Synology DS209+ Ultra-High-Speed 2-bay (upto 2TB) NAS Server with RAID 0 or 1 Data Protection

Scan code: LN25251 Manufacturer code: DS209+ Request call
Pay on Scan Finance with a 10% deposit from just £8.39 / month (APR 15.9%)
High End
Delivery options £5.48 By DPD On 22nd Nov 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview The DS209+ Ultra-High-Speed 2-bay NAS Server with RAID 1 Data Protection, Intuitive AJAX-based User Interface, Smart FAN, and Energy-Saving Design. The DS209+ is the ideal choice for businesses and entry corporations demanding ultra-high performance NAS server of proficient storage capacity scale.

Designed with modern simplicity fashion, Synology DS209+ with its 800MHz CPU and 512MB RAM delivers impressive performance, brings forth the concept of energy saving with Power On/Off design, and offers variable RAID management. The 3-speed smart fan control is applied to ensure a cool and quiet NAS server in the office environments.


Surveillance Station
Photo Station 3
File Station
Audio Station
Web Station
Download Station 2
iTunes Server

Speedy Performance
Synology DS209+ provides speedy data transmission and powerful computing capability with proven statistics. Within RAID 1 configuration, the DS209+ reaches 42+MB/Sec in reading and 36+MB/Sec in writing based on the built-in high level CPU and RAM standards. It accelerates efficiency by maximizing user accounts to 2,048, user groups to 256, and concurrent connections to 256.

Smart Fan Design
The Synology DS209+ adopts 3-speed smart fan control. The fan operates in a full, middle, and low speed based on temperature fluctuation. This helps to cool down the machine while a quiet working environment is guaranteed. And more importantly, the automatic speed adjustment design saves the unnecessary power consumption caused by fan spinning.

Intuitive User Interface
Using the lastest Disk Station Manager 2.0 this offers a broad range of pragmatic and refined functions on its well organized and responsive user interfaces. Utilizing the AJAX technology, sophisticated designs of Synology DS209+, such as fast searching, file sharing, drag-n-drop My favorites, and data auto check, come true in a simplified presentation. Led by the innovation and beauty of this presentation, users are able to surf the Linux system as they would do in a Windows environment.

Energy Saving
The Power On/Off application added to the Synology DS209+ gives users the freedom to set the system to power on or power off modes at a specified time as they wish, which assists users to better watch out their wallets, especially in the age of high oil price.

RAID Management

Volume Type: Basic, RAID 0, RAID 1
Upgrade from Basic to RAID 1
Expand RAID 1 with Larger Hard Drives Features External HDD Interface: USB 2.0 port X3, eSATA port x1 (front)
Speedy Performance
Smart Fan Design
Intuitive User Interface
Energy Saving
Secured Internet File Sharing
Flexible Storage Management
Total Backup Solution
Economic and Integrated NVR Solution
Multiple Corporate Websites Hosting
RAID Management RAID 0, RAID 1

File System - EXT3, FAT (External Disk Only) & NTFS (External Disk Read Only)

CPU Clock Rate: 800 MHz
RAM Size: 512MB
Internal HDD: 3.5” SATA(II) X2
External HDD Interface: USB 2.0 port X3, eSATA port X1
Size: 160mm X 218mm X 88mm
Weight: 0.98kg
LAN: Gigabit X1
Fan: X1(70mmX70mm)
Noise Level:(5) 25dB(A)
Power Recovery
AC Input Power Voltage: 100V to 240V
Power Frequency: 50Hz to 60Hz, Single Phase
Max Capacity (Internal HDD): 2 TB (See All Supported HDD)
Max Supported IP Camera: 10


AJAX-based Management UI
BitTorrent Port Range Setup
BitTorrent DHT Support
CIFS Recycle Bin
Download Station Bandwidth control
Download Station Port Range Setup
Editable HTTP Error Page
Email Alert Message
Email Notification for New User
Package Management
External HDD Hibernation (eSATA, USB)
Scheduled Power On/Off
Firmware Upgrade
FTP passive port range
Hide-able Shared Folder
Internal HDD Hibernation
Movable Shared Folder
Removable Default Shared Folder
Telnet/SSH Support
UPS Management (Over USB 2.0)
User Quota
Web-based Download Station
