Scan code: LN67856 Manufacturer code: 90-XRH000-14QEB0

ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router

ASRock G10 AC2600 Wireless Gaming Router, 1733+800Mbps, 2.4/5GHz, a/b/g/n/ac, 4x GLAN, 2x USB3,+ H2R 2in1 HDMI Dongle

Thumbnail 1 : ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router Thumbnail 2 : ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router Thumbnail 3 : ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router Thumbnail 4 : ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router : video thumbnail 1 ASRock G10 Gaming AC WiFi Router with H2R HDMI Dongle Router : video thumbnail 2
Scan code: LN67856 Manufacturer code: 90-XRH000-14QEB0
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD On 27th Jan to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

Product Overview Background Story
The design concept of our prototype began from a router/decorative for the living room, or even an art piece for public spaces. Therefore we decided to create a stereoscopic tower shaped router

Speed, coverage and stability are the basics for a router, however to make one attractive is the difficult part.

While most routers follow a dull uniformed mold, users tend to hide them in shame, behind shelves or under the table. Hence, we've made ASRock G10 into a futuristic and vogue art piece that deserves to be put under the spotlight.

Aside from the superficial design, our engineers introduced the Internet of Things technology to make this router even more practical. By adding infrared receivers and transmitters, you can remotely control your home appliances with your mobile devices.

Furthermore, a travel router, Ethernet adapter plus HDMI dongle hybrid called H2R comes with the G10 router, just like icing on the cake! Now, you are entitled to high speed connections and wireless sharing with ASRock G10.

World's Fastest 4T4R 802.11ac
[email protected] & [email protected]
• Beamforming Technology.
• Multi-User MIMO.
• Gaming Boost.

Ultra Fast with 8 Antennas – 5GHz (1733Mbps) & 2.4GHz (800Mbps)
• 8 x dipole high power antennas that deliver wireless signals 360 degrees.
• Fixed internal antennas to keep the perfect performance and coverage.

Gaming Boost
Gives your online games / consoles the bandwidth they need for the best gaming experience automatically.

MU-MIMO (Multi-User MIMO)
The latest wireless 802.11ac technology for simultaneously streaming and gaming on multiple devices.

Beamforming Technology
ASRock's Beamforming technology optimizes performance, enhances wireless coverage and improves the stability of your client devices.

Remotely Control Your Home Appliances: IR Learning Technology & ASRock Router APP

ASRock Router APP
• Learn the codes of other infrared devices.
• Turn your smart phone into a universal remote controller for your home appliances.

• Step 1: Download the ASRock Router APP to your mobile device.
• Step 2: Let G10 learn the infrared signals of your remote controller.
• Step 3: Use your mobile device to remotely manipulate your router to control your home appliances.


Your Private Cloud
• 2 USB 3.0 Ports.
• Printer Server.
• Easy NAS.

Easy NAS
Works as a streaming server, file sharing server or even a personal cloud server.

Easy Setup
Users are automatically directed to the configuration page upon connecting their systems to ASRock G10, regardless of any kind of browser. The user friendly interface allows newbies to automatically detect internet configurations, upgrade firmware and optimize bandwidth.

H2R: HDMI Dongle 2-In-1 Travel Router & HDMI Miracast / EZplay / DLNA Device
• Watch your favorite movies or photos from YouTube, Dropbox and more on your TV with HDMI Miracast / EZplay & DLNA.
• Works with devices you already own, including Android / iOS smartphones and tablets.
• 1920 x 1080 output resolution
• A powerful access point for sharing Ethernet connections over WiFi.
• 802.11n 2T2R internal antennas, supports up to 300Mbps of rated bandwidth.

More information can be found in the PDF manual below:
Data Sheet Features G10 Gaming Router Features:

GAMING BOOST Automatically Cloud QoS
IOT Turns G10 as Infrared HUB to control all IR devices from you mobile phone from everywhere.
NAS Plug & Play NAS in zero setting, and upload/download files or BitTorren from everywhere.
SELF-HEALING it keeps the performance and stability at its peak and also extends the lifespan of the router.
H2R (HDMI 2-in-1 Router) HDMI Dongle (Airplay/Miracast)& Travel router 2-in-1, can work at the same time.

Main Specs

• Supports IEEE 802.11 a/b/g/n/ac 2.4GHz & 5GHz.
• Dual Core 1.4GHz processor.
• 8 x internal antennas.
• Memory – 256MB Flash + 512MB RAM.
• MU-MIMO support.
• Beamforming support.
• ASRock Gaming Boost.

H2R HDMI 2-in-1 Router Features:
• Supports IEEE 802.11 a/b/g/n.
• 2T2R travel router.
• Supports Miracast / EZplay & DLNA.
• Memory - 128MB Flash + 128MB RAM.
• 2 x internal antennas.
• 1920 x 1080 output resolution.

• G10 Gaming Router.
• H2R (HDMI 2-in-1 Router).
• 12V Power Adapter for G10.
• Network RJ45 Cable for H2R.
• Micro USB Cable for H2R.
• HDMI Cable for H2R.
• 2 x Quick Start Guide (G10 and H2R).

Please note: Specifications below refer to the G10 Router ONLY.
Networking, Connectivity & Ports
Device Type Cable (WAN)
Compatible Internet Connections
Network Connectivity
  • 10/100/1000
  • Wireless LAN
Network Ports
Other Connectors 2 x USB 3.0
USB Applications
Wired Protocols
Total LAN Connections 4
Total WAN Connections 1
64 Bytes L3 Forwarding Performance
512+ Bytes L3 Forwarding Performance
Wireless Speed 2533 (800+1733) Mbps
Wireless Protocols
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
  • IPv4
  • IPv6
Wireless Band Dual Band
  • 2.4 GHz
  • 5 GHz
Operation Channel
Wireless Transmitter Power 0%~100%
Antenna 8x Internal High Performance Antennas
Core Features
Router/Modem Processor 1.4GHz Dual Core
Internal RAM Memory
Internal RAM Memory Type
Internal Flash Memory
LED Indicators
OS Support
Max. Power Consumption
PSU Type
Security & VPN
Security Protocols
  • WPA
  • WPA2
  • WPS
Firewall/NAT No
VPN Support
Physical Specifications
Additional Information
Scan Code LN67856
Model Number 90-XRH000-14QEB0
GTIN 4717677328615

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

24 months
Return to base
DOA Period:
28 days
RTB Period:
24 months
Manufacturer Contact Details
0871 472 4747
