Product Overview AMD EPYC™ 7002 Series Processor (Rome)
The next generation of AMD EPYC has arrived, providing incredible compute, IO and bandwidth capability – designed to meet the huge demand for more compute in big data analytics, HPC and cloud computing.
• Built on 7nm advanced process technology, allowing for denser compute capabilities with lower power consumption.
• Up to 64 core per CPU, built using Zen 2 high performance cores and AMD’s innovative chiplet architecture.
• Supporting PCIe Gen 4.0 with a bandwidth of up to 64GB/s, twice of PCIe Gen 3.0.
• Embedded security protection to help defend your CPU, applications, and data.

PCIe Gen 4.0 Ready
AMD EPYC Rome is ready to support PCIe Gen 4.0 with a bandwidth of 64GB/s, twice that of PCIe Gen 3.0. This doubles the bandwidth available from the CPU to peripheral devices such as graphics cards, storage devices and high speed network cards. GIGABYTE’s AMD EPYC 7002 Series server platforms are ready to be used with a new generation of PCIe Gen 4.0 devices such as AMD’s Radeon MI50 GPGPU.

Higher Memory Speed
AMD EPYC’s Rome 7002 Series processors feature faster 8 channel DDR4 memory lanes, supporting RDIMM or LRDIMM memory modules with a speed of up to 3200MHz (1 DIMM per channel).

More M.2 Storage
GIGABYTE’s AMD EPYC 7002 Series server platforms feature more M.2 drive capacity for ultra-fast NVMe storage – both onboard M.2 slots and extra capacity via optional riser cards.

Max TDP Support
GIGABYTE’s AMD EPYC server platforms come ready to support the full list of AMD EPYC Rome 7002 Series processors: up to 225W (standard TDP) / 240W (cTDP).

Data Security
TPM 2.0 Module
GIGABYTE’s AMD EPYC Server is designed to support Trusted Platform Modules (TPM - discrete cryptographic on-board processors).

Optional CMC / Ring Topology Module
GIGABYTE’s H242-Series servers include support for an optional CMC / Ring Topology Module, featuring an Aspeed CMC (Central Management Controller), LAN hub and dual MLAN ports for multi-node management (including iKVM support) by connecting internally to Aspeed BMCs integrated on each node. This results only in one MLAN connection required to perform management of all four nodes, resulting in less ToR (Top of Rack) cabling and switch connections.

In addition, the LAN hub and dual MLAN ports support the ability to create a “ring” connection for management of all servers in the rack - only two ToR (Top of Rack) switch connections are needed to create the ring system, and the ring will not be broken even if one server in the chain is shut down, reducing cabling and switch port usage for greater cost savings and management efficiency.

Carefully Selected Components
GIGABYTE’s passive components are carefully selected to guarantee a stable operating environment and allow the processors and the memory to deliver their maximum performance. GIGABYTE’s server motherboards are built with long lasting components for a high degree of reliability and durability.

Design Features for Easy Maintenance
GIGABYTE’s AMD EPYC 7002 Series server platforms contain many tool less design features for easy installation, maintenance and removal – never worry about forgetting your toolbox or losing a screw again!

Tool-less Rail Kits
Rail kits attach to the side of the server chassis via clipping mechanism.

Tool-less 2.5” & 3.5” Drive Bays
Clipping mechanism secures the drive in place. Install or replace a new drive in seconds.

Efficient, Reliable Power Supply
GIGABYTE’s AMD EPYC 7002 Series server are designed to guarantee high conversion efficiency regardless of load. Redundant 80 Plus ‘Titanium’ or ‘Platinum’ PSUs, combined with GIGABYTE’s precision engineering, translates to super efficient power usage which maximizes the system’s power : performance ratio and reduces OPEX for the user.

Intelligent Power Management Features
Cold Redundancy
To take advantage of the fact that a PSU will run at greater power efficiency with a higher loading, GIGABYTE has introduced a power management feature called Cold Redundancy for servers with dual PSU. When the total system loading falls lower than 40%, the system will automatically place one PSU into standby mode, enabling the other PSU to take over the greater load. This can enable total system power efficiency savings of up to 10%.

SCMP (Smart Crises Management / Protection)
SCMP is a GIGABYTE patented feature that will automatically force the system’s CPU to enter ULFM (ultra-low frequency mode for minimum power consumption) when the BMC is alerted to a PSU fault or error (such as power loss, power surge, overheating or a fan problem). This feature will prevent shutdown in systems with less than 1 + 1 PSU redundancy when one PSU is lost. In a 2U 4 Node server, only two nodes will be switched to low power mode, while two remaining nodes can continue normal operation. When the fault is resolved or the PSU is replaced, the system will automatically return to normal power mode.

GIGABYTE Server Management (GSM)
GIGABYTE Server Management (GSM) is GIGABYTE’s proprietary multiple server remote management software platform, available as a free download from each GIGABYTE server product page. GSM is compatible with either IPMI or Redfish (RESTful API) connection interfaces, and comprises the following sub-programs:
• GSM Server, a software program with an easy to use browser-based GUI to enable global remote monitoring and management of multiple GIGABYTE servers via each server node’s BMC.
• GSM CLI, a command-line interface program to enable global remote monitoring and management of multiple GIGABYTE servers via each server node’s BMC.
• GSM Agent, a software program installed locally on each GIGABYTE server node that retrieves additional node information (CPU/Mem/HDD/PCI/…) from the OS and passes it to the BMC. This information can then be utilized by GSM Server or GSM CLI.
• GSM Mobile, a remote server management mobile APP, available for both Android and iOS.
• GSM Plugin, a plugin that allows the user to manage and monitor GIGABYTE server nodes within VMware’s vCentre.

Intuitive & Informative User Interface
Starting from the GSM Server dashboard, the user can clearly understand the status of each node in the IT environment, including:
• Node connection status (system is online/offline).
• Node hardware sensor status (to detect hardware anomalies). Sensors measure voltage, fan speed and temperature.
• Node usage rate status (allowing you to timely allocate more resources when they are needed), including:
o Power consumption
o Disk/RAID usage information
o Memory usage rate
o CPU usage rate
o Network card / PCI information

The user can also perform various management functions, including:
• Node remote access
o Power on / off / reset
o Launch iKVM
o Reboot BMC / BMC Account Configuration
• Network Configuration
o IPv4/IPv6 setting
• Alert Management
o SNMP trap setting
o Platform events filters
o Forwarding alerts by email
• BMC / BIOS / CPLD Update
• Power Consumption Limit Setting
• Group Management
o Create groups of nodes for BMC / BIOS update or manage power consumption settings.

GSM Mobile for iOS and Android
A GSM Mobile app is available for download for both iOS and Android mobile phones for remote server management on the go.

Management through VMware vCentre
A GSM Plugin is available for VMware’s vCentre, allowing the user to perform remote monitoring and management of GIGABYTE server nodes without having to switch to a separate software platform.

GIGABYTE Management Console (AMI MegaRAC SP-X)
This GIGABYTE server product utilizes a AMI MegaRAC SP-X platform for BMC server management, with a feature rich and easy to use browser-based graphical user interface.
Notable features include:
• RESTful API support (including the latest DMTF standards of Redfish) allows the administrator to integrate with 3rd party applications for server management.
• HTML5-based iKVM remote management client included as a standard feature, no additional add-on license required to purchase.
• Detailed FRU information from SMBIOS.
• Pre-event automatic video recording feature from 10 to 30 seconds.
• SAS / RAID controller monitoring feature.

Easy BIOS Refresh
GIGABYTE has also developed this integrated function (requiring no additional software) that allows users to update the BIOS of motherboards through the BMC controller:
• No need to install core components such as CPUs, memory, drives and OS.
• No need to power on the system (NB. PSU must be connected).
• Update individual (IPMI 2.0) or multiple boards simultaneously (Command Line).

Dynamic Fan Speed Control
GIGABYTE servers are enabled with dynamic fan speed adjustment. Individual fan speed will be automatically adjusted according to the system’s current temperature (according to CPU, DIMM, M.2, HDD, GPU temperature sensors), to achieve the best cooling and power efficiency. When the BMC detects a temperature change, fan speed will be automatically adjusted accordingly. Fan speed profiles may also be manually created and edited when necessary according to the user’s custom requirements.

Environmental Compliance
GIGABYTE maintains its commitment to green products, and adheres to the latest RoHS regulations (in effect July 2017).

VMware Technology Alliance Partner
Recognized as an Advanced Partner in VMware’s Technology Alliance Partner (TAP) program enables GIGABYTE to rapidly develop and certify joint solutions or go-to-market products that leverage VMware virtualization and cloud solutions, enabling our customers to modernize their data centres and implement IT infrastructure and application services with speed, agility, and cost optimization.
Enquire with your GIGABYTE sales representative for more information about combining or integrating this server product with VMware solutions.




@@@ Additions to be made @@@
CPU Socket - 4 x LGA 4094, Socket SP3
Discrete GPU Chipset - AMD’s Radeon MI50 GP
Expansion Slots - 4 x Low profile half-length slots with PCIe x16 (Gen4 x16 bus), 4 x Low profile half-length slots with PCIe x16 (Gen3 x16 bus), 4 x OCP 2.0 mezzanine slot with PCIe Gen3 x16 bandwidth (Type1, P1, P2, P3, P4 with NCSI supported)
Storage Drive Type - 4 x 2.5" NVMe hot-swappable SSD
Backplane I/O - 4 x SATA 6Gb/s / SAS 12Gb/s / PCIe Gen3 x4 port
Internal I/O - 1 x OCP 2.0 mezzanine slots
Network Interface Type - 8 x 1GbE LAN ports
Network Chip/Modules - 1 x Intel® I350-AM2 Port (1Gb/s)
Back Panel - 4 x MLAN Features • Supports 5G network infrastructure.
• 2U - 4 nodes rear access server system for Edge Computing.
• Single AMD EPYC™ 7002 series processor family.
• 4 x LGA 4094 sockets.
• 8-Channel RDIMM/LRDIMM DDR4, 32 x DIMMs.
• 8 x 1Gb/s LAN ports (Intel® I350-AM2).
• 4 x 2.5" NVMe hot-swappable SSD bays.
• 8 x M.2 with PCIe Gen3 x4 interface.
• 8 x Low profile PCIe x16 expansion slots.
• 4 x OCP 2.0 Gen3 x16 mezzanine slots.
• Aspeed® AST2500 remote management controller.
• 1200W 80 PLUS Platinum redundant PSU.
Specifications
Edition H242-Z11 (rev. 100)
Form Factor 2U Rackmount with 4 Nodes
CPU Included Yes
CPU Type AMD EPYC™ 7002 Series
CPU Model Rome
Architecture Zen 2
Manufacturing Process 7 nm
Unlocked CPU No
Core 64 Core
No. of Threads 128
Clock Speed 2.25 GHz
Burst Frequency 3.40 GHz
CPU Cache 256MB
CPU Cooler
Max. TDP 225 W
CPU Socket N/A
Chipset System-on-Chip
Motherboard Form Factor
Motherboard Model MZ12-HD0
Memory Type DDR4
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC)
Memory Type (R/U) RDIMM / LRDIMM
Memory Speed (Mhz) DDR4 - 3200
Max. Memory Capacity 128GB
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed AST2500 Integrated
Discrete GPU Yes
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type DDR4
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution 1920x1200 @60Hz (WUXGA)
Graphics Interface PCIe 4.0 (x16)
Expansion Slots 8 x M.2, 22-42/60/80/110, PCIe Gen3x4
SATA N/A
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
Optical Drive None
Drive Bays 4 x 2.5" NVMe Hot-Swap
Backplane I/O
RAID Support
Internal I/O
  • 1 x Back plane board header
  • 1 x BIOS Recovery Jumper
  • 1 x Clear CMOS jumper
  • 1 x Front Panel Connector
  • 1 x IPMB Connector/Header
  • 2 x M.2
  • 1 x TPM (SPI_TPM) header
  • 1 x TPM Header
  • 1 x USB 3.0 Header
Network Interface Type Dedicated Management Ports
Network Chip/Modules 4 x Dedicated Management Ports
Front Panel
  • 4 x ID button with LED
  • 4 x Power Button with LED
  • 4 x Reset Button
  • 4 x Status LED
Back Panel
  • 4 x ID LED
  • 8 x RJ-45
  • 8 x USB 3.0
  • 4 x VGA
Cooling Fans
  • 1 x 40mm
  • 3 x 80mm
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 2 x 1200 W
PSU Efficiency Rating 80 PLUS Platinum
PSU Redundancy N/A
Operating System Included No
Operating System N/A
Colour
Dimensions 440 x 87.5 x 475 (mm WxHxD)
Weight 17.2 kg
Includes
  • 1 x Barebone Server
  • 4 x CPU Heatsink/s
  • 1 x Rail Kit
Notes
Storage Drives
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Additional Information
Scan Code LN100503
Model Number 6NH242Z11MR-00
GTIN 00000000
