Scan code: LN138952 Manufacturer code: USB2-EXT4P

Scan USB 2.0 4 Port Extender over Ethernet

4 Port Scan USB 2.0 4 Port Extender Over Ethernet, Up to 150m Over Cat6/7 (480 Mbps), 4x USB-A Input, 1x USB-A Output

Scan code: LN138952 Manufacturer code: USB2-EXT4P
Order now and receive it by Tuesday, 12th December
Get it Tuesday, 12 DecIn stock
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 12th Dec to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

Scan 4 Port USB 2.0 Over Ethernet Extender

The USB2-EXT4P is a 4 Port USB2.0 Extender. It operates as one-to-one connection through CAT5e/6/7 Ethernet cables, with a transmission distance of up to 100m for CAT5e and 150m for CAT6 and above; When the connection passes through a Gigabit Ethernet Switch, the input and output cable lengths can reach 100m (Cat5e) or 150m (Cat6/7) respectively.

It supports 4 channels of USB 2.0 device input, such as printer, camera, scanner, USB flash drive, keyboard, mouse, touchscreen, etc., and supports Gigabit switch cascade. It can be used for security monitoring, gaming, industrial control, professional audio-visual, and other fields.


• Compatibility: USB 2.0, compatible with USB1.1, USB1.0.
• Transmission Rate: High-Speed (480 Mbps), Full-Speed (12 Mbps), Low-Speed (1.5Mbps).
• Transmission Distance: CAT5e = 100m, CAT6 / 6A / 7 = 150m.
• Supports USB Hot-Plug.
• Operating System: Windows, MacOS, Linux and Android.
• 4x USB-A Input.
• 1x USB-A Output.
• Follows IEEE-568B standard.

Interface USB 2.0
Connectivity 5 x USB 2.0
Additional Information
Scan Code LN138952
Model Number USB2-EXT4P
GTIN 5055781250255

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

12 months
Return to base
DOA Period:
7 days
RTB Period:
12 months
