Kiloview E1 HD/3G-SDI Wired Video Encoder

Kiloview E1 HD/3G-SDI Live Video Encoder, H.264, 1x SDI Input, 1x SDI Loop Out, 1080p60, MicroSD, USB 2.0
MORE INFO
MORE INFO

Scan code: LN113516 Manufacturer code: E1-S
£400.99
Item currently awaiting an ETA
Pre Order
Pre order
  • By DPD Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
  • Collect instore Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE) | Free
  • From £19.58 / month (APR 16.9%) or 0% for 4 months
    Monthly Payment: £36.33
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £400.99
    Total inc. interest: £435.92
    Monthly Payment: £19.58
    Instalment Rate: 16.9% p.a. (fixed)
    Cost of purchase: £400.99
    Total inc. interest: £469.89
    Example
    Minimum Spend: £99
    Instalment Rate: N/A
    Cost of purchase: £99
    Total inc. interest: £99
    If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

    Representative Example:

    Purchase Rate: 23.9% p.a. (variable)

    Representative: 23.9% APR (variable)

    Assumed Credit Limit: £1,200

    Subject to status. Terms and Conditions apply.
  • With a 10% deposit from just £10.66 / month (APR 19.9%)
  • SCANPROTECT Protect against installation damage for 28 days. More info

Kiloview - 'E1 H.264 HD SDI to IP Wired Video Encoder'

Kiloview E1 H.264 HD SDI to IP Wired Video Encoder

Professional Live Video EncodingKiloview E1 H.264 live video encoder delivers H.264 SDI video to various platforms like live broadcasts, Youtube Live, Facebook and live broadcast audio and video encoding for Ustream, Livestream, Twitch, Meridix, Streamspot, Dacast, and more. Applications of the SDI encoder include hotel TV system, school teaching, live broadcasting, church streaming.
E1 encoder has been approved by CE,FCC,ISO,etc.

Amazing Features

• H.264 Video Encoding
• Full Live platforms supported
• SDK provided

• Branded Chip
• SDI loop monitorin
• Low cost

• Low bandwidth transmission
• Voice Intercom
• SRT supported

The Tech Spec

Features Specification
Model E1
Video Input 1*BNC SDI
Video Loopout 1*BNC SDI
Analog Audio Input 1*3.5mm
Analog Audio Output 1*3.5mm
USB Interface 2*USB 2.0 Type-A; 1*USB 2.0 Mini-USB
Micro SD 1*Micro SD/TF Card storage interface
Video Resolution Up to 1080P60Hz, details as follows:
1080p23.98/24/25/29.97/30Hz
1080p50/59.94/60Hz
1080i50/59.94/60Hz
720p23.98/24/25/29.97/30Hz
720p50/59.94/60Hz, 576i, 480i
720*480(NTSC)，720*576(PAL)
Network Support RJ-45 Ethernet
Video Encoding H.264/ AVC High/ Main/ Baseline profile (up to Level 5.3) ; Motion-JPEG
Audio Encoding AAC/G.711
Encoding Latency ≤67ms
Media Transmission Protocols RTMP/SRT/HLS/TS over UDP/RTSP and so on
Management App/ Web
Power DC 12V 1A
Operating temperature -20℃ to 60℃
Dimension 4.9 x 3.5 x 1.125"/125 x 89 x 28mm
Weight 380g(13.4oz)
