Product Overview For the most demanding processing and graphics intensive applications, UniWorkstation platform will meet and surpass expectations.

Often times, workstations are integrated using combination of desktop and server components, thus, excelling in certain area of computing but lack in other. UniWorkstation is a tightly integrated, full-featured platform that can excel in all aspects of performance requirements of a powerful workstation.

The key objective for UniWorkstation is to overcome the major areas that are often bottleneck. UniWorkstation starts the latest AMD Opteron™ processor for Socket F (1207) supported, AMD Opteron™ main board. When additional processing power is needed, 2-way can be scaled to 4-way configuration by plugging in a CPU & Memory board. In addition, 8 DDR2 667MHz DIMM sockets are supported per CPU. This first-in-industry feature increases the performance/value mix by reducing the cost of system memory by up to 100% over competition.

In line with extreme processing and data buffering capability, UniWorkstation has built-in SATA with RAID 0, 1, 1E, maximizing on disk I/O with striping data across multiple disks. Data transfer is optimized with on-board dual PCI-Express Gigabit Ethernet ports.

With 3 PCI Express slots, SLI is supported, aggregating dual GPU's and delivering world-class graphics performance. Last but not least, UniWorkstation employs cable-less and tool-less integration. This well thought-out packaging keeps all components ultra cool and easy to maintain, thus, optimizing on reliability and TCO.

More details.... Features Performance
Capable of supporting 2-way or 4-way, AMD Opteron™ processor for Socket F (1207) ,64-bit AMD Opteron™ processors with integrated memory controller is unsurpassed in processing power. In addition, up to 8 DIMM sockets per CPU provides up to double the memory capacity of any current 64-bit server platform available in the market.

Scaling from 2-way to 4-way CPU configuration is done by adding a CPU & Memory board. Up to 6 hot swap SATA II hard disk drives offers Terabytes of internal storage capacity. Simultaneous support for PCI-Express (up to three) and PCI-X slots (up to three) can accommodate various add-on cards to meet the I/O demand increase on as-needed-basis.

UniWorkstation is full featured, highly available workstation platform. Most commonly failed components such as HDD, PSU and fans are hot swap, redundant. In the case of SATA devices, RAID 0, 1, and 1E is a standard feature. Dual PCI-Express Gigabit Ethernet can be aggregated for increased throughput as well as fail-over.

Over ten years of high-end system design experience and recent utilization of cable-less & tool-less integration makes the UniWorkstation the coolest running system. This advancement in integration method completely eliminates failure due to component life degradation due to excessive heat or aging of various cables.

The reduced cost of the memory is up to 100% when configuring 16GB per CPU. Furthermore, higher performing, AMD Opteron™ processor for Socket F (1207) based systems require 37.5% less number of systems compared to competition as well as reduced power consumption.

Standard Features:
• Supports 4-way, AMD Opteron™ processor for Socket F (1207)
• 8 DIMM sockets per CPU, Total 32 sockets, 128GB/System, DDR2 400/533/667 ECC registered
• Three PCI-Express and three PCI-X slots
• Two PCI-Express Gigabit Ethernet ports
• Eight hot-swap, SAS HDD drive bays
• 3.5" FDD
• Support NVIDIA SLI(Scalable Link Interface) Function
• 1000W(2+1) hot swap redundant power supply with PFC
• Powerful & ultra quiet cooling fans
• Cable-less and Tool-less integration
• Mid-tower pedestal design.
Form Factor
CPU Included No
CPU Type
CPU Model
Manufacturing Process
Unlocked CPU No
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP
CPU Socket F (1207) x 4
Chipset nForce Pro 2200
Motherboard Form Factor
Motherboard Model
Memory Type DDR2
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels
Memory Type (ECC) ECC
Memory Type (R/U) RDIMM (Registered)
Memory Speed (Mhz)
  • DDR - 400
  • DDR2 - 533
  • DDR2 - 667
Max. Memory Capacity 128GB
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip N/A
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe (x16)
Expansion Slots
  • 3 x PCI-X (64bit 133MHz)
  • 2 x PCIe x16
  • 1 x PCIe x16 (x4 bandwidth)
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive None
Drive Bays
  • 1 x 3.5"
  • 2 x 5.25" External
  • 8 x SAS
Backplane I/O
Internal I/O N/A
Network Interface Type
Network Chip/Modules
Front Panel
  • 1 x Firewire
  • 1 x Line Out
  • 1 x Mic In
  • 2 x USB 2.0
Back Panel
  • 2 x 10/100/1000 (LAN)
  • 1 x D-Sub (VGA) Out
  • 1 x Firewire
  • 1 x PS/2 Keyboard
  • 1 x PS/2 Mouse
  • 1 x SAS
  • 1 x Serial (COM)
  • 2 x USB 2.0
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 1000 W
PSU Efficiency Rating
PSU Redundancy N/A
Operating System Included No
Operating System N/A
Colour Black
Dimensions 131.0x 430.0 x 698.0 mm (mm WxHxD)
