EVGA SuperNOVA G2 750 Watt Modular Power Supply/PSU

750W EVGA SuperNOVA 750 G2, 80 PLUS Gold, Full Modular, SLI/CrossFire, Single Rail, 62.4A +12V, 1x140mm Fan, ATX PSU

EVGA
Scan code: LN70001 Manufacturer code: 220-G2-0750-X3 Request call
£109.99
In stock
Buy Now, Pay Later with a 10% deposit. Or spread the cost of your finance over 24-48 months.
3xs Approved High End
Delivery options £11.50 By DPD On 5th Dec 2016 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout Scansure protection Scansure Protect against installation damage for 28 days.More
Frequently Bought Together

EVGA 750 G2 80PLUS GOLD

EVGA 750 G2

750G2 - Next Generation in Power

Unleash the next generation in power with the EVGA SuperNOVA 750 G2 Power Supply. Based on the award winning G2 series Power Supplies from EVGA, this PSU features 80 PLUS Gold rated efficiency, and clean, continuous power to every component. This provides improved efficiency for longer operation, less power consumption, reduced energy costs and minimal heat dissipation. The new ECO Thermal Control Fan System offers fan modes to provide zero fan noise during low load operations. Backed by a 10 year warranty and Japanese capacitor design, the EVGA SuperNOVA 750 G2 is not only the right choice for your system today, it is also the best choice for your system tomorrow.

750G2 POWER CHART

AC Input
DC Output
Max Output
Combined
Output

Large 62.4 amp single + 12V Rail

100 - 240 VAC / 10A / 50 - 60Hz
+3.3V +5V +12V +5Vsb -12V
24A 24A 62.4A 3A 0.5A
120W 748.8W 15W 6W
750W @ +50C

Industrial grade testing all load and regulation testing done at 50C

CONNECTIVITY

Standard ATX Form Factor
Will fit most mATX / ATX / EATX / HPTX & XLATX cases

Fully Modular Cabling
Fully Modular to reduce clutter and improve airflow

HARDWARE PROTECTION

While being silent, this entire series has a large single 12volt rail, providing plenty of power to fuel all of your hardware. And lastly, because power without safety is pointless, a full suite of top tier circuit protections have been added to keep you running strong and more importantly keeping your hardware safe.

OVP

(Over Voltage Protection)

OPP

(Over Power Protection)

UVP

(Under Voltage Protection)

SCP

(Short Circuit Protection)

OCP

(Over Current Protection)

OTP

(Over Temperature Protection)

FEATURES

Single +12V Rail

A single +12V rail offers the best power output, rail stability and compatibility with the latest hardware.

Double Ball Bearing Fan

A high-quality dual ball bearing fan gives the SuperNOVA 750 G2 an excellent thermal and acoustic profile, and its high reliability ensures a long PSU lifetime.

LLC Resonant Circuit Layout

Full DC to DC, LCC resonant circuit design improves efficiency.

Highest Quality Japanese Nippon Chemi-Con Solid State Capacitors

Get the most reliability and greatest performance with the use of the highest possible quality Japanese solid state capacitors.

80PLUS GOLD Efficiency

80 Plus certification ensures your power supply isn’t wasting power and turning it into exess heat. Under typical load this power supply is 90 efficient or higher.

Fully Modular

Fully modular designs allows every single cable to be removed from the power supply for ease of installation and removal. You can also leave off unnecessary cables to reduce case clutter and maximise case airflow.

Specifications
Specifications
Size ATX
Edition SuperNOVA 750 G2
Wattage 750 W
80 PLUS Certification 80 PLUS Gold
Max. Efficiency 92 %
Cooling Fan
Fans 1 x 140mm
Internal +12V Rails Single Rail
Rail 1 +12V 62.4 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 62.4 A
Modular Yes
Modularity Full Modular
SLI/CrossFire Yes
EPS 12V Yes
Motherboard Connector 20+4 Pin
Connectors
  • 2 x 4+4pin CPU +12V
  • 4 x 4pin Molex
  • 4 x 6+2pin PCI-E Power
  • 1 x FDD Power
  • 9 x SATA Power
Dimensions 150 x 85 x 180 mm (WxHxD)
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
120 months
Type:
Direct
DOA Period:
280 days
RTB Period:
12 months
Manufacturer Contact Details
Telephone:
01788 247 298
