Product Overview PreSonus Ships AVB Networking for StudioLive Active Integration Mixers
April 15, 2015
Click for larger image.

PreSonus® is now shipping its SL-AVB-MIX Audio Video Bridging (AVB) audio networking option card for StudioLive™ AI-series console and StudioLive™ RM-series rack-mount Active Integration™ mixers. These options allow you to create a complete, networked live-sound solution, using CAT5e or CAT6 cables instead of a snake—and that’s just the beginning.

AVB enables precisely synchronized, real-time, low-latency, streaming of audio across an Ethernet network with no-hassle, self-configuring, true plug-and-play convenience. All StudioLive RM-series mixers already have the SL-AVB-MIX option card installed and just need a firmware update to enable the new AVB networking functionality. The card is offered as an upgrade option for StudioLive AI console mixers.

With this first phase of AVB support, you can use the StudioLive RM32AI or RM16AI as a stage box and monitor mixer for any StudioLive AI-series front-of-house (FOH) console mixer. Remote-control the StudioLive RM-series mixer’s recallable, Class A XMAX™ preamps from the console; take advantage of the RM mixer’s 16 additional aux mixes; and use the RM mixer’s Fat Channel processing and FX buses for independent monitor mix processing from the FOH mix.

Thanks to PreSonus Active Integration technology, the mixers on the AVB system can be set up, and your mixing workflows synchronized, in a single step. All input routing to and from the onstage RM mixer and the AI console mixer at FOH is configured automatically. You simply change the channel source from “analog” to “network” on the channels you want to source from the other mixer.

In addition, the talkback and main L/R mix from FOH are set up as the talkback input and main L/R outputs on the RM mixer onstage. The talkback on/off at FOH also engages the talkback onstage, making it easy to communicate with the band. PreSonus Active Integration also keeps your scene save and recall in sync between the mixers in the system.

Both mixers can be controlled using PreSonus UC Surface touch-control software or VSL-AI and SL-Remote AI for Mac®, Windows®, and iPad®, and all aux mixes can be wirelessly controlled using PreSonus QMix™-AI for iPhone® / iPod® touch. All audio and control data flows over one slender Ethernet cable, so you can shed that heavy, noisy analog copper snake.

“This is just the beginning of PreSonus AVB networking,” commented Ray Tantzen, Senior Product Manager for PreSonus. “We have big plans to unleash the true power of a networked audio system. Our implementation of AVB will continue to grow, supporting more workflows and more devices from PreSonus and other manufacturers. With more manufacturers getting onboard with AVB, we are very excited about the future.” Features • Network any StudioLive RM-series rack-mount mixer with any StudioLive AI-series console mixer, enabling the RM-series mixer to be used as a remote stage box and monitor mixer.
• Replace hundreds of dollars of analog copper snake with one CAT5e or CAT6 Ethernet cable.
• Add a complete monitor mixer on stage, with independent Fat Channel processing and effects.
• Send up to 32 input channels from the StudioLive RM stage mixer and 32 input channels, the Main L/R Mix, and Talkback from the StudioLive AI console at FOH across the network.
• Add 16 more aux mixes.
• Control with free UC Surface software for Mac, Windows, or iPad, including support for Windows 8 touchscreens.
• Control individual aux mixes with an iPhone/iPod touch using free PreSonus QMix-AI.
• FOH can source any input from the remote StudioLive RM-series mixer's analog and FireWire inputs.
• Onstage StudioLive RM monitor mixer can source any input from the local analog or remote FOH mixer.
• Linked talkback: Talkback input on the StudioLive AI console is the source for StudioLive RM's talkback, and pressing Talkback on the AI-series console engages talkback on the RM-series stage mixer.
• Linked scene save and recall.
• Simple one-step connection takes care of all default routing and setup.
Total Channels
Max Mic Inputs
Computer Interface
Mixer Type
Computer Interface Channels
Total Aux Channels
Max Line Inputs
Insert Points No
Direct Channel Outputs
Internal FX No
Flying Faders No
