mm Intelligent Fan
Barely audible, the 135mm intelligent fan spins effortlessly to the cooling needs of your system, effectively air-conditioning even the most power-intensive systems so quietly, you will wonder if it’s on.

Power Protection
Active Power Factor Correction (PFC) justly allocates AC power through the system by utilizing circuitry to correct power fluctuations from the input, shrewdly minimizing power loss, consequently supporting greater efficiency.

NVIDIA SLI-Ready Certified
The Silent Pro M500 is judiciously qualified to support any NVIDIA SLI computing configuration after acing numerous intense NVIDIA tests.

Intel Compliant
Proficiently prepared to provide a stable power source and connectors for the latest ATX 12V v2.3 Intel processors and SSI standard EPS 12V v2.92 systems.

Single 12V Power Rail
This singular stout 12V power rail maximizes power control to connected elements with 80A flowing through it, reducing the need for load balancing on multiple rails.

Modularized Cabling
Neatly arranged connectors on the rear plate connect to flat internal cabling improve installment facility while allowing for greater airflow through the PSU.

80Plus Bronze Certification
The Silent M500 has been stringently put through multiple heat and power loading testing, competently earning a honorable bronze certification from 80Plus, reassuring every owner that their system is well protected.

…And So Much More
- Shock-absorbing silicon pads reduce undue vibration for enhanced noise suppression.
- High reliability with an MBTF of at least 100,000 hours of use.
- Multiple protection design including OVP/UVP/OPP/OTP/SCP/OCP.
- Five Year Warranty.
Features •The single rail is with up to 50A on the 12V rail, delivers where it counts and won't have any problems powering even the most demanding SLI
• Modularized cable design to Eli min ate clutter and improve airflow inside the chassis
• Two 6+2 pin PCI-e connectors for multiple graphic card set up
• Energy efficient design that meats 80 Plus requirements
• Single +12V rail provides more power for over-clocker
• Compliant with Intel standard Intel ATX12V V2.3 & SSI EPS 12V V2.91
• Green power design that meets energy star, blue angel requirements
• Super silent operation with intelligent 135mm fan speed control
• Protection: OVP / UVP / OCP / OPP /OTP / SCP / OLP

Model RS-500-AMBA-D3
Type Intel ATX12V V2.3 ? SSI EPS 12V V2.91
Dimension (W / H / D) 150(W) x 86(H) x 150(L) (mm)
Input Voltage 90~264V (Auto Range)
Input Current [email protected], [email protected]
Input Frequency Range 47~63Hz
PFC Active PFC >0.9
Power Good Signal 100~500ms
Hold Up Time >17ms
Efficiency 85% Typically
MTBF >100,000hrs
Protection OVP/ UVP/OCP/OPP/OTP /SCP/ OLP
Output Capacity 500W
Max. Output Capacity 620W
Operation Temperature 0~40°C (Nominal Input Voltage)
Regulatory NEMKO / TUV / CE / GOST / C-tick / / UL / FCC
Fan 135mm ultra silent fan
Certifications 80 Plus
Connector M/B 20+4 Pin Connector x 1
CPU 4+4 Pin x 1
PCI-E 6+2 Pin x2
4 Pin Peripheral x 5
SATA x 6
4 Pin Floppy x 1
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
60 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
60 months
