Scan code: LN141694 Manufacturer code: R-CH780-BKADE41-G-1

DeepCool CH780 Tempered Glass Black Panoramic Gaming Case

DeepCool CH780 Panoramic Gaming Case, Black, Full Tower, Tempered Glass, 3x ARGB Fans, E-ATX/ATX/MicroATX

Thumbnail 1 : DeepCool CH780 Tempered Glass Black Panoramic Gaming Case Thumbnail 2 : DeepCool CH780 Tempered Glass Black Panoramic Gaming Case Thumbnail 3 : DeepCool CH780 Tempered Glass Black Panoramic Gaming Case Thumbnail 4 : DeepCool CH780 Tempered Glass Black Panoramic Gaming Case
Scan code: LN141694 Manufacturer code: R-CH780-BKADE41-G-1
Order now and get it tomorrow, Fri 19th Apr
£159.98
Get it Tomorrow, 19 AprIn stock
From £14.50 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £14.50
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £159.98
Total inc. interest: £173.91
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
spend over £280 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 19th Apr to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £9.58

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

CH780 Panoramic Full Tower PC Case from DeepCool

CH780 case

ENJOY THE VIEW The CH780 is a majestic premium ATX+ case that places an emphasis on displaying the beauty of the high-end hardware inside. Air flow and radiator compatibility are not ignored, as there are a plethora of fan and radiator combinations. Beauty and air flow without the need for a mesh front panel.

The Perfect Format

back

PANORAMIC GLASS-DUAL CHAMBER LAYOUTWith its highly sought-after panoramic glass and dual chamber layout, the CH780 provides both premium tempered glass panels and the undeniable aesthetics of a dual chamber setup. The lack of an A pillar removes the main obstruction to a clear and uninterrupted view of the main chamber, while the second chamber houses the less appealing cable management, drives, and power supply.

Do It Your Way

back

MAXIMIZED COMPATIBILITYThe ATX+ form factor of the CH780 case guarantees compatibility with a large range of components. This panoramic DeepCool case supports E-ATX motherboards while also having compatibility for GPUs up to 480mm in length. The dual chamber layout limits GPU mounting to the vertical position, but a PCI-e riser cable and vertical mount are included.

Keeping it Cool

4K Recording

EXTENSIVE COOLING CAPABILITYFan options are plentiful, with the ability to mount nine 120mm or 140mm fans or go to the extreme and add up to four 200mm fans into the conversation. The highly modular fan rails make these configurations a reality.

The CH780 can also support up to three 420mm radiators simultaneously. 420mm radiators can be mounted to the top, bottom, and side of the motherboard tray. The CPU cooler height is limited to 132mm due to the internal configuration.

Included Style and Cooling

4K Recording

A TRINITY OF FANSA set of highly convenient trinity fans come mounted inside the CH780: three beautifully bright 140mm ARGB fans are united into a single 420mm unit. The trinity of fans only require the wiring of a single set of PWM and ARGB cables, greatly reducing the amount of cable management.

Making it Easy

back

QUALITY OF LIFE UPGRADESThe tempered glass side panel makes upgrading components a breeze, while the secondary option to lock the panel in place with screws provides an extra bit of security. A swing-out GPU support arm is built into the case, and a generous 26mm of cable management makes everything a little less complicated. A magnetic top mesh filter helps keep the dust out and can be cleaned with ease. With four USB 3.0 ports, a Type-C port, and a hybrid audio port, there is no shortage of devices that can be accessed from the top front I/O panel.

Specifications
Core Chassis Specifications
Case Edition CH780 Black
Case Form Factor Full Tower
Motherboard Form Factor
  • ATX
  • E-ATX
  • MicroATX
  • Mini-ITX
I/O, Bays & Expansion
Front/Side/Top Panel I/O
  • 1 x Headphone/Mic Combo
  • 4 x USB 3.0
  • 1 x USB Type-C
Drive Bays
  • 3 x 2.5" Internal
  • 2 x 3.5"
Standard Expansion Slots 3
Vertical Expansion Slots
Fans & Filters
Fan Bays
  • 9 x 120mm
  • 9 x 140mm
  • 4 x 180mm
  • 4 x 200mm
Fans Included 3 x 140mm w/ Addressable RGB LEDs
Fan Controller/Hub
Dust Filters
Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility 1 x 120/140/240/280/360/420mm
Bottom Radiator Compatibility 1 x 120/140/240/280/360/420mm
Rear Radiator Compatibility 1 x 120/140mm
Side Radiator Compatibility 1 x 120/140/240/280/360/420mm
Clearances
Max CPU Cooler Height 132mm mm
Max GPU Card Length 480 mm
Cable Routing Space
Side Panels
Window/s Yes
Window Configuration 1 x Main Side
Window Construction Tempered Glass
LED Lighting Functionality
LED Lighting Yes
LED Lighting Emitters Included Addressable LED Fan/s
LED Lighting Colour RGB
LED Lighting Support & Control
Power Supply Compatibility
PSU Included No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support ATX
PSU Mounting Location
Max PSU Length 180 mm
Chassis Physical Specifications
Colour Black
Chassis Construction Materials Steel / Plastic / Tempered Glass
Dimensions 250 × 551 x 528 (WxHxD mm)
Weight 13.7 kg (Approx)
Please Note
Additional Information
Scan Code LN141694
Model Number R-CH780-BKADE41-G-1
GTIN 6933412774723
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
3 months
Manufacturer Contact Details
Manufacturer:
Beijing Deepcool Industries Co
Telephone:
Scan 0871 472 4747
