MSI A68HM GRENADE FM2+ Godavari Micro-ATX Motherboard

MSI A68HM GRENADE, AMD A68H, FM2+ Godavari, DDR3, SATA III 6Gb/s, RAID, PCIe 3.0 (x16), D-Sub/DVI-D/HDMI, MATX

MSI
Scan code: LN64873 Manufacturer code: A68HM GRENADE Request call
£46.99Item due today
Pre order
Spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
3xs Approved High End
Delivery options £5.48 By DPD DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Product Overview Military Class 4
Military Class 4 is the next step in high quality components. The Dark Choke and Solid CAP will make sure that your PC runs more stable under extreme gaming conditions.

• Dark Choke
Dark Choke uses the special core design and allows the Dark Choke to run at a lower temperature with higher capacity and better power efficiency and stability.

• SOLID CAP
With their aluminum core design and Japanese made quality, Solid CAPs are made for high-end design motherboard. Not only do Solid CAPs could provide lower Equivalent Series Resistance (ESR), but also work firmly for over-10-year.

Military Class essentials
The core of Military Class 4 is based on the essentials which increase your stability in the worst conditions. The humidity protection and high temperature protection ensure your system surviving each environment, no matter how harsh. The new structure of the PCB limits EMI radiation. On top of that all the connectors have ESD protection in order to prevent short circuit.

• Humidity Protection
The latest Gen 4 Fabric PCB helps to against moisture cause by some humid conditions and environments.


• EMI Protection
The optimized EMI-proof design helps to keep users safe when during a long-time computer operation.


• ESD Protection
Anti-ESD ICs and fuses onboard helps to totally protect your motherboard from electrostatic damage.


• HIGH Temperature Protection
Certificated Military Class 4 components help to work stable under some extreme conditions.


Click BIOS 4
The MSI Click BIOS 4 is the latest UEFI BIOS with optimizations for Windows 8.1. Not only that it also reacts faster, runs smoother and has better mouse support. And this all comes with many cool features. Click on the button on the right to visit our dedicated BIOS page and learn more. Features LIVE UPDATE 6
MSI Live Update is renewed! Our popular software automatically downloads and installs the latest drivers, BIOS and software. Rest assured while your system is always configured using the latest software so you get the maximum performance and stability.

FAST BOOT
No more seamless waiting for your O/S to be loaded! MSI Fast Boot helps to make your system boot lightning fast. MSI Fast Boot also features a GO2BIOS button. Simply click it to restart your PC and go straight to the system BIOS.

M-Flash
Compared to common motherboards which need extra BIOS chips, MSI's M-Flash has a double advantage which doesn't need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover, it can also be seen as a portable BIOS chip which is actually able to boot up your PC.

• Backup/Restore Your BIOS to/from Any USB Flash Disk
• Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process
• Earn more BIOS Lifespan by Reducing Unnecessary Rewriting Process

USB 3.0
Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gb/s offers 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute.

• 10X Faster Than USB 2.0
• Up to 5Gb/s Data Transfer Bandwidth
• Boost Transfer Rate Between Your PC and External Storage Devices

SATA 6Gb/s
SATA 6Gb/s provides double the bandwidth of traditional SATA 3Gb/s, and increases the data transfer rate between your motherboard and internal storage devices, such as 7200RPM HDDs, 10000RPM HDDs and SSDs. It's also the current trend for upcoming high-speed internal storage devices to break the existing bottleneck of a PC's performance.

• 2X Faster Than SATA 3Gb/s
• Up to 6Gb/s Data Transfer Bandwidth
• Unleash True Performance of New HDDs/SSDs

USB Safeguard
USB Safeguard can prevent motherboards and USB devices from being damaged by short-circuit and ESD (Electro-Static Discharge) with Anti-ESD chips built-into the motherboards. Additionally, the safeguard can protect against such dangers multiple times, and greatly improves product lifespan.

• All MSI motherboards use USB Safeguard’s anti-ESD chip for thorough protection against ESD damage
• USB Safeguard is protected against a short circuit and/or ESD without the need for a fuse. It also supports stand-by power supply

AMD Cool'n'Quiet
AMD Cool'n'Quiet™ Technology reduces heat and noise so you can experience amazing performance without distraction. Combined with core enhancements, included in the AMD processors, that can improve overall power savings, deliver better multitasking and energy efficiency. Cool'n'Quiet technology can automatically adjust processor ratio to throttle CPU speed with four modes.

• Independent Dynamic Core Technology
• Dual Dynamic Power Management™
• AMD CoolCore™ Technology
• AMD Wideband Frequency Control
• Multi-Point Thermal Control

HDMI
Enjoy the awesome HD video playback now! MSI motherboards that equip with HDMI port(s) supports the latest and the most innovative signal outputs to provide an unprecedented visual experience.
Specifications
Core Specifications
Form Factor MicroATX
CPU Socket FM2+
Chipset AMD A68H
RAM Memory Support
Memory Type DDR3
Memory Channel Dual (2)
Memory Type (ECC) Non-ECC
Memory Type (R/U) UDIMM (Unbuffered)
Memory Speed (Mhz)
  • DDR3 - 1333
  • DDR3 - 1600
  • DDR3 - 1866
  • DDR3 - 2133(OC)
Max. Memory Capacity 32GB
Audio
Audio
Graphics Support
Primary GPU Interface PCIe 3.0 (x16)
SLI Support N/A
Crossfire Support N/A
On-Board Graphics Connectors
  • D-Sub (VGA)
  • DVI-D
  • HDMI
Internal Connectivity
Expansion Slots
  • 1 x PCI
  • 1 x PCIe 2.0 x1
  • 1 x PCIe 3.0 x16
SATA Support SATA3
RAID Support via SATA
Storage Mode Support
Internal I/O
  • 1 x 24-pin (Power)
  • 1 x 4-pin (Power)
  • 2 x 4-pin Fan
  • 1 x Chassis Intrusion connector
  • 1 x Clear CMOS jumper
  • 1 x Front Panel Connector
  • 4 x SATA III - 6Gb/s
  • 1 x Serial (COM) Header
  • 2 x System panel connector
  • 1 x TPM Header
  • 2 x USB 2.0 Header
  • 1 x USB 3.0 Header
External Connectivity
Network Interface Type
Network Chip/Modules
Rear I/O Connectors
  • 1 x 10/100/1000 (LAN)
  • 1 x D-Sub (VGA) Out
  • 1 x DVI-D
  • 1 x HDMI
  • 1 x Line In
  • 1 x Line Out
  • 1 x Mic-In
  • 1 x PS/2 Keyboard
  • 1 x PS/2 Mouse
  • 4 x USB 2.0
  • 2 x USB 3.0
Other Motherboard Specifications
Water Cooled No
QPI Speed N/A
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
36 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
36 months
Manufacturer Contact Details
Manufacturer:
Scan
Telephone:
0871 472 4747
Customers also bought
Reviews
MSI A68HM GRENADE, AMD A68H, FM2+ Godavari, DDR3, SATA III 6Gb/s, RAID, PCIe 3.0 (x16), D-Sub/DVI-D/HDMI, MATX is rated 5.0 out of 5 by 1.
Rated 5 out of 5 by from Good solid board ordered around 15 of these boards, all have worked really well and overclocking was done within about 10seconds, been overclocking the a8 7650k to 4.2ghz, always stable, so really pleased.
Date published: 2015-10-08
