8 Port eten SA-3008 Ethernet Switch 10/1000 Gigabit

8 Port eten SA-3008 10/100/1000 Gigabit Ethernet Switch

eten
Scan code: LN39057 Manufacturer code: SA-3008 Request call
£31.99
In stock
Buy Now, Pay Later with a 10% deposit. Or spread the cost of your finance over 24-48 months.
High End
Delivery options £5.48 By DPD On 5th Dec 2016 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout Scansure protection Scansure Protect against installation damage for 28 days.More
Product Overview SA-3008 is 8-Port 10M/100M SOHO Fast Ethernet Switch that is designed for small or medium network environment to strengthen its network connection. This product is compact in size, making it ideal for SOHO users with limited space. It is a superb choice for expanding your network.

High-Speed Networking
SA-3005 / 3008 provide an excellent solution for expanding your Gigabit network. By Gigabit speed, this product provides high flexibility and high bandwidth connectivity to servers, workstations and other attached devices. It enables you to save time transferring large files.

Auto-MDI/MDI-X
Every port can automatically sense your type of cable, so there is no need for crossover cables whether you are connecting this switch to another switch or to a computer.

Auto-Negotiation
Every port can automatically sense if the connected network devices are running at 10Mbps, 100Mbps or 1000Mbps and Half/Full-Duplex mode, and adjust accordingly.

Non-Blocking
This switch receives and forwards traffic seamlessly with its non-blocking wire-speed. Every port simultaneously supports up to 2000Mbps of bandwidth in full-duplex mode. This feature provides full wire speed to the connected devices and allows you to run a smooth network.

Store and Forward
By this function, this switch can maximize network performance while minimizing the propagation of bad network packets.

Features Standards
o IEEE 802.3 10BaseT
o IEEE 802.3u 100BaseTX
o IEEE 802.3ab 1000BaseT
o IEEE 802.3x Flow Control

Features
o Number of Ports: 5
o MAC Address: 4K
o Buffer Memory: 1.25 MB
o Jumbo Frames: 4.6K
o Transmission Method: Store and Forward

Filtering/Forwarding Rates
o 1000Mbps port - 1,488,000pps
o 100Mbps port - 148,800pps
o 10Mbps port - 14,880pps

Transmission Media
o 10BaseT Cat. 3, 4, 5 UTP/STP
o 100BaseTX Cat. 5 UTP/STP
o 1000BaseT Cat. 5E UTP/STP

Led Indicators
o Per Port: Link/Act
o Per Unit: Power

Power Requirement
o 5-Port: DC 5V/2A
o 8-Port: DC 5V/2.5A

Power Consumption
o 10 Watts (Max)

Dimensions
o 140 x 105 x 25 mm (L x W x H)

Weight
5-Port: 196 g
8-Port: 224 g

Certifications
o FCC Class B, CE

Specifications
Specifications
Edition
Network Ports 8 x Fast Ethernet 10/100
PoE Ports
Other Ports
Built-in Memory
Bandwidth 1.6 Gbps
Network Protocols
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
Mean Time Between Failures (MTBF)
Acoustic Noise
Max. Power Consumption 6 W
Dimensions (WxHxD) 105 x 25 x 140 mm
Weight 0.224 kg
