PowerColor Mini Pro 240FU eGFX Thunderbolt 3 Enclosure with RX 570 8GB

Product Overview Thunderbolt™ 3 External Graphics (eGFX) Box
PowerColor Mini Pro eGFX box is powerful, portable and upgradable solutions to boost graphics performance and empower the demanding MacBook Pro, the new MacBook Air and Mac mini users.

High Speed Computing Mode
Leveraging the ultra-fast 40Gbps single-cable Thunderbolt™ 3 connection, PowerColor Mini Pro eGFX solution offers easy plug-and-play connectivity for improving graphics performance of macOS computers.

• Thunderbolt3 connectivity.
• 40Gbps bandwidth.
• Included AMD Radeon RX 570 8GB graphics card.
• 240W supplied power.
• Gigabit Ethernet.
• 2x USB 3.0 Type-A ports.
• 68 x 153 x 215mm chassis dimensions.

Smallest PCIe eGFX
Compact & light design of PowerColor Mini Pro provides better working environment. The portable design definitely makes your life much easier.

Includes Radeon RX 570 Graphics Card
PowerColor Mini Pro features Radeon RX 570 with 8 GB of memory, Gigabit Ethernet port, latest GCN 4 architecture designed for GloFo 14nm FinFET that delivers premium VR capability, increased level of performance, smooth VR, seamless support for next-gen gaming monitors and CPU-free game streaming or recording.

External Adapter
PowerColor Mini Pro adopts an external power adapter which efficiently reduces the noises comparing with standard PSU. Moreover, by using external power adapter, you will be more comfortable when there is no heat from it.

TB3 port in front bezel & 2 x USB-A
• The front design of Thunderbolt port is more user friendly and easy to plug when it connects with your Macbook.
• PowerColor Mini Pro equips with 2 x USB-A 3.0 which provides more possibilities to you to connect with keyboard, mouse, HDD, or other devices.

Gigabit LAN
Gigabit Ethernet provides more stable & faster internet connection.

More Speed, More Pixels, More Possibilities
Thunderbolt™ 3 brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all - delivering the fastest, most versatile connection to any dock, display, or data device.

More Speed
• 40Gbps Thunderbolt™ 3
• Four lanes of PCI Express Gen 3
• Two streams (eight lanes) of DisplayPort 1.2
• Integrated USB 10Gbps host controller
• Four times the data and twice the video bandwidth of any other cable

Plug Your Ways
Not only is it an eGPU box, the many provided I/O ports make it multifunctional.
• External Adapter.
• Thunderbolt™ 3 (Type C).
• 2x USB 3.0 (Type A).
• Gigabit Ethernet (RJ–45). Features

I/O ports: 1 x Thunderbolt 3 (USB-C) port Upstream, 2 x USB 3.0 Type A, 1 x Gigabit Ethernet, 1 x DC-in
External Power Adapter: 240 Watts
Chassis Size: 215 x 153 x 68 mm
Operating System Requirements: macOS 10.13.4 or above

Graphics Engine: AMD Radeon RX 570
Process technology: Fin FET 14 nm
Engine Clock (max): up to 1244 MHz
Graphics Memory: 256-bit, 8GB, GDDR5
Memory Clock (max): 1750 MHz / 7.0 Gbps
Bus Interface: PCI Express 3.0 (x16)
Shader Processing Units: 2048 Shaders
Floating Point Performance: 5.1 TFLOPs
DirectX Capability: DirectX 12
OpenGL: OpenGL 4.5
OpenCL: OpenCL 2.0
VULKAN: VULKAN Support
Unified Video Decoder (UVD): UVD 6.3 for H.265/HEVC, 4K H.264, VC-1, MPEG-2, MPEG-4 part 2 decode
Display Interface: 2 x DisplayPort, 2 x HDMI, 1 x DL DVI-D
Maximum Resolution: DisplayPort: 3840 x 2160; HDMI: 3840 x 2160; DL DVI-D: 2560 x 1600
Power Consumption: 150W
Operating Temperature: 0 ~ 45 celsius degree
Dimension: 175 x 111 mm
