ASRock Intel Z170 OC FORMULA ATX Overclocking Motherboard

ASRock Z170 OC FORMULA, Intel Z170, S 1151, DDR4, SATAe, M.2 (PCIe/SATA), 2-Way SLi/4-Way CrossFire, GbE, USB3.1A+C, ATX

ASRock
Scan code: LN67551 Manufacturer code: Z170 OC FORMULA Request call
£203.99
In stock
Spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
High End
Delivery options £5.48 By DPD On 30th Mar 2017 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout ScanProtect protection ScanProtect Protect against installation damage for 28 days.More
Specifications
Core Specifications
Form Factor ATX
CPU Socket 1151
Chipset Intel Z170
RAM Memory Support
Memory Type DDR4
Memory Channel Dual (2)
Memory Type (ECC) Non-ECC
Memory Type (R/U) UDIMM (Unbuffered)
Memory Speed (Mhz)
  • DDR4 - 2133
  • DDR4 - 2400(OC)
  • DDR4 - 2600(OC)
  • DDR4 - 2800(OC)
  • DDR4 - 2933(OC)
  • DDR4 - 3000(OC)
  • DDR4 - 3200(OC)
  • DDR4 - 3300(OC)
  • DDR4 - 3400(OC)
  • DDR4 - 3466(OC)
  • DDR4 - 3600(OC)
  • DDR4 - 3666(OC)
  • DDR4 - 3733(OC)
  • DDR4 - 3800(OC)
  • DDR4 - 3866(OC)
  • DDR4 - 4000(OC)
  • DDR4 - 4133(OC)
  • DDR4 - 4200(OC)
  • DDR4 - 4266(OC)
  • DDR4 - 4300(OC)
  • DDR4 - 4400(OC)
  • DDR4 - 4500+(OC)
Max. Memory Capacity 64GB (4x16GB)
Audio
Audio Purity Soundâ„¢ 3 Realtek ALC1150 7.1 HD Audio
Graphics Support
Primary GPU Interface PCIe 3.0 (x16)
SLI Support 2-Way SLi
Crossfire Support 4-Way CrossFire
On-Board Graphics Connectors
  • DisplayPort 1.2
  • HDMI
Internal Connectivity
Expansion Slots
  • 1 x M.2, 2230/2242/2260/2280, PCIe/SATA
  • 1 x M.2, 2230/2242/2260/2280/22110, PCIe/SATA
  • 1 x M.2, 2242/2260/2280, PCIe/SATA
  • 1 x PCIe 2.0 x1
  • 1 x PCIe 3.0 x1
  • 1 x PCIe 3.0 x16
  • 2 x PCIe 3.0 x16 (x4 Bandwidth)
  • 1 x PCIe 3.0 x16 (x8 Bandwidth)
  • 1 x Vertical Half-size Mini-PCIe Slot
SATA Support SATAe / SATA3 / M.2
RAID Support via SATA3 0~5 / M.2
Storage Mode Support
  • AHCI
  • Hot Plug
  • Intel® Rapid Storage Technology 14
  • Intel® Smart Response Technology
  • NCQ
  • NVMe Boot (via M.2 PCIe Slot)
  • NVMe Boot (via PCIe 3.0 Slot)
  • RAID 0
  • RAID 1
  • RAID 10
  • RAID 5
Internal I/O
  • 1 x 24-pin (Power)
  • 1 x 4-pin (Power)
  • 2 x 4-pin CPU Fan Connector
  • 4 x 4-pin System Fan Connector
  • 1 x 8-pin (Power)
  • 1 x BIOS Selection Switch
  • 1 x Direct Key Button
  • 1 x Dr. Debug with LED
  • 1 x Front Panel Audio Header
  • 1 x LN2 Mode Header
  • 1 x Menu Button
  • 1 x PCIe ON/OFF Switch
  • 1 x Post Status Checker (PSC)
  • 1 x Power LED / Speaker Header
  • 1 x Power Switch with LED
  • 1 x Rapid OC Buttons
  • 1 x Reset Switch with LED
  • 3 x SATA Express (Compatible with 2x SATA III)
  • 4 x SATA III - 6Gb/s
  • 1 x Serial (COM) Header
  • 1 x Slow Mode Switch
  • 1 x Thunderbolt AIC Connector (10-pin)
  • 1 x Thunderbolt AIC Connector (5-pin)
  • 1 x TPM Header
  • 2 x USB 2.0 Header
  • 2 x USB 3.0 Header
  • 1 x USB 3.0 Type-A - Vertical
  • 1 x V-Probe: 7-set of voltage measurement points
  • 1 x XMP Switch
External Connectivity
Network Interface Type Wired Gigabit LAN (10/100/1000)
Network Chip/Modules 1 x Intel® I219V (Gigabit LAN)
Rear I/O Connectors
  • 1 x 10/100/1000 (LAN)
  • 1 x Bass Speaker Out
  • 1 x Central Speaker Out
  • 1 x Clear CMOS switch
  • 1 x DisplayPort 1.2
  • 1 x Front Speaker Out
  • 1 x HDMI
  • 1 x Line In
  • 1 x Mic-In
  • 1 x PS/2 Keyboard/Mouse Combo
  • 1 x Rear Speaker Out
  • 1 x SPDIF Out (Optical)
  • 2 x USB 2.0
  • 4 x USB 3.0
  • 1 x USB 3.1 Type-A
  • 1 x USB 3.1 Type-C
Other Motherboard Specifications
Water Cooled No
QPI Speed N/A
