Scan code: LN96720 Manufacturer code: BX80673W3175X

Intel 28 Core Xeon W-3175X Pro Creator Workstation CPU/Processor

Intel Xeon W-3175X, S 3647, Skylake-SP, 28 Cores, 56 Threads, 3.1GHz, 3.8GHz Turbo, 38.5MB Cache, 255W, Retail

Scan code: LN96720 Manufacturer code: BX80673W3175X
£2,739.98Item due on 04 April 2019
Pre order
From £131.52 / month (APR 14.9%)
Monthly Payment: £475.45
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,739.98
Total inc. interest: £2,852.70
Monthly Payment: £245.98
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,739.98
Total inc. interest: £2,951.70
Monthly Payment: £169.61
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,739.98
Total inc. interest: £3,052.93
Monthly Payment: £131.52
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £2,739.98
Total inc. interest: £3,156.33
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 17.9% and may be even lower.

Representative Example:

Purchase Rate: 17.9% p.a. (variable)

Representative: 17.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £68.43 / month (APR 15.9%)
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Product Overview Built for the Professional Creator: Introducing the Intel® Xeon® W-3175X Desktop Processor

Introducing the 28-core Intel® Xeon® W-3175X desktop processor!
When your work is on the line, you want a processor built for Creators to power your most demanding projects. Designed with 28 high-performance cores and 56 threads, the Intel® Xeon® W-3175X processor is in a class by itself.

3D Artists
When your art is your livelihood, don’t compromise on power. The new Intel Xeon W-3175X processor delivers optimised performance for today’s top tools.

Game Developers
Serious game design requires serious power. Build out your game with 28 high-performing cores, 56 threads, and Intel AVX-512 support for ray tracing and encoding.

Filmmakers and Editors
Make monster projects manageable with the most cores, most CPU PCIe lanes, and most memory capacity available on any Intel desktop processors.

Power Creation Platform
Need to edit, render and encode on a tight deadline? Need to use multiple input and output devices at the same time? Support you peripherals and high-speed tools with up to 68 platform PCIe lanes, 38.5MB of Intel Smart Cache, 6-Channel DDR4 memory support, ECC memory support, and standard RAS support.

Multi-Threaded Performance
The new Intel Xeon W-3175X processor features 28 high-performance cores and 56 threads, perfect for handling your most demanding multithreaded applications and tasks. When your application demands single-threaded performance, Intel Turbo Boost Technology 2.0 delivers frequencies up to 4.3GHz.

Looking for even more performance? The new Intel Xeon W-3175X processor is unlocked, and supports expert overclocking tools such as Intel Extreme Tuning Utility and Intel Extreme Memory Profile. When you need even more CPU and memory optimisation, the Intel Advanced Vector Extensions 512 (Intel AVX-512) ration offset and memory controller trim voltage control can give you more control.

The Creator Platform
The Intel C621 chipset paired with the Intel Xeon W-3175X processor provides power-user features designed for the enthusiast. Whether it is connectivity, expandability or performance you need, this platform has you covered:
• Integrated USB 3.0 controller with up to 10 ports makes moving files to your portable storage solutions with blazing fast speeds.
• Support for Gigabit network speeds with an integrated Gigabit Ethernet controller.
• Configure large storage arrays with support for Intel Virtual RAID on CPU (Intel VROC) and Intel Rapid Storage Technology with support for RAID configuration on PCI Express and Serial ATA storage devices.
With this workstation-class platform, the Intel C621 chipset and unlocked Intel Xeon W-3175X processor allows professional content creators to achieve a new level of performance. Features • Intel Turbo Boost Technology: Dynamically increases the processor’s frequency, as needed, by taking advantage of thermal and power headroom when operating below specified limit.
• Intel Hyper-Threading Technology: Delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
• Integrated Memory Controller: Supports up to 6-channel memory with 2 DIMM per channel. Support for the Intel Extreme Memory Profile (Intel XMP) specification, revision 2.0 for DDR4.
• Intel Smart Cache: Up to 38.5MB of shared cache allows fast access to your data by enabling dynamic and efficient allocation of the cache to match the needs of each core significantly reducing latency to frequently used data and improving performance.
• Overclocking Enabled: Fully unlocked core multipliers, power, and DDR4 memory ratios for amazing flexibility in setting frequencies above the specification frequency of the processor resulting in higher performance.
• Chipset/Motherboard Compatibility: Supported by the Intel C621 Chipset.
• Intel Advanced Encryption Standard New Instructions (Intel AES-NI): A set of instructions that can be used to accelerate a variety of encryption apps, including whole disk encryption, file storage encryption, conditional access of 4K UHD content, Internet security, and VoIP. Consumers benefit from internet and email content protection, plus fast, responsive disk encryption.
• Intel Virtualisation Technology: Allows one hardware platform to function as multiple “virtual“ platforms. Offers improved manageability by limiting downtime and helping maintain productivity by isolating computing activities into separate partitions.
• Intel Advanced Vector Extensions 512 (Intel AVX-512): A set 512-bit instructions to deliver enhanced performance on floating point- and integer-intensive apps. Includes instructions for FMA (Fused Multiply Add) which can deliver better performance on media and floating point computations, including face recognition, professional imaging, high-performance computing, consumer video and imaging, compression, and encryption.
• PCI Express 3.0 Interface: Offers up to 8GT/s for fast access to peripheral devices and networking with up to 48 lanes.
Model & Type
CPU Type Intel Xeon
CPU Model W-3175X
Socket 3647
Architecture Skylake-SP (Purley)
Manufacturing Process 14 nm
Cores & Clocks
No. of Cores 28 Core
No. of Threads 56
Core Ratio 31 x
Clock Speed 3.1 GHz
Turbo Speed 3.8 GHz
Max. Turbo Speed (On 2 Cores Only) N/A
Intel Turbo Boost Max Technology 3.0 No
Unlocked Core Multiplier Yes
Unlocked Full Range Base Clock (B-Clock) No
Bus Speeds
FSB Speed N/A
QPI Speed 8.0 GT/s
UPI Links/Speed N/A
DMI Speed 8 GT/s
Memory Support
Max. Memory Size 512 GB
Max. Memory Speed DDR4 - 2666
Max. Memory Channels 6 (Hex Channel)
ECC Memory Support Yes
Intel Optane Memory Support No
Lanes & Scalability
Scalability 1 Socket/Processor ONLY
Max. PCIe Lanes Supported 48
Integrated Graphics
Features Integrated Graphics No
Integrated Graphics Model/Type N/A
iGPU Cores
iGPU Base Clock N/A
iGPU Boost Clock N/A
iGPU Max. Resolution
CPU Cache
L1 Cache
L2 Cache
L3 Cache *See Intel Smart Cache*
Intel® Smart Cache 38.5MB
Thermals & Package
Max. TDP 255W
Thermal Specification 85 °C
Heatsink/Cooler Included? Not Included, Sold Separately
Package Type Retail
