Scan code: LN100770 Manufacturer code: Focus PX-750

Seasonic Focus PX 750 750W Modular 80+ Platinum PSU/Power Supply

750W Seasonic Focus PX-750 80PLUS Platinum, Single Rail, Fully Modular, 62A, 120mm Fan, ATX PSU

Thumbnail 1 : Seasonic Focus PX 750 750W Modular 80+ Platinum PSU/Power Supply Thumbnail 2 : Seasonic Focus PX 750 750W Modular 80+ Platinum PSU/Power Supply Thumbnail 3 : Seasonic Focus PX 750 750W Modular 80+ Platinum PSU/Power Supply Thumbnail 4 : Seasonic Focus PX 750 750W Modular 80+ Platinum PSU/Power Supply
Scan code: LN100770 Manufacturer code: Focus PX-750
£139.49Item overdue since 30 August 2019
Pre order
From £12.53 / month (APR 14.9%)
Monthly Payment: £24.21
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £139.49
Total inc. interest: £145.22
Monthly Payment: £12.53
Instalment Rate: 14.9% p.a. (fixed)
Cost of purchase: £139.49
Total inc. interest: £150.27
If you are approved for a credit limit with PayPal Credit and use it for future purchases, the APR for those purchases won't be more than 19.9% and may be even lower.

Representative Example:

Purchase Rate: 19.9% p.a. (variable)

Representative: 19.9% APR (variable)

Assumed Credit Limit: £1,200

Subject to status. Terms and Conditions apply.
spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
Delivery Options
  • By DPD to your specified address. | £5.48 Receive SMS with one-hour delivery window Weekend, timed and European delivery options are available at checkout

    Have your parcel delivered by DPD to your specified address. Receive SMS with one-hour delivery window

    Weekend, timed and European delivery options are available at checkout
  • Collect instore Collect from our Bolton store, BL6 6PE | Free

    Order online, collect from our Bolton store (25-28 Enterprise Park, Middlebrook, Horwich, Bolton, BL6 6PE)

  • UPS and DPD Pickup Pickup from local convenience store | £4.79

    Collect your parcel from your newsagents, petrol stations and convenience stores

Services
  • SCANPROTECT Protect against installation damage for 28 days. More info

    ScanProtect is an enhanced warranty specifically designed and offered by Scan to reduce the risk of any mishap or damage to components during installation.

    Our aim with ScanProtect is to encourage our customers to upgrade or build their own PC confidently. For a small additional fee our customers are provided with complete peace of mind.

  • 48HR REPLACEMENT If you need to return this item, your replacement will be dispatched within 2 working days of your product arriving back at Scan. More info
Product Overview The newly upgraded FOCUS GX series are the successor to the FOCUS PLUS Series, which became an instant the top seller in the power supply market after its launch in 2017. In 2019, Seasonic engineers have made improvements on the popular series, removing the inline capacitors on the supplied cables. Besides the small change in the series naming, the PSU housing and its packaging are also updated to be in line with the concept of the OneSeasonic Initiative.

80 Plus® Platinum
The FOCUS PX achieves 80 PLUS® Platinum certification with its 92 % efficiency at 50 % system load.

Cable-Free Connection Design
Seasonic’s engineers have implemented a new design feature, where instead of cables; the back panel and the PCB (Printed Circuit Board) are connected by a copper plate. This breakthrough solution not only lowers the chance of production errors during manual insertion but it also improves output power quality.

Hybrid Silent Fan Control
The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Hybrid Silent Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode.

The Fan Control Button
The fan control button can be found on the back of the FOCUS PLUS power supply, next to the power switch. The image here illustrates how to select different fan control modes to suit your need.

Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.

How It Works
When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces. As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
Features • 80 PLUS® Platinum certified
• Compact Size - 140 mm deep
• Tight Voltage Regulation
• Cable-free Connection Design
• S3FC - Fanless until 30 % load
• Multi-GPU setup
• Gold plated connectors
• 10 years warranty
Specifications
Size ATX
Edition Focus PX 750
Wattage 750 W
80 PLUS Certification 80 PLUS Platinum
Max. Efficiency (at 230Vac)
Cooling Fan
Fans 1 x 120mm
Internal +12V Rails Single Rail
Rail 1 +12V 62 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 62 A
Modular No
Modularity Full Modular
SLI/CrossFire No
EPS 12V Yes
Motherboard Connector 20+4-pin
Connectors
  • 2 x 4+4-pin ATX 12V
  • 1 x 4-pin FDD Power
  • 5 x 4-pin Molex
  • 5 x 6+2-pin PCIe
  • 10 x SATA
Dimensions 150 x 86 x 140 (WxHxD)
Package Type Retail
Additional Information
Scan Code LN100770
Model Number Focus PX-750
GTIN 4711173874645
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
120 months
Type:
Direct
DOA Period:
30 days
RTB Period:
12 months
Manufacturer Contact Details
Manufacturer:
Seasonic
