20 x Scan S-WDG75 Acoustic Foam Wedge Tiles
Scan code: LN38646
Manufacturer code: S-WDG75
End Of Life
20 x Scan S-WDG75 Acoustic Foam Wedge Tiles
Scan S-WDG75 Acoustic Foam Wedge Tiles - 425mm x 425mm x 75mm (Box of 20 Panels) - Grey
Scan code:
LN38646
Manufacturer code:
S-WDG75
This product is no longer available to purchase.
Email me when the availability or price changes
Product Overview
The acoustic foam grade we use is specifically formulated for acoustic applications by one of the UK's leading specialist foam manufacturers. It has been used for many years as the basic sound absorption foam due to its excellent performance for a wide range of applications. It may be used for acoustic enclosures, studio wall panelling, air handling units (AHU's), air conducting, cab linings and just about any other application where a controlled acoustic sound level is required
CNC Profile Cut Open Cell Melamine Treated Grey Acoustic Foam, 25kg / m3 Density Foam which has a controlled permeability and open cell structure that gives optimum acoustic performance for a foam of this density. Hardness 125 to 155 Newton's, Please note all polyurethane foam will react to UV light and can fade and yellow over time this however will in no way affect the foams sound absorption performance.
Sound dampening for small sized areas like vocal sound booths help prevent echo and improve acoustics and give a more pure sound response. This tile is also ideal for home recording studio applications, home cinemas, server rooms etc. Features • Tiles are sold in packs of 20
• 3.61 square metres (38.58 square feet) per pack
• Tile size 425mm x 425mm x 75mm (16.73 x 16.73 x 3 inches)
• Coverage 1.9sq ft per tile
• Can be attached with spray adhesive, evo stick contact or evo stick impact adhesives
• Below is the Foams Random Incidence Sound Absorption for a flat piece of foam cut at 25mm thick (Typical Results) Frequency (Hz) to Relative Absorption Coefficient
125Hz - 0.06
250Hz - 0.12
500Hz - 0.33
1000Hz - 0.6
2000Hz - 0.72
4000Hz - 0.97
The acoustic foam grade we use is specifically formulated for acoustic applications by one of the UK's leading specialist foam manufacturers. It has been used for many years as the basic sound absorption foam due to its excellent performance for a wide range of applications. It may be used for acoustic enclosures, studio wall panelling, air handling units (AHU's), air conducting, cab linings and just about any other application where a controlled acoustic sound level is required
CNC Profile Cut Open Cell Melamine Treated Grey Acoustic Foam, 25kg / m3 Density Foam which has a controlled permeability and open cell structure that gives optimum acoustic performance for a foam of this density. Hardness 125 to 155 Newton's, Please note all polyurethane foam will react to UV light and can fade and yellow over time this however will in no way affect the foams sound absorption performance.
Sound dampening for small sized areas like vocal sound booths help prevent echo and improve acoustics and give a more pure sound response. This tile is also ideal for home recording studio applications, home cinemas, server rooms etc. Features • Tiles are sold in packs of 20
• 3.61 square metres (38.58 square feet) per pack
• Tile size 425mm x 425mm x 75mm (16.73 x 16.73 x 3 inches)
• Coverage 1.9sq ft per tile
• Can be attached with spray adhesive, evo stick contact or evo stick impact adhesives
• Below is the Foams Random Incidence Sound Absorption for a flat piece of foam cut at 25mm thick (Typical Results) Frequency (Hz) to Relative Absorption Coefficient
125Hz - 0.06
250Hz - 0.12
500Hz - 0.33
1000Hz - 0.6
2000Hz - 0.72
4000Hz - 0.97
20 x Scan S-WDG75 Acoustic Foam Wedge Tiles
![20 x Scan S-WDG75 Acoustic Foam Wedge Tiles]()
