PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB

PowerColor Mini Pro 240FU eGPU Chassis, 40Gbps Thunderbolt 3, 8GB Radeon RX 570 GPU Included, 240W Power, GbE, USB 3.0

Thumbnail 1 : PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB Thumbnail 2 : PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB Thumbnail 3 : PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB Thumbnail 4 : PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB
Scan code: LN98103 Manufacturer code: PowerColor Mini Pro
£443.99
From £21.31 / month (APR 14.9%)
Monthly Payment: £77.05
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £443.99
Total inc. interest: £462.26
Monthly Payment: £39.86
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £443.99
Total inc. interest: £478.28
Monthly Payment: £27.49
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £443.99
Total inc. interest: £494.68
Monthly Payment: £21.31
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £443.99
Total inc. interest: £511.48
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 19.9% and may be even lower.

Representative Example:

Purchase Rate: 19.9% p.a. (variable)

Representative: 19.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £11.09 / month (APR 15.9%)
Delivery Options
  • By DPD On 22nd Oct 2019 to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview Thunderbolt™ 3 External Graphics (eGFX) Box
PowerColor Mini Pro eGFX box is powerful, portable and upgradable solutions to boost graphics performance and empower the demanding MacBook Pro, the new MacBook Air and Mac mini users.

High Speed Computing Mode
Leveraging the ultra-fast 40Gbps single-cable Thunderbolt™ 3 connection, PowerColor Mini Pro eGFX solution offers easy plug-and-play connectivity for improving graphics performance of macOS computers.

• Thunderbolt3 connectivity.
• 40Gbps bandwidth.
• Included AMD Radeon RX 570 8GB graphics card.
• 240W supplied power.
• Gigabit Ethernet.
• 2x USB 3.0 Type-A ports.
• 68 x 153 x 215mm chassis dimensions.

Smallest PCIe eGFX
Compact & light design of PowerColor Mini Pro provides better working environment. The portable design definitely makes your life much easier.

Includes Radeon RX 570 Graphics Card
PowerColor Mini Pro features Radeon RX 570 with 8 GB of memory, Gigabit Ethernet port, latest GCN 4 architecture designed for GloFo 14nm FinFET that delivers premium VR capability, increased level of performance, smooth VR, seamless support for next-gen gaming monitors and CPU-free game streaming or recording.

External Adapter
PowerColor Mini Pro adopts an external power adapter which efficiently reduces the noises comparing with standard PSU. Moreover, by using external power adapter, you will be more comfortable when there is no heat from it.

TB3 port in front bezel & 2 x USB-A
• The front design of Thunderbolt port is more user friendly and easy to plug when it connects with your Macbook.
• PowerColor Mini Pro equips with 2 x USB-A 3.0 which provides more possibilities to you to connect with keyboard, mouse, HDD, or other devices.

Gigabit LAN
Gigabit Ethernet provides more stable & faster internet connection.

More Speed, More Pixels, More Possibilities
Thunderbolt™ 3 brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all - delivering the fastest, most versatile connection to any dock, display, or data device.

More Speed
• 40Gbps Thunderbolt™ 3
• Four lanes of PCI Express Gen 3
• Two streams (eight lanes) of DisplayPort 1.2
• Integrated USB 10Gbps host controller
• Four times the data and twice the video bandwidth of any other cable

Plug Your Ways
Not only is it an eGPU box, the many provided I/O ports make it multifunctional.
• External Adapter.
• Thunderbolt™ 3 (Type C).
• 2x USB 3.0 (Type A).
• Gigabit Ethernet (RJ–45). Features

I/O ports: 1 x Thunderbolt 3 (USB-C) port Upstream, 2 x USB 3.0 Type A, 1 x Gigabit Ethernet, 1 x DC-in
External Power Adapter: 240 Watts
Chassis Size: 215 x 153 x 68 mm
Operating System Requirements: macOS 10.13.4 or above

Graphics Engine: AMD Radeon RX 570
Process technology: Fin FET 14 nm
Engine Clock (max): up to 1244 MHz
Graphics Memory: 256-bit, 8GB, GDDR5
Memory Clock (max): 1750 MHz / 7.0 Gbps
Bus Interface: PCI Express 3.0 (x16)
Shader Processing Units: 2048 Shaders
Floating Point Performance: 5.1 TFLOPs
DirectX Capability: DirectX 12
OpenGL: OpenGL 4.5
OpenCL: OpenCL 2.0
VULKAN: VULKAN Support
Unified Video Decoder (UVD): UVD 6.3 for H.265/HEVC, 4K H.264, VC-1, MPEG-2, MPEG-4 part 2 decode
Display Interface: 2 x DisplayPort, 2 x HDMI, 1 x DL DVI-D
Maximum Resolution: DisplayPort: 3840 x 2160; HDMI: 3840 x 2160; DL DVI-D: 2560 x 1600
Power Consumption: 150W
Operating Temperature: 0 ~ 45 celsius degree
Dimension: 175 x 111 mm
Specifications
Edition Mini Pro 240F
System-Enclosure Interface Thunderbolt™ 3
Graphics Card Interface PCIe 3.0 x16 Slot
Graphics Card Included Yes
Graphics Card Edition Radeon RX 570 8GB
Graphics Card Chipset Radeon RX 570
Built-In I/O Connectivity
  • 1 x DC Power-In
  • 1 x Gigabit Ethernet (RJ45)
  • 1 x Thunderbolt 3 (USB-C) (for Connection to System)
  • 2 x USB 3.0 Type-A
Included Cooling Fans
Lighting No
Lighting Type
Compatible Graphics Card Chipsets
Supported GPU Type
Max. Internal Dimesions Available for GPU
Compatible Operating Systems
Power Supply Included Yes
PSU Form-Factor External
PSU Wattage 240 W
80+ Certification
Max. Power Available for GPU
Max. Combined Power Available for Peripherals
Laptop Charging Support No
Max. Laptop Power Delivery
Data Cable Length
Colour Black
Materials
Includes
  • External GPU Enclosure
  • Graphics Card
  • Thunderbolt™ 3 Cable
Dimensions 68 x 153 x 215 mm (WxHxD)
Weight
Note
Additional Information
Scan Code LN98103
Model Number PowerColor Mini Pro
GTIN 713436171416
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
24 months
Manufacturer Contact Details
Manufacturer:
Scan
Telephone:
0871-472-4747
Loading Please Wait

Please wait . . .

Reviews
Questions & Answers

Is this compatible/benfitial for iMacs?

I have a 21.5" late 2015 2.8GHz Intel Corei5 and a 27" 2017 4.2 GHz Intel Core i7, thanks
Asked by: StudioGuy
Good Afternoon, Yes, this should work fine for you. The below is taken from the product page: "Leveraging the ultra-fast 40Gbps single-cable Thunderbolt™ 3 connection, PowerColor Mini Pro eGFX solution offers easy plug-and-play connectivity for improving graphics performance of macOS computers." Kind Regards,
Answered by: LukeW
Date published: 2019-07-29
