SYSTEM

Scan 3XS Ultimate 3D Workstation, 2x Intel Xeon, 64GB DDR4, Quadro P5000

Scan 3XS Ultimate 3D, 2x Intel Xeon E5 2640 v4, 64GB ECC DDR4, 16GB Quadro P5000, 256GB SSD, 2TB HDD, Win 10 Pro

Scan
Scan code: LN75704 Manufacturer code: 3XSULTIMATE3D Request call
£5,449.99
In stock
Buy Now, Pay Later with a 10% deposit. Or spread the cost of your finance over 24-48 months.
3xs Approved High End
Delivery options £11.50 By DPD On 5th Dec 2016 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout

SCAN 3XS ULTIMATE 3D

The Ultimate 3D marks a giant leap forward in performance thanks to having two 10-core Intel Xeon E5 2640 v4 CPUs which support Hyper-Threading and run at 2.4GHz. These CPUs are partnered with a high performance 16GB NVIDIA Quadro P5000 professional graphics card and 64GB of 2133MHz ECC Registered DDR4, all connected via a Supermicro X10DAI motherboard. The Ultimate 3D also includes a 256GB Samsung 850 Pro SSD and 2TB HDD as standard.

The system is pre-installed with Windows 10 Pro and is backed by our 3 Year Premium Warranty and is ready for next-day delivery.

3D Workstation
This graphics workstation is designed for 3D modelling, basic animation, texturing and rendering such as 3DS Max, Cinema 4D, Creative Cloud and SolidWorks.

THE BEST GRAPHICS WORKSTATIONS

Unlike in the consumer world, the manufacturers of workstation-class components such as NVIDIA engineer and optimise its Quadro graphics cards for specific applications. This guide will help you by suggesting which graphics card will provide you with the optimum performance.

NVIDIA Quadro Card Cores Frame Buffer Best For
K420 192 2GB Entry-Level 2D Graphics
K620 384 2GB Mid-Range 2D & Entry-Level 3D Graphics
K1200 512 4GB High-End 2D & Mid-Range 3D Graphics
M2000 768 4GB High-End 2D & Mid-Range 3D Graphics
M4000 1664 8GB High-End 3D
P5000 2560 16GB Very High-End 3D
P6000 3840 24GB Ultra High-End 3D & Simulations

DETAILED SPECIFICATIONS

Component Description
Chassis Fractal Design Define XL Full-Tower
Motherboard Supermicro X10DAI
Processor 2x Intel Xeon E5 2640 v4 10 core with HyperThreading 2.4GHz
CPU Cooler 2x Corsair H80i
Memory 64GB ECC Registered 2133MHz DDR4
Graphics Card 16GB NVIDIA Quadro P5000
Power Supply Corsair 1000RMi - 80PLUS GOLD
System Drive 256GB Samsung 850 Pro SSD
Storage Drive 2TB Seagate Barracuda HDD
Optical Drive Samsung DVD-RW
Operating System Microsoft Windows 10 Professional 64bit
Recovery Media Recovery USB drive with system image and diagnostic software
Warranty 3 Year Premium Warranty - 1st Year Onsite, 2nd & 3rd Year Return to Base (inc Parts & Labour)

WHY BUY BUILT?

Professionally Built PCs vs Self-Built

Anyone can build a PC, so what really makes the difference between any old PC and a 3XS PC? For starters, our team has been designing and building PCs for more than 20 years, so we have a huge amount of experience in building highly reliable systems that deliver the most performance for your budget. These are the benefits you receive when buying a professionally built 3XS system versus building a system yourself.

NO COMPATIBILITY HEADACHES

It can take weeks to research the right combination of components, not just to ensure you get the most bang for your buck but to minimise the chance of one component being incompatible with another. Whether you buy a system from our configurator or a custom spec system our engineers will do all this hard work for you, ensuring that when your system is delivered it performs flawlessly.

INTENSIVELY TESTED

Building a PC only takes a few hours, but installing all the software and making sure that everything is configured properly and that your software runs stably takes up a huge amount of time. By ordering a 3XS system our engineers take this painful process away, as all our systems undergo a strenuous Quality Control procedure which includes updating Windows, installing the latest drivers and motherboard BIOS. Overclocked systems receive an additional 24 hour burn-in test to ensure stability.

PEACE OF MIND

Unfortunately PC components do occasionally fail, and when this happens if you’ve built your PC yourself you’re on your own. However, with a professionally built Scan 3XS system you’re no longer alone. Our technical support team is available 7 days a week, from 9am to 10pm Mon - Fri, 10am to 6pm on Saturdays and 10am to 4pm on Sundays. Click here for more info on how to get technical support for your 3XS system.

If our support team is unable to fix your system remotely and it’s still under warranty we’ll either send out an engineer to visit your home or office or repair it or have it repaired in our state of the art factory in Lancashire.

A WORK OF ART

We don't just build PCs in our state-of-the-art factory, we craft them. For instance, we route and tidy all the cables around the sides of the case. This not only makes your PC look great and easier to upgrade in the future, but eases airflow through the case resulting in a cooler and quieter PC. In addition, we can customise your PC for you, not just the components inside but also its appearance, so if you fancy a PC in an unusual shape or colour we look forward to hearing from you.

WIDELY ACCLAIMED

Our 3XS PCs have won hundreds of awards in the press from publications such as Custom PC, Develop3D, Expert Reviews, HEXUS, PC Gamer and PC Pro. In addition 3XS has won Custom PC’s annual Dream PC competition every year it has run since 2007. You can read all our reviews here plus customer reviews on the configurator.

RAPID DELIVERY

Sometimes you just need a system right now. Maybe your existing system has kicked the bucket or you’ve found that your old workhorse can’t hope with the latest game or application you just bought. F-series systems are pre-built and tested in our factory, so can be collected same day or delivered next-day to your home or office.

WARRANTY & TECH SUPPORT

Another key difference is that all Scan 3XS Custom Series PCs are covered by our Premium 3 Year Warranty. This means that if your system develops a fault in its first year we can send an engineer to your home or office to repair it. In the remaining two years of the warranty we'll still repair or replace any faulty parts, but do this from our state of the art factory in Lancashire. Click here for more info on how to get technical support for your 3XS system.

Specifications
Processor
CPU Type 2x Intel Xeon
CPU Model E5-2640 v4
Professionally Overclocked No
CPU Speed 2.4 GHz
CPU Boost/Turbo Speed 3.4 GHz
CPU Cores 10 Core
CPU Threads 20
CPU Cooler Dual (2) All-In-One Water Coolers
Motherboard
Motherboard Chipset Intel C612
Motherboard Form Factor E-ATX
RAM Memory
Memory 64GB (8x8GB)
Memory Type DDR4 ECC Registered
Memory Speed DDR4 - 2133
Storage Drives
SSD Boot Drive Installed Yes
SSD Boot Drive Type 2.5" SATA
SSD Boot Drive Capacity 256 GB
SSD Project Drive Installed No
SSD Project Drive Type N/A
SSD Project Drive Capacity N/A
SSHD Installed No
SSHD Capacity N/A
HDD Installed Yes
HDD Capacity 2000 GB
Monitor
Screen Size Monitor Not Included, Sold Separately
Screen Type *See Above*
Resolution *See Above*
Graphics
Graphics NVIDIA
Graphics Chipset Quadro P5000
SLi/CrossFire Multi GPU System No
GeForce GTX VR Ready No
GPU Cores/Streams 2560
GPU Core Clock
GPU Boost Clock
GPU Memory 16GB
GPU Memory Type GDDR5X
GPU Memory Clock
GPU Memory Bit Rate 256 Bit
Graphics Card Connectors
  • 4 x DisplayPort 1.4
  • 1 x DVI-D DL
I/O
Back Panel
  • 2 x 10/100/1000 (LAN)
  • 1 x 7.1 Audio I/O
  • 2 x USB 2.0
  • 4 x USB 3.0
Front / Side Panel
  • 1 x Headphone
  • 1 x Mic In
  • 2 x USB 2.0
  • 2 x USB 3.0
Other Specifications
Optical Drive DVD±RW
Keyboard & Mouse No
Webcam No
Wireless LAN No
Operating System Windows 10 Pro (64 bit)
Colour Black
PSU Wattage 1000 W
Case Form Factor Full Tower
Dimensions (Tower) 232 x 559 x 560 mm (WxHxD)
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
14 days
RTB Period:
36 months
Manufacturer Contact Details
Manufacturer:
Scan
Telephone:
0871 472 4747
