ASUS ESC4000A-E11-SKU1 AMD EPYC Zen 3 2U PCIe Gen4 Barebone GPU Server

ASUS ESC4000A-E11 AMD EPYC™ 7002/3 Server System, 2U Rackmount, 1600W 1+1, 8x 3.5"/2.5" SATA Hot-Swap Bays, 2x NVME

Thumbnail 1 : ASUS ESC4000A-E11-SKU1 AMD EPYC Zen 3 2U PCIe Gen4 Barebone GPU Server Thumbnail 2 : ASUS ESC4000A-E11-SKU1 AMD EPYC Zen 3 2U PCIe Gen4 Barebone GPU Server Thumbnail 3 : ASUS ESC4000A-E11-SKU1 AMD EPYC Zen 3 2U PCIe Gen4 Barebone GPU Server Thumbnail 4 : ASUS ESC4000A-E11-SKU1 AMD EPYC Zen 3 2U PCIe Gen4 Barebone GPU Server
Scan code: LN133593 Manufacturer code: 90SF0251-M00150
£3,119.99Item currently awaiting an ETA
Pre order
From £87.97 / month (APR 16.9%) or 0% for 4 months
Monthly Payment: £282.67
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £3,119.99
Total inc. interest: £3,391.93
Monthly Payment: £152.35
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £3,119.99
Total inc. interest: £3,656.18
Monthly Payment: £109.26
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £3,119.99
Total inc. interest: £3,933.08
Monthly Payment: £87.97
Instalment Rate: 16.9% p.a. (fixed)
Cost of purchase: £3,119.99
Total inc. interest: £4,222.54
Example
Minimum Spend: £99
Instalment Rate: N/A
Cost of purchase: £99
Total inc. interest: £99
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 23.9% and may be even lower.

Representative Example:

Purchase Rate: 23.9% p.a. (variable)

Representative: 23.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
With a 10% deposit from just £82.91 / month (APR 19.9%)
Delivery Options
  • By DPD to your specified address. | £11.50 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

Services
  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview

Powered by AMD EPYC™ 7003 & 7002 Series Processors

The AMD EPYC™ 7003 & 7002 processor features the world's first 7nm datacenter-design and a PCI Express® 4.0-capable x86 server processor with up to 2X the performance and 4X the floating-point capability. With support for up to 64 cores, 128 threads, 8-channel DDR4 3200, 128 PCIe 4.0 lanes and up to 280 watts of max. thermal design power (TDP), this processor also includes memory and virtualization encryption features to ensure exceptional security.


PCIe 4.0 Expansion

PCIe® 4.0 delivers 16 GT/s bandwidth - double the speed of PCIe 3.0 - while offering lower power consumption, better lane scalability and backwards compatibility. ASUS ESC4000A-E11 features up to eleven PCIe 4.0 slots to support a diverse array of graphics, storage and networking applications, such as HBA/RAID, NIC and InfiniBand (IB) cards.


GPU and FPGA Support

ESC4000A-E11 features a powerful GPU architecture that supports up to four double- slot or eight single-slot GPUs in a 2U chassis, including NVIDIA® A100 and AMD Instinct™ MI100 accelerator to meet the demands of AI and HPC, and to securely run workloads in virtualization environment. It is also a Xilinx Alveo-qualified server to provide optimized acceleration for hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.


Flexible Front Panel Design

ESC4000A-E11 features a flexible front panel design that allows for easy storage and network expansions and upgrades. The design offers easier accessibility of up to four NVMe SSD drives and an optional choice of OCP 3.0, a hyper M.2 adapter or HBA/RAID card via PCIe 4.0 slot for better performance and lower latency.


NVIDIA RTX Server

ESC4000A-E11 is a NVIDIA RTX server validate system that deliver unprecedented performance at a fraction of the cost, space, and power requirements of traditional CPU-based solutions, from production rendering to scalable visualization systems or HPC, AI, ML, big data analytics, and at the edge deployment options.


Ultrafast Connectivity for HPC Applications

ESC4000A-E11 features an OCP 3.0 mezzanine card to deliver speeds of up to 200 Gbps for HPC applications that require high-bandwidth, low-latency network support for connecting multiple nodes and clusters.


Scalable Storage Design

To effectively manage the storage demands of growing amounts of data, ESC4000A-E11 has a dense chassis design that accommodates up to eight 3.5-inch or 2.5- inch drives, including up to four NVMe SSDs support. One onboard 22110-length M.2 SSD allows faster data transfer speeds for OS installation, and a hyper M.2 card is available to provide even greater expansion capability.


Enhanced Security

ASUS ESC4000A-E11 servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.

In addition, all ESC4000A-E11 servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.


ASUS ASMB10-iKVM

ASUS ASMB10-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.


ASUS Control Center

ASUS Control Center (ACC) is a centralized and integrated IT-management platform for monitoring and controlling ASUS servers, workstations and mini PCs. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.


Performance Boost Technology

ASUS servers feature exclusive Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for time-sensitive applications such as financial services or data center operations. In the BIOS you can choose from pre-configured server profiles optimized for specific workloads, maximizing overall performance and reducing server-configuration time.

Core Optimiser - Maximises the processor frequency in multi-core operations, avoiding frequency shifting for reduced latency.
Engine Boost - Automatic power acceleration with an innovative voltage design to increase server overall performance.
Workload Presets - Preconfigured BIOS server profiles based on workloads and benchmarks for improved performance and efficiency.


Thermal Control Technology

ASUS features server thermal-control technologies to provide real-time server temperature monitoring, intelligent fan-curve adjustments, and continue delivering the value of optimised power-efficiency.


ASUS Thermal Radar 2.0

ASUS Thermal Radar 2.0 takes advantage of placing up to 56 ambient sensors on the front panel of a server as well as in components for temperature monitoring. It can perform intelligent fan-curve adjustments to fit the real-time server usage patterns, lowering fan power-consumption by up to 36% and reducing total cost of ownership - ideal for data centres with extreme workloads.

More Sensors - Sensors are embedded on front panel, CPU, NVMe SSD, OCP card, PSU and memory. Up to 56 ambient sensors on selected models.
Intelligent Adjustment - Fans are grouped for dynamic fan curve adjustment in different fan zones to achieve more precise thermal monitoring.
Economics and Eco-friendly - More precise thermal information can reduce power consumption and lower down TCO.


ASUS Power Balancer

ASUS Power Balancer is an exclusive technology that enables ASUS servers to adjust overall loading automatically based on real-time monitoring in order to decrease overall power consumption for improved efficiency and cost/performance optimisation.

Dynamic Monitoring - Monitor and feedback CPU loading to have more accurate management on the system.
Auto Frequency Adjustment - Dynamically and automatically adjust CPU frequency based on current utilisation to reduce power consumption.
Enhanced Power Efficiency - Optimise performance per watt for a better power efficiency system.


Features


• Up to eleven PCIe® 4.0 slots enables higher bandwidth and improved data transfer rates.
• GPU-optimized design allows four double-slot or eight single-slot GPUs, including NVIDIA® A100, Tesla® T4 or Quadro®.
• A Xilinx Alveo-qualified server support for Alveo U50 to provide optimized acceleration for workloads across cloud and on-premises data centers.
• Supports NVIDIA® NVLink bridge to enable scaling of performance to meet the demands of visual computing workloads.
• A choice of PCIe Gen 4.0, OCP 3.0, NVMe and M.2 on the front panel offer flexibility, performance and scalability for changing business needs.
• High power efficiency with redundant 2200W or 1600W Platinum power supplies.
• ASUS thermal control technology offers more efficient power consumption for large-scale environments.
• ASUS performance tuning technology improves workload throughput to achieve optimal server performance.
• Onboard ASUS ASMB10-iKVM with ASPEED AST2600 controller for out-of-band management.
• Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency.
• Two hot-plug, hot-swap fans design for fully redundancy protection and thermal efficiency.

Specifications
Edition ESC4000A-E11
Form Factor 2U Rackmount
CPU Included No
CPU Type AMD EPYC™ 7003 Series
CPU Model
Architecture Infinity / Zen 3
Manufacturing Process 7 nm
Unlocked CPU No
Core
No. of Threads N/A
Clock Speed N/A
Burst Frequency N/A
CPU Cache
CPU Cooler
Max. TDP 280 W
CPU Socket SP3
Chipset N/A
Motherboard Form Factor Proprietary
Motherboard Model
Memory Type DDR4 RDIMM/LRDIMM
Memory Included No
Memory Capacity Included N/A
Memory Edition
Memory Channels Octa (8)
Memory Type (ECC) ECC/Non-ECC
Memory Type (R/U) RDIMM / LRDIMM / LRDIMM 3DS
Memory Speed (Mhz) DDR4 - 3200
Max. Memory Capacity 2048GB
On-board/Integrated Graphics Yes
Processor/Motherboard Graphics Chip Aspeed® AST2600
Discrete GPU No
Discrete GPU Chipset
GPU Architecture
GPU Manufacturing Process
GPU Cores/Streams/Execution Units
GPU Tensor Cores N/A
Base GPU Speed N/A
Max. GPU Speed N/A
GPU Memory Size
GPU Memory Type
GPU Memory Clock
GPU Memory Bus
Discrete GPU Cooler
Multi-GPU Configuration No
Max. GPU Resolution
Graphics Interface PCIe 4.0 (x16) [PCIe 3.0 Backwards Compatible]
Expansion Slots
  • 2 x M.2, 22-42/60/80/110, PCIe Gen4x4
  • 8 x PCIe 4.0 x16 (x8 Bandwidth)
  • 2 x PCIe 4.0 x16, LP, HL
  • 1 x PCIe 4.0 x8
SATA SATA3 / M.2
HDD Storage Included No
HDD Storage Type
HDD Storage Capacity N/A
SSD Storage Included No
SSD Storage Type
SSD Storage Capacity
Optical Drive None
Drive Bays
  • 4 x 2.5"/ 3.5" Internal SATA Hot-Swap
  • 4 x 2.5"/3.5" SATA/SAS Hot-Swap (Front)
Backplane I/O
  • 4 x NVMe/SAS/SATA Ports (Front)
  • 4 x NVMe/SAS/SATA Ports (Rear)
  • 4 x SAS/SATA Ports (Front)
RAID Support Requires RAID Card
Internal I/O N/A
Network Interface Type Dual Wired Gigabit LAN (10/100/1000)
Network Chip/Modules
  • 1 x Intel® i350-AM21 Dual Port (GbE)
  • 1 x Mgmt LAN
Front Panel 4 x USB 3.2 Gen1 Type-A
Back Panel
  • 2 x 10/100/1000 (LAN)
  • 1 x Mgmt LAN
  • 2 x USB 3.2 Gen1 Type-A
  • 1 x VGA
Cooling Fans
Keyboard / Mouse Included No
Remote Control Included No
VESA Mountable N/A
PSU Wattage 1600 W
PSU Efficiency Rating 80 PLUS Platinum
PSU Redundancy 1+1
Operating System Included No
Operating System N/A
Colour
Dimensions 800 x 440 x 88.9 (mm WxHxD)
Weight 34 kg
Includes
Notes
Additional Information
Scan Code LN133593
Model Number 90SF0251-M00150
GTIN 4711081670605
