Keith McMillen Instruments - K-Mix BLUE USB Audio Interface and Performance Mixer - Special Edition
Keith McMillen Instruments - K-Mix Blue, 8-in/10-out USB Audio Interface/Control Surface with 2 Microphone Preamps
- By DPD to your specified address. | Free Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout
- Collect instore Collect from our Bolton store, BL6 6PE | Free
- SCANPROTECT Protect against installation damage for 28 days. More info
8×10 Digital Mixer/USB Audio Interface
KMI - K Mix Blue

Programmable Digital Mixer, Audio Interface
and MIDI Control SurfaceMusicians, producers both new and veteran and performers alike in search of a small-form, all-in-one digital mixer/audio interface/MIDI controller could well see the end of their search with KMI’s K-Mix! A fully programmable digital mixer, also featuring an 8-input/10-outpuit 24-bit/96kHz audio interface and MIDI control surface.
The K-Mix boasts two precision low-noise uPre preamps offering up to 60dB of gain with both line and instrument level inputs on offer thanks to the combo jacks. Each of the K-Mix’s channels offers a 3-band semi-parametric EQ, broad dynamics including compression and gate, alongside a dedicated reverb. Furthermore, the K-mix boasts RIAA equalised phono inputs on channels 3-8, allowing for the connection of outside hardware such as turntables without the requirement for a phono preamp.
8 in/10 outChannels
24-bit/96kHzA/D Resolution
1 x 1/8"Headphones
at a glance
• Standalone Digital Mixer
• Low Noise, High Gain Micpre
• 24-Bit / 96 kHz Audio Interface
• Precision Opto-Tactile Control Surface
• LED Backlit Faders and Rotary Controls
• Fully Programmable MIDI Control Surface
Fully Programmable MIDI Outputs

no moving partsThe control surface is capable of accommodating up to 32 channels. Each and every fader, rotary encoder and button sports fully programmable MIDI outs.
The slim and tidy enclosure features zero moving parts, ensuring it’s a good choice for the travelling performer. K-Mix is fully USB powered and includes a 1A USB power supply, 6” USB cable and 3” micro-B USB cable.
Introducing K-Mix!

The Tech Spec
Features | Specification | Type | Digital Mixer with USB Interface |
---|---|
Channels | 8 in, 10 out |
Inputs - Mic Preamps | 2 x XLR-1/4" combo (mic/line/Hi-Z) |
Phantom Power | 2 Channels (1, 2) |
Inputs - Line | 6 x 1/4" TRS |
Outputs - Main | 2 x 1/4" TRS (main), 6 x 1/4" (aux) |
Busses/Groups | 4 x Stereo Bus (mains, aux 1/2/3) |
MIDI I/O | USB |
Headphones | 1 x 1/8" |
USB | 1 x Mini-B, 1 x Micro-B |
Computer Connectivity | USB |
Faders | 8 x 75mm LED Backlit Channel Fader Touch Strips, 1 x Master Fader Touch Strip |
A/D Resolution | 24-bit/96kHz |
EQ Bands | 3-band |
Effects | Master Reverb, Highpass Filter |
Signal Processing | Compressor/Limiter, Gate |
Features | Full Ableton Live 11 Control Surface Integration |
Transport Controls | Yes |
DAW Control | Yes |
Software | K-Mix Editor |
Power Source | USB bus power, 5V DC USB power supply (included) |
