Asus NVIDIA GeForce GTX 1070 8GB ROG STRIX GAMING
Asus GeForce GTX 1070 ROG STRIX GAMING 8GB GDDR5 VR Ready Graphics Card, 1920 Core, 1506 MHz GPU, 1683 MHz Boost
ASUS - GeForce GTX 1070 - GPU - STRIX GAMING
STRIX Gaming GTX 1070 GPU
This 1070 from ASUS features all the brilliant technologies from previous Strix cards, such as advanced cooling and FanConnect. It is slightly cheaper than most 1070 Strix graphics cards due to having slightly lower core and boost speeds. It runs on the Pascal architecture and GDDR5 memory. You can expect this graphics card to run recent games with crisp visuals easily. Take on today’s most challenging graphics intensive PC games without missing a beat. The GeForce GTX 1070 graphics card delivers the incredible speed and power of NVIDIA Pascal™ the most advanced GPU architecture ever created. This is the ultimate gaming platform. #GameReady.
ASUS STRIX 1070 BREAKDOWN
STRIX GPU COOLING SYSTEM
DirectCU III GPU Cooling Tech
Achieve up to 30% extra cooling performance when gaming with the exclusive DirectCU III cooling technology. This tech features direct-GPU contact heat-pipes that will transport more heat away from the GPU and out-perform the reference designs.
*Image for illustration only. Actual design may vary.
ENHANCED GTX 1070 COOLING
Triple Wing-Blade GPU Cooling
DirectCU III features triple 0dB fans engineered with a patented wing-blade design that delivers maximum air flow and improved 105% static pressure over the heat sink, while operating at 3X quieter volumes than reference cards. The 0dB fans also let you enjoy games in complete silence and make DirectCU III the coolest and quietest graphics card in the market.
FANCONNECT CONTROLLED GPU COOLING
GPU Controlled Fan Headers
When you are gaming it is commonly found GPU temperatures are higher than that of the CPU, due to chassis fans usually referencing CPU temps only - resulting in inefficient cooling. The ROG STRIX 1070 graphics card features two 4-pin GPU controlled headers that can be connected to system fans fort argeted cooling on your GTX 1070.
STRIX 1070 EMBEDDED LED
ASUS 1070 Aura RGB Lighting
Featuring Aura RGB Lighting on both the shroud and backplate, ROG STRIX graphics cards are capable of displaying millions of colors and six different effects for a personalized gaming system (as seen above).
GPU DURABILITY & EFFICIENCY
A More Reliable GTX 1070
This 1070, like various other ASUS boards has had premium alloy components intergrated into their graphics card designs to reinforce the overall reliability. Super Alloy Power II components greatly enhance 1070 efficiency, reduce power loss and achieve thermal levels that are approximately 50% cooler than previous designs.
GEFORCE GTX VR READY
GeForce® GTX graphics cards provide a powerful next-generation platform for the ultimate immersive virtual reality experience. Rigs and cards marked with "GeForce GTX VR Ready" ensure that your VR games will be optimized with a best-in-class GPU.
Immersive VR requires seven times the graphics processing power of traditional 3D apps and games. NVIDIA's unique set of features - such as multi-res shading - mean you get the right level of performance, image quality, and latency to ensure your VR experience is nothing short of amazing.
|Chipset||GeForce GTX 1070|
|Edition||ROG STRIX GAMING|
|Manufacturing process||16 nm|
|Core Clock||1506 (1531 in OC Mode) MHz|
|Boost Clock||1683 (1721 in OC Mode) MHz|
|Memory Clock||8008 MHz|
|Memory Bus||256 Bit|
|Cooling Solution||Tri Fan (3)|
|Cooler Design||DirectCU III with RGB LED|
|Interface||PCIe 3.0 (x16)|
|Maximum Digital Resolution||7680x4320 @ 60Hz|
|Maximum Analog (VGA) Resolution||N/A|
|Max. Concurrent Displays||4 Displays|
|NVIDIA SLI Support||2-Way SLi with High Bandwidth Bridge Support|
|GeForce GTX VR Ready||Yes|
|Microsoft DirectX Support||12 API with Feature Level 12.1|
|Low Profile Compatible||No|
|Low Profile Support||N/A|
|Graphics Card TDP/Power|
|Graphics Card Power Connectors||1 x 8-pin PCIe|
|Minimum Recommended PSU|
|Maximum GPU Temperature|
|Dimensions||134 x 40 x 298 mm|
