Gainward NVIDIA GeForce GTX 1070 8GB Phoenix Edition
Gainward GeForce GTX 1070 Phoenix 8GB GDDR5 VR Ready Graphics Card, 1920 Core, 1506MHz GPU, 1683MHz Boost
Gainward GeForce GTX 1070 Phoenix
Gainward Phoenix GTX 1070
Gainward.s standard GTX 1070 is the Phoenix Edition 1070 GPU. It features a great spec, boasting high amounts of both memory and core count, as well as various embedded technologies to increase the potential of the graphics card. This high-powered, well cooled GPU is the out-come of combining NVIDIA and Gainward tech.
Take on today’s most challenging graphics intensive PC games without missing a beat. The GeForce GTX 1070 graphics card delivers the incredible speed and power of NVIDIA Pascal™ the most advanced GPU architecture ever created. This is the ultimate gaming platform. #GameReady.
GAINWARD PHOENIX BREAKDOWN
GAINWARD LOADING LED
Phoenix 1070 LED-Lighting
Embedded into the Phoenix GTX 1070 is an LED. This LED will light up when the gaming graphics card is loading, it also adds style and lighting to the inner of your gaming PC.
PHOENIX TEMPERATURE CONTROL
Phoenix GPU Heat Dissipation: Copper Base & Pipes
Within the Phoenix 1070 are various technologies to help keep GPU cool, other than the two 10cm fans. Primarily there is a copper plate for the GPU to ensure maximum heat transfer. Secondly, this 1070 graphics card also has copper pipes running through it to further increase the dissipation of heat - for those extended gaming sessions.
Phoenix Advanced Heat Control: DrMOS
This technology is designed to handle high currents extremely well. It will achieve low noise output and generate less heat whilst handling these high currents.
Extremely silent acoustics when 3D heavy loading. Gainward GeForce GTX 1070 Phoenix gets much quieter than founders edition board under full load operation
Extremely cool temperatures in 3D loading. Gainward GeForce GTX 1070 Phoenix performs extremely lower GPU temperature than founders edition board under full load operation.
GAINWARD GPU CONTROL
Phoenix Control Through Expertool II
This is Gainward’s Expertool is a brand new, useful utility tool, allowing you to control various things on the Phoenix GTX 1070. Expertool grants flexible fan curve control as well as BIOS saving features for the powerful GeForce GTX 1070.
GTX 1070 Connections
HDMI 2.0b / 3x DisplayPort 1.4 / Dual-Link DVI
GEFORCE GTX VR READY
GeForce® GTX graphics cards provide a powerful next-generation platform for the ultimate immersive virtual reality experience. Rigs and cards marked with "GeForce GTX VR Ready" ensure that your VR games will be optimized with a best-in-class GPU.
Immersive VR requires seven times the graphics processing power of traditional 3D apps and games. NVIDIA's unique set of features - such as multi-res shading - mean you get the right level of performance, image quality, and latency to ensure your VR experience is nothing short of amazing.
|Chipset||GeForce GTX 1070|
|Manufacturing process||16 nm|
|Core Clock||1506 MHz|
|Boost Clock||1683 MHz|
|Memory Clock||4000 MHz|
|Memory Bus||256 Bit|
|Cooling Solution||Dual Fan (2)|
|Cooler Design||Gainward Twin Fan|
|Interface||PCIe 3.0 (x16)|
|Maximum Digital Resolution||7680x4320 @ 60Hz|
|Maximum Analog (VGA) Resolution||N/A|
|Max. Concurrent Displays||4 Displays|
|NVIDIA SLI Support||2-Way SLi with High Bandwidth Bridge Support|
|GeForce GTX VR Ready||Yes|
|Microsoft DirectX Support||12 API with Feature Level 12.1|
|Low Profile Compatible||No|
|Low Profile Support||N/A|
|Graphics Card TDP/Power|
|Graphics Card Power Connectors||1 x 8-pin PCIe|
|Minimum Recommended PSU||500 W|
|Maximum GPU Temperature||94 °C|
|Dimensions||285 x 133 mm|
