Scan code: LN108023 Manufacturer code: 53023

One-channel 3G SDI encoder

Magewell Ultra stream SDI

Thumbnail 1 : One-channel 3G SDI encoder Thumbnail 2 : One-channel 3G SDI encoder Thumbnail 3 : One-channel 3G SDI encoder
Scan code: LN108023 Manufacturer code: 53023
£438.49Item currently awaiting an ETA
Pre order
From £20.13 / month (APR 9.9%) or 0% for 4 months
Monthly Payment: £38.45
Instalment Rate: 9.9% p.a. (fixed)
Cost of purchase: £438.49
Total inc. interest: £461.32
Monthly Payment: £20.13
Instalment Rate: 9.9% p.a. (fixed)
Cost of purchase: £438.49
Total inc. interest: £483.09
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £10.95 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Single-Channel HD Streaming Encoder
Magewell - 'Ultra Stream SDI'

Magewell Ultrastream HDMI

MAKING LIVE STREAMING REMARKABLY EASY FOR EVERYONE Magewell Ultra Stream SDI is a Single-Channel HD Streaming Encoder that makes live streaming remarkably easy for everyone! Supports up to 2K60p 3G-SDI input and loop-through with embedded and analogue audio.

Magewell Ultra Stream SDI encoder enable users to record or stream high-quality video with one click using on-device buttons or an intuitive smartphone app. Customers can stream live to popular services such as YouTube, Facebook Live and Twitch or to a custom-specified RTMP server, and can simultaneously record video as files to a USB drive or the associated smartphone.

Key Features • Stand-alone device; no computer needed
• Control via on-device buttons or intuitive Android/iPhone smartphone app
• Ultra Stream SDI standalone Encoder, encode and stream at up to 1080p60
• LED indicators display status

Wired & Wireless


full control from anywhere via vpnA new web interface, enabling users to control Ultra Stream encoders through a web browser. While the smartphone app continues to provide the simplest way to locally manage the device, the browser-based interface enables customers to remotely control the encoder from anywhere via VPN or access it from a desktop computer over wired Ethernet.

Multi-level user management in the web interface allows access to administrator functions to be restricted to authorized users.

Developers wishing to integrate control of Ultra Stream SDI standalone encoder into their software applications also gain important new capabilities, with an API enabling them to leverage the devices’ robust functionality in their own branded interface.

The Tech Spec

Specification Description
Supported Mobile Clients Android • Android 5.0 and above iOS • iOS 9.0 and above iPhone • iPhone 5s • iPhone SE • iPhone 6 / iPhone 6s / iPhone 6 Plus / iPhone 6s Plus • iPhone 7 / iPhone 7 Plus • iPhone 8 / iPhone 8 Plus • iPhone X iPod Touch • iPod Touch 5 • iPod Touch 6
Supported Web Browser Microsoft Internet Explorer 11 Microsoft Edge Mozilla Firefox version 61 and above Google Chrome version 49 and above Apple Safari 11.1 and above Opera 55.0.2994.44 and above
Input Interfaces BNC • SD/HD/3G SDI 3.5mm audio jack • Microphone interface
Output Interfaces BNC • SD/HD/3G SDI USB • USB 2.0 3.5mm audio jack • Headphone interface
Network Interfaces Wired Ethernet •10/100/1000Mbps Ethernet Wi-Fi •IEEE 802.11 a/b/g/n/ac USB •USB 3G/4G Modem (not included)
Bluetooth Bluetooth 4.0 BLE
SDI Specific Features Support for SD/HD/3Ga/3Gb/3Ga-DL/3Gb-DS standards Support for 2K (2048x1080) input and loopthrough signals Support for 8/10/12-bit color depths Support for 60p, 60i, 50p, 50i, 30p, 25p signal formats Limited support for the first stream of 3Gb-DS Limited support for the first link of dual link interfaces • YCbCr 4:2:2 10-bit 1080p 50/59.94/60: output as 1080i 50/59.94/60 • YCbCr 4:4:4 10-bit: output as 4:2:2 • RGB 4:4:4: R/B sub-sampled
Analog Audio Features Extraction of stereo embedded SDI audio for recording and output via 3.5mm stereo mini-jack Line Out Recording and streaming analog audio via 3.5 mm microphone interface
Streaming Features Support for live streaming using RTMP protocol to software including Flash Media Server, Wowza, Red5 and Nginx server Streaming to Facebook, Twitch and YouTube platforms Support for streaming to 2 servers simultaneously
Recording Features (to USB Flash Drive) Support for H.264/HEVC (video) and AAC High Quality (audio) encoding Supports recording at input signal resolution up to 2048x1080 Support for 1920x1080, 1600x1200, 1440x1080, 1440x900, 1280x1024, 1280x960, 1280x800, 1280x720, 1200x900, 1024x768, 960x540, 800x600, 768x576, 720x576, 720x480, 640x480, 640x360, 480x360 resolutions Support for 60fps, 50fps, 30fps, 25fps, 24fps, 15fps frame rates Support for recording as MP4 files USB Flash Drive file system format: FAT32, NTFS, exFAT, VFAT
Recording Features (to Mobile Device) Support for recording at up to 1280x720, 30fps Support for recording as MP4 files Take still image snapshots during recording Save recording files and screenshots to system album Input signal previewing Timer recording: 15s, 30s, 1min, 2min, 5min
