Areca ARC-8026-24 SAS Expander Module

Areca ARC-8026-24 SAS Expander Module, 3 x 6Gb/s SASA / 4 x SFF8088 ports

Areca
Scan code: LN53648 Manufacturer code: ARC-8026-24 Request call
£601.49Item currently awaiting an ETA
Pre order
Buy Now, Pay Later with a 10% deposit. Or spread the cost of your finance over 24-48 months.
High End
Delivery options £5.48 By DPD DPD Delivered to your specified address. Receive SMS with one-hour delivery window. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout
Product Overview ARC-8026 SAS Expander Module
(Three 6Gb/s SAS 4x SFF-8088 ports; one host and two for expansion to additional JBOD enclosures)
The Areca SAS Expander module ARC-8026 is based on the LSI LSISAS2x36/28 expander IC, SAS-2 chip which features 36/28 x 6Gb/s ports and 6G/3G multiplexing, SAS 2.0 zoning, self-configuration, table-to-table routing, and an integrated PPC processor for SES-2 and enclosure management support.
The ARC-8026 expander module features three 6Gb/s SAS 4x SFF-8088 ports; one host and two for expansion to additional JBOD enclosures. It is designed to fit into a stand-alone box and can be installed in a 5.25”mounting shell. The Areca SAS expander box is ideal for enclosure customers that want to support up to 24 channels 6Gb/s and 3Gb/s SAS/SATA/SSD JBOD function units using low-cost SFF-8087 SAS cables. It has been fully tested and qualified with 6Gb/s and 3Gb/s Areca external SAS/Fibre/iSCSI/PCIe to SAS RAID controller, SAS RAID adapters and HBAs.

Data Sheet

Features Box Controller Modules
Expander Board: 1 modules
Sensors: 1 sensor on expander board

Controller External Connectors
SAS Connectors
1 x SAS “IN” connector for connection to the host
2 x SAS “OUT” connector for expasion to next JBOD enclosure

Drives
• SAS Hot-Plug Hard Drives
Up to 12/16/24 6.0 Gb/s SAS hard drives at speed of 10K or 15K rpm
• SATA Hot-Plug Hard Drives
Up to 12/16/24 6.0 Gb/s SATA hard drives at speeds of 7.2K or 10K rpm

Internal Connectors
3/4/6 SFF-8087 min- SAS connectors
1 x 6-pin PCI-E power connector
4 x 3-pin fan connector
2 x 2-pin power status connector
1 x 6-pin LCD connector

Serial Connector (per Expander Board)
1 x 6-pin UART RJ-11 connector (for expander box manager only)

LED Indicators
Internal fault/activity header
12/16/24 2.54mm activity and fault header

External SAS Port LED Indicators
Two one-color LED status indicators for each SAS host port, one for SAS port link and one for the activity status
Two one-color LED status indicators for each SAS expansion port, one for SAS port link and one for the activity status

Monitors/Indicators
System status indication through LCD, LED (Link status and Activity) and alarm buzzer
Enclosure management such as two power supplies status connectors and four fan monitor/speed control connectors (Protocols SES-2 over SAS ports) ready

Management
In-band SAS port
Out-of-band RS232 serial port
CLI through RS232 serial port

Physical
Dimension
41(H) x 145(W) x 200(D) mm

Environmental
Temperature
Operating: 10° to 40°C
Storage: –40° to 70°C

Relative Humidity
Operating 10% to 80 (non-condensing)
Storage 5% to 95% (non-condensing)

Power Consumption
12V @ 0.63Amps = 7.56W
+5V @ 0.52Amps = 2.6W
Specifications
Specifications
Ports Total Port
Ports Internal 4 Int Ports
Ports External Ext Ports
Connectors
Interface
JBOD No
RAID Support N/A
Low Profile Compatible No
Cables Inc.
Cache Memory
Notes
