Scan code: LN104930 Manufacturer code: CD8069504382000

Intel 12 Core i9 10920X Unlocked Cascade Lake-X CPU/Processor OEM

Intel Core i9 10920X, S 2066, Cascade Lake-X, 12 Cores, 24 Threads, 3.5GHz, 4.6GHz Turbo, 19.25MB Cache, 165W, OEM

Free Arctic MX-4 Enthusiast Thermal Paste (1.2g) - LN 105362
Scan code: LN104930 Manufacturer code: CD8069504382000
Order in the next 1 hr 16 mins and get it tomorrow
£623.99
Get it Tomorrow, 27 MayIn stock
From £18.92 / month (APR 5.9%) or 0% for 4 months
Monthly Payment: £53.64
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £623.99
Total inc. interest: £643.59
Monthly Payment: £27.59
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £623.99
Total inc. interest: £662.00
Monthly Payment: £18.92
Instalment Rate: 5.9% p.a. (fixed)
Cost of purchase: £623.99
Total inc. interest: £680.79
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 21.9% and may be even lower.

Representative Example:

Purchase Rate: 21.9% p.a. (variable)

Representative: 21.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £15.59 / month (APR 15.9%)
Delivery Options
  • By DPD On 27th May to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info

Intel Core i9 10920X X-Series OEM Processor - Power your Creativity

Intel i9 X Series CPU

Ultimate Creator PC Platform for Freelancers and EnthusiastsThe latest Intel Core i9 10920X X Series processor is powered by 12 Cores and 24 Threads to address the simultaneous, compute-intensive demands of creators. The Intel Core X Series CPU’s allow flexible system configuration for specific creator usages, giving you access to 48 PCIe lanes, quad channel memory, plus support for Thunderbolt technology and high-speed SSD drives. The new X Series processors are fully unlocked and offer the power, and convenience of a full studio in your PC to help accelerate your creative work flow from start to finish.

3.50 GHzBase

4.60 GHzTurbo

12 / 24Cores / Threads

19.25 MBSmart Cache

Please Note

This is an OEM version of the Intel Core i9 10920X processor.

Power your Creative Vision with the X Series Family

X Series i9 Performance

Intel® Core™ X-Series Processor FamilyThe Intel® Core™ X-series processor family is built to scale to your content creation needs, starting with 10 cores and going up to 18 for the most extreme performance demands. Experience extreme performance, immersive 4K visuals, high speed storage and DDR4 memory, and the latest technological advancements which are all designed to get you from planning to your masterpiece faster than ever. Intel® Turbo Boost Max Technology 3.0 optimizes lightly-threaded performance by identifying your processor's fastest two cores and directing your most critical workloads to them. It also comes ready to install Intel® Optane™ memory and Intel® Optane™ SSDs for amazing system responsiveness.

Mega Tasking to the Extreme

Intel X Series Mega Tasking

Your Fastest Path from Creativity to Productivity Whether you are working on your latest feature film or the next episode of a YouTube series, the unlocked Intel® Core™ X-series processor family is designed to meet your most demanding creative workflows. With up to 18 AVX-512 enabled cores and enhanced Intel® Turbo Boost Max Technology 3.0 directing your most critical workloads to your processor’s four fastest cores. Experience extreme performance, immersive 4K visuals, high speed storage and memory, and the latest technological advancements - all designed to get you from planning to final product faster than ever.

Additionally, for those tech enthusiasts and data scientists working with AI workloads, support for Intel® Deep Learning Boost streamlines a set of Intel® AVX-512 instructions, reducing it from three tasks to just one for efficient inference acceleration.

X299 Chipset and Intel X-Series Processor

X299 Chipset with X Series

A CPU BUILT FOR THE ULTIMATE PLATFORM The Intel X299 chipset paired with intel Core X-series processors provide a world class platform for gaming, content creation and over-clocking. Whether it is responsiveness, expandability or performance you crave, this platform has you covered.

The platform also provides RAID support on PCI Express and Serial ATA storage devices, fast data transfers with support for PCIe 3.0 storage devices and finally, Intel Optane Memory support. Want to push the envelope with overclocking? The Intel X299 chipset and Intel Core X-series processor family bring new unlocked base clock capabilities.

Unlock your individual cores and memory frequencies to amazing levels while having the flexibility to keep other areas within specification. With support for Intel Extreme Memory Profiles (XMP), Intel Extreme Tuning Utility (XTU), and the Intel Performance Tuning Protection Package Plan the capabilities of the Intel X299 chipset and new Intel Core X-series processors are a threat to every overclocking world record.

Overclock with Confidence

Overclocking X Series

DON'T JUST MEET EXPECTATIONS, EXCEED THEM! The Intel® Core™ X-series processor family is unlocked to provide additional headroom. New features include the ability to overclock each core individually, AVX ratio controls for more stability, and VccU voltage control for extreme scenarios. Combined with tools like Intel's Extreme Tuning Utility (Intel® XTU) and Extreme Memory Profile (Intel® XMP), you have a powerful kit for maximizing performance. Intel® Smart Cache also features a new power-saving feature that dynamically flushes memory based on demand or during periods of inactivity, ensuring your applications keep up with your demands.

Push Past the Limits!

x series overclocking

WHAT IS OVERCLOCKING?Increase processing power by fine-tuning your system to run your processor at higher settings than the default specification.

x series overclocking

WHAT ARE THE BENEFITS?Higher processor settings can allow you to increase game configurations, play at higher frame rates and enable smoother gameplay for the ultimate gaming experience.

x series overclocking

HOW EASY IS IT TO OVERCLOCK?Intel® XTU is an overclocking toolkit that lets you easily change your settings and benchmark speeds to tune your system to its highest possible frequency.

Product and Performance Information 1.Altering clock frequency or voltage may damage or reduce the useful life of the processor and other system components, and may reduce system stability and performance. Product warranties may not apply if the processor is operated beyond its specifications. Check with the manufacturers of system and components for additional details.
2.Intel® technologies’ features and benefits depend on system configuration and may require enabled hardware, software or service activation. Performance varies depending on system configuration. No computer system can be absolutely secure. Check with your system manufacturer or retailer or learn more at Intel.co.uk.
3.Best in Class Wi-Fi 6: Intel® Wi-Fi 6 (Gig+) products support optional 160 MHz channels, enabling the fastest possible theoretical maximum speeds (2402 Mbps) for typical 2x2 802.11ax PC Wi-Fi products. Premium Intel® Wi-Fi 6 (Gig+) products enable 2-4x faster maximum theoretical speeds compared standard 2x2 (1201 Mbps) or 1x1 (600 Mbps) 802.11ax PC Wi-Fi products, which only support the mandatory requirement of 80 MHz channels.

Intel Processor Specifications

Series
Model
Generation
Architecture
Socket
P-cores / Threads
E-cores / Threads
Base Frequency
Turbo Frequency
Cache
Memory Controller
Maximum Memory
DDR5 Memory Frequency
DDR4 Memory Frequency
PCIe 5.0 / 4.0 / 3.0 Lanes
Integrated GPU
TDP
Core i9 Core i7 Core i5 Core i3 Pentium Celeron
12900KS 12900K 12900KF 12900 12900F 12700K 12700KF 12700 12700F 12600K 12600KF 12600 12500 12400 12400F 12300 12100 12100F G7400 G6900
12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th 12th
Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake Alder Lake
S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700 S1700
8 / 16 8 / 16 8 / 16 8 / 16 8 / 16 8 / 16 8 / 16 8 / 16 8 / 16 6 / 12 6 / 12 6 / 12 6 / 12 6 / 12 6 / 12 4 / 8 4 / 8 4 / 8 2 / 4 2 / 2
8 / 8 8 / 8 8 / 8 8 / 8 8 / 8 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4 4 / 4 0 / 0 0 / 0 0 / 0 0 / 0 0 / 0 0 / 0 0 / 0 0 / 0 0 / 0
3.4GHz 3.2GHz 3.2GHz 2.4GHz 2.4GHz 3.6GHz 3.6GHz 2.1GHz 2.1GHz 3.7GHz 3.7GHz 3.3GHz 3.0GHz 2.5GHz 2.5GHz 3.5GHz 3.3GHz 3.3GHz 3.7GHz 3.4GHz
5.5GHz 5.1GHz 5.1GHz 5.1GHz 5.1GHz 4.9GHz 4.9GHz 4.9GHz 4.9GHz 4.9GHz 4.9GHz 4.8GHz 4.6GHz 4.4GHz 4.4GHz 4.4GHz 4.3GHz 4.3GHz
30MB 30MB 30MB 30MB 30MB 25MB 25MB 25MB 25MB 20MB 20MB 18MB 18MB 18MB 18MB 12MB 12MB 12MB 6MB 4MB
Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel Dual-channel
128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB 128GB
4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz 4,800MHz
3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz 3,200MHz
16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0 16 / 4 / 0
150W 125W 125W 65W 65W 125W 125W 65W 65W 125W 125W 65W 65W 65W 65W 65W 65W 65W 46W 46W
Specifications
Model & Type
CPU Type Intel Core i9
CPU Model 10920X
Socket 2066
Architecture Cascade Lake
Manufacturing Process 14 nm
Cores & Clocks
No. of Cores 12 Core
No. of Threads 24
Core Ratio 35 x
Clock Speed 3.5 GHz
Turbo Speed 4.6 GHz
Turbo Boost Max Technology 3.0 Speed N/A
Unlocked Core Multiplier Yes
Unlocked Full Range Base Clock (B-Clock) Yes
Bus Speeds
FSB Speed N/A
QPI Speed N/A
UPI Links/Speed N/A
DMI Speed N/A
Memory Support
Max. Memory Size 256 GB
Max. Memory Speed DDR4 - 2933
Max. Memory Channels 4 (Quad Channel)
ECC Memory Not Supported
Intel Optane Memory Yes
Intel Optane DC Persistent Memory No
Lanes & Features
Intel Deep Learning Boost Support No
Scalability 1 Socket/Processor ONLY
Node Controller Support No
PCIe Version 3.0
PCIe Lanes 48
Integrated Graphics
Features Integrated Graphics No
Integrated Graphics Model/Type N/A
iGPU Cores
iGPU Base Clock N/A
iGPU Boost Clock N/A
iGPU Max. Resolution
CPU Cache
L1 Cache
L2 Cache
L3 Cache 19.25MB
Intel® Smart Cache N/A
Thermals & Package
Max. TDP 165W
Thermal Specification 94 °C
Heatsink/Cooler Included? Not Included, Sold Separately
Package Type OEM
Note
Additional Information
Scan Code LN104930
Model Number CD8069504382000
GTIN 5032037171731
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
12 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
1 months
Manufacturer Contact Details
Manufacturer:
Intel
