Offer
Scan code: LN56331 Manufacturer code: TL-SF1005D

TPLINK 5 Port 10/100 Compact Size Ethernet Switch TL-SF1005D

5 Port TP-LINK TL-SF1005D Mini Desktop 10/100 Fast Ethernet Switch

MORE INFO
MORE INFO
Thumbnail 1 : TPLINK 5 Port 10/100 Compact Size Ethernet Switch TL-SF1005D Thumbnail 2 : TPLINK 5 Port 10/100 Compact Size Ethernet Switch TL-SF1005D Thumbnail 3 : TPLINK 5 Port 10/100 Compact Size Ethernet Switch TL-SF1005D Thumbnail 4 : TPLINK 5 Port 10/100 Compact Size Ethernet Switch TL-SF1005D
Scan code: LN56331 Manufacturer code: TL-SF1005D
Was: £6.98
£5.99
Add To Basket
In stock
Order now and get it tomorrow, Tue 7th Jul
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 7th Jul to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Frequently Bought Together
Product Overview What This Product Does
The TL-SF1005D 5-Port 10/100Mbps desktop switch provides an easy way to expand your wired network. All 5 ports support auto-MDI/MDIX, eliminating the need to worry about the type of cable to use. Featuring full duplex mode, the TL-SF1005D can process data at a rate of up to 200Mbps making it an ideal choice for expanding your high performance wired network. Moreover, with innovative energy-efficient technology, the TL-SF1005D can save up to 60% of power consumption, making it an eco-friendly solution for your home or office network.

High Performance
TL-SF1005D Fast Ethernet Switch provides 5 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports..Featuring non-blocking switching architecture,TL-SF1005D forwards and filters packets at full wire-speed for maximum throughput. With 10K Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1005D work reliably.

Easy to Use
The auto features of this ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

• 5 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX.
• Green Ethernet technology saves the power up to 60%.
• IEEE 802.3x flow control provides reliable data transfer.
• Plastic case, desktop design.
• Plug and play, no configuration required. Features • Innovative energy-efficient technology saves power up to 60%.
• Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode.
• Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput.
• Auto-MDI/MDIX eliminates the need for crossover cables.
• Supports MAC address auto-learning and auto-aging.
• Auto-negotiation ports provide smart integration between 10Mbps and 100Mbps hardware.
• Fanless design ensures quiet operation.
• Desktop design.
• Plug and Play design simplifies installation.
Specifications
Edition
Form Factor
Total Network Ports 5 x Fast Ethernet 10/100
PoE Support Type
No. of Ports Providing PoE
Other Non-Network Ports
Switching Capacity
Non-Blocking Throughput
Forwarding Rate
MAC Address Table Size
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols IEEE 802.3x
Acoustic Noise
Max. Power Consumption
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply
Material
Includes
Dimensions (WxHxD) 103.5 x 22 x 70 mm
Weight
Additional Information
Scan Code LN56331
Model Number TL-SF1005D
GTIN 6935364020064
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Direct
DOA Period:
28 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
TP-LINK
Telephone:
0845 147 0017 (UK) or 0818 229 000 (Ireland)

Additional Notes:
UK Users Tel:
0845 147 0017

E-mail:
[email protected]

http://uk.tp-link.com/support-contact.html#E-mail-Support

Service Time:
24 hours a day, 7 days a week

Procedures in Detail

Step 1: Contact us through our Technical Support Line 0845 147 0017 (UK) or 0818 229 000 (Ireland), a representative will help you with remote troubleshooting. If the product is judged to be defective, the representative will provide you with a unique RMA number. Customer contact and product info will be requested during this process.

Step 2: An email explaining the RMA process will be sent from TP-LINK UK.

Step 3: Send defective product, purchase receipt along with RMA number to TP-LINK.

Note: Customers are responsible for the shipping fee in Step 3.

Step 4) Once the defective product is received, TP-LINK UK Limited will send back a replacement and inform customer of the tracking number. The warranty starts from the purchase date of your original unit and lasts for 2+1 years on SOHO products regardless of how many replacements are made.

Note: TP-LINK UK Limited will pay the one way shipping fee in Step 4

PLEASE NOTE: If you register your product with TP-LINK then you can enjoy a free 3rd year warranty.

Registration http://warranty.uk.tp-link.com/register.aspx
Sign in portal http://warranty.uk.tp-link.com/SignIn.aspx
Warranty information http://uk.tp-link.com/rma.html

Loading Please Wait

Please wait . . .

TekSpek Guides
Port Forwarding
Port Forwarding
Date Issued: 20th Oct 2008

Port forwarding is a technique you’ll need to use to enable certain services if you’re using a router. If you don’t really care how it works, you can skip this section and just find out how to do it.

Read More

Home Networking
Home Networking
Date Issued: 26th Oct 2006

As a growing number of homes contain more than one computer, their users must find ways to network them. The primary purpose for creating a home network tends to be to provide Internet access to all computers within the house. There are other good reasons, however. These include enabling LAN gaming, data backups from one machine to another and the sharing of music within the home.

Read More

Reviews
5 Port TP-LINK TL-SF1005D Mini Desktop 10/100 Fast Ethernet Switch is rated 4.3 out of 5 by 3.
Rated 5 out of 5 by from Nice unit For the price this is excellent, using it to increase the number of connections from a tp link power line set, it works beautifully and taken all my home entertainment units of wi fi. It’s all very stable now with very little lag or stalling.
Date published: 2019-11-20
Rated 3 out of 5 by from Good for casuals. Exactly what you get for spending a small amount for a lan switch. My use is to act as an extension into my room from where the router is placed as i use all the internet in the house only. Does quite fairy at a lan party where playing lan games and all playing online like cs go or BF4 does very well. Low ping ect. The only (expected) disappointment is that when transferring large amount of data through one pc to another lets say through windows teamgroup, the recipients transferring and receiving data cant play games without incredibly high 400+ ping. That's probably the pc's fault though.. Overall a nice cheap entry level lan switch for the casuals.
Date published: 2015-08-10
Rated 5 out of 5 by from does what it says in the box No problems, it just works, plug it in and away it goes. I used it on the end of a long cable to extend broad band router. Same product on ebay, but more expensive, I would deffinatly recommend.
Date published: 2014-05-16
