ASRock Intel Z690 Phantom Gaming-ITX/TB4 PCIe 5.0 Mini-ITX Motherboard

Open box ASRock Z690 Phantom Gaming-ITX/TB4, Intel Z690, S 1700, DDR5, PCIe 5.0, SATA3, M.2, 2.5GbE,ax WiFi/BT,Mini-ITX

Thumbnail 1 : ASRock Intel Z690 Phantom Gaming-ITX/TB4 PCIe 5.0 Mini-ITX Motherboard
ASRock Intel Z690 Phantom Gaming-ITX/TB4 PCIe 5.0 Mini-ITX Motherboard : image 1
Scan code: LN127766 Manufacturer code: Z690 Phantom Gaming-ITX/TB4 DDR5
End Of Life This product is no longer available to purchase
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview

SPS (Smart Power Stage)

Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability.


11 Power Phase Design

Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.


10 Layer PCB

The 10 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency for memory overclocking! Thus, it's able to support the latest memory modules with most extreme memory performance!


PCIe 5.0 + Surface-Mount Tech

Compares to conventional DIP style PCIe slot, the SMT type PCIe slot improves signal flow and maximize stability under high speed, a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard. The latest PCI Express 5.0 is capable to perform a breathtaking bandwidth of 128GBps, ready to unleash the full potential of future high-end graphic cards.


Reinforced DIMM Slot

The reinforced DIMM slot is surfaced mounted onto the motherboard to give better physical strength as well as a more stable memory signal, with this superior revolutionary design, it is able to dramatically overclock DRAM module up to insane frequency.


DIY Friendly Design

Due to the unique electrical architecture of DDR5 DIMM, there’s a high risk of damaging the memory module if AC power isn’t disconnected properly during removal or installation. To prevent this, ASRock has implemented a trouble-free protection circuit on every DDR5 motherboard, lowers the risk of damaging your memory module.


High Speed M.2 Solution

This motherboard is capable of accommodating multiple M.2 storage devices, one of which can support PCI Express 4.0 M.2 SSD, it is capable of performing twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.


Killer E3100 + AX1675

The Killer Ethernet controller is designed specifically for competitive gamers and performance-hungry users, this motherboard comes with both Killer E3100 2.5G Ethernet & WiFi 6E solution, the enhanced detection and prioritization engine provides the ultimate networking experience for gaming and multimedia applications.


Killer DoubleShot Pro

Killer DoubleShot Pro allows the use of both the Killer Wireless and Killer Ethernet interfaces work at the same time which will give the end user max throughput as high as 4.9 Gbps, it automatically utilizes the fastest network connection for high priority traffic, this ensures the highest priority traffic will always be put on the fastest and most reliable link.


Thunderbolt 4/USB 4 Type-C

Thunderbolt™ 4/USB 4 technology brings speed and versatility to the most advanced USB Type-C, offering a fast and simple level of connection for work or home. It enables lightning-fast data transfer up to 40Gbps and connects external monitors, Thunderbolt™, and USB devices with a single Thunderbolt 4 cable.


Fast Charging Technology

Enjoy the superfast charging rate, up to [email protected] 27W with the next generation PD 3.0!


Nahimic Audio

Whether you are using headphones, a headset, external or internal speakers, via USB, Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant and rich with details.


POLYCHROME RGB

This motherboard features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.


Front USB 3.2 Gen2x2 Type-C

The latest USB 3.2 Gen2x2 Type-C delivers up to 20 Gbps data transfer rate which is 2x as fast as previous generation, providing a blazing fast data transfer interface with reversible USB Type-C design that fits the connector either way.


USB 3.2 Gen2

This motherboard has four onboard Type-A USB 3.2 Gen2 ports built on the rear i/o for supporting next generation USB 3.2 Gen2 devices and to deliver up to 10 Gbps data transfer rates.


Auto Driver Installer

No need to worry about lack of disk drive! ASRock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.


BIOS Flashback

Get the most convenient BIOS flashing with just a simple click. Users can easily achieve the latest BIOS support with a USB and power supply, No CPU, RAM or other components required.


Flexible Integrated I/O Shield

Unlike most so called pre-mounted I/O shield that is only decorated with fancy color schemes. We reserve more tolerance space and allow IO shield is adjustable when installing, thus fitting chassis perfectly without any mechanical issue.

Features
• Supports 12th Gen Intel® Core™ Processors (LGA1700).
• 11 Phase SPS Dr.MOS Power Design.
• Supports DDR5 6400MHz (OC).
• 1 PCIe 5.0 x16.
• Graphics Output Options: HDMI, DisplayPort.
• Thunderbolt™ Type-C.
• Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio.
• 3 SATA3.
• 1 Hyper M.2 (PCIe Gen4 x4).
• 1 Hyper M.2 (PCIe Gen4 x4 & SATA3).
• Thunderbolt™ 4/USB4 Type-C.
• 1 USB 3.2 Gen2x2 Front Type-C.
• 4 Rear USB 3.2 Gen2 Type-A.
• 3 USB 3.2 Gen1 (1 Rear, 2 Front).
• Killer E3100 2.5G LAN.
• Killer AX1675 802.11ax (WiFi 6E) + Bluetooth.
