Edimax EN-9220F-64 64/32bit Fiber Optic Gigabit Adapter
Scan code: LN11358
Manufacturer code: EN-9220F-64
End Of Life
Edimax EN-9220F-64 64/32bit Fiber Optic Gigabit Adapter
Edimax EN-9220F-64 64/32bit Fiber Optic Gigabit Adapter
Scan code:
LN11358
Manufacturer code:
EN-9220F-64
This product is no longer available to purchase.
Email me when the availability or price changes
- SCANPROTECT Protect against installation damage for 28 days.
Product Overview
Key Features
• PCI 32/64bit 1000Base-SX Gigabit NIC Full Duplex
• Support Tag VLAN
• Built-in FIFO buffers
• Plug-and-Play
• Web-Based Management
• Complies with the IEEE 802.3z 1000BASE-SX standard
• Support 64/32-bit, 66/33MHz PCI Local Bus Master for high-speed,operation of Rev. 2.1/2.2 specification
• Plug-and-Play installation--auto-setup IRQ and I/O address
• Full duplex design to double the performance to 2000Mbps
• One Fiber SC connector for 62.5/125 multi-mode fiber
• Built-in FIFO buffers reduce overhead of memory transfers
• Support Tag VLAN
• Provide web-based management
• Provide two LEDs to indicate network link/activity and full duplex function Features Specifications
• Standards: IEEE 802.3z 1000BASE-SX Gigabit Ethernet
• Network Media: 62.5/125 multi-mode fiber with SC type connector
• Protocol: CSMA/CD
• Transmission Rate: 1000Mbps / 2000Mbps
• Hardware Required: IBM compatible PC with available PCI slot ( PCI 2.1/2.2 ), 66/33MHz, 32bit & 64bit
• IRQ Line: Assigned by system
• I/O Address: Assigned by system
• LEDs: Link, Activity
• Temperature: 0 to 55°C (Operating)
• Humidity: 10% to 90% (Non-condensing)
• Certification: FCC Class B, CE Mark
• Dimension: 165 x 58 mm
• Weight: 85g (Max.)
• Support Drivers: Windows 95 OSR2, Windows 98, Windows Me, Windows NT, Windows 2000, Netware Server driver 4.x/5.x, Linux, Unix
