CoolerMaster G550M 550 Watt Hybrid Modular Power Supply

550W Cooler Master G550M, 80 PLUS Bronze, Hybrid Modular, SLI/CrossFire, Single Rail, 42A +12V, 1x120mm Fan, ATX PSU

Cooler Master
Scan code: LN54743 Manufacturer code: RS550-AMAAB1-UK Request call
£59.99
Low stock
Spend over £225 and Buy Now, Pay Later or spread the cost of your finance over 24-48 months with a 10% deposit.
High End
Delivery options £5.48 By DPD On 13th Dec 2016 DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout Scansure protection Scansure Protect against installation damage for 28 days.More
Frequently Bought Together
Product Overview Cooler Master G550M comes with 80 Plus Bronze certified and a single +12V rail. The intelligent 120mm fan speed controller with honey combo mesh increases airflow for better heat dissipation. Features • Unique 3D circuit design offers high efficiency and improves the heat dissipation. It reduces the unnecessary cables which results in much lower crosstalk, signal noise and improves airflow.
• Powerful Single +12V rail for superior load balancing and VGA compatibility. All series supports VGA up to NVIDIA Titan.
• Modular cable designs for better cable management.
• Custom DC-DC module design offers higher efficiency and voltage stability.
• Haswell C6/C7 support & zero load operation.
• 80 PLUS Bronze certified: up to 88% efficiency @ typical load.
Specifications
Specifications
Size ATX
Edition G550M
Wattage 550 W
80 PLUS Certification 80 PLUS Bronze
Max. Efficiency 88 %
Cooling Fan
Fans 1 x 120mm
Internal +12V Rails Single Rail
Rail 1 +12V 42 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V 42 A
Modular Yes
Modularity Hybrid Modular
SLI/CrossFire Yes
EPS 12V Yes
Motherboard Connector 20+4 Pin
Connectors
  • 1 x 4+4pin CPU +12V
  • 3 x 4pin Molex
  • 2 x 6+2pin PCI-E Power
  • 1 x FDD Power
  • 6 x SATA Power
Dimensions 140 x 86 x 150 mm (WxHxD)
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
60 months
Type:
Return to base
DOA Period:
28 days
RTB Period:
60 months
Manufacturer Contact Details
Reviews
Rated 5 out of 5 by 3 reviewers.
Rated 5 out of 5 by Quality cost effective PSU I originally bought this PSU as a test unit to so I had a spare to check for possible PSU fault on my gaming rig. Also for use in a HTPC I intend to put together when I get around to it. Turned out it was a faulty PSU with my main gaming rig, so While it was only going to be used as test. It ended up being used for a few weeks supplying the power to my overclocked 4770K and R9 290X with no problems. Even though it was running up near it's 550w limit, it never failed or ran too hot. The cables supplied are basic plastic, but no different to the cables supplied with more expensive Corsair PSU's. The price/performance of this PSU is excellent and I would recommend it to anyone who was building a PC on a budget. 01 May 2015
Rated 5 out of 5 by A solid PSU If you are looking for a cost effective solution for a tidy build that provides perfectly stable voltages look no further. This PSU is handling a 280x toxic and athlon 860k without issue. All the voltages stay stable and there is only cool air coming out of the exhaust showing that it isn't even straining under load. 26 January 2015
Rated 5 out of 5 by good value and does the job I use it in a media system where heat/airflow is a issue due to having a fx cpu and a gtx 670 combo. I now have less redundant cables coming of the PSU that has reduced the temps inside the unit by 2c. And due to the slim nature of the modular connectors it looks cool too. When weighing up which psu to I compare this and the Corsair CS550M and chose this one because the cable management and price. Yes it is only a bronze rated supply unlike the corsair but when you weight this up alone with the price difference I am more then happy with it and believe it to be the best 550w PSU for the job. 19 October 2014
  • 2016-05-20 T12:52:45.821-05:00
  • bvseo_lps, prod_bvrr, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasreviews, tv_3, tr_3
  • loc_en_US, sid_54743, prod, sort_default
1-3 of 3
Questions & Answers
(2 Questions : 4 Answers)

Product Q&A

Ask your questions. Share your answers.



« Back


got a GTX 760 in my machine that i bought recently and my current PSU is able to run it on desktop and lower end games but if i try running something higher it just resets my pc, after confirming i need a PSU upgrade i came across this one in my price range and want to know if it will handle it well
Age: 25 to 34
Gender: Male
1 year, 4 months ago
Customer avatar
by
Swansea, Swansea, Swansea, UK
Read all my Q&A

Please wait while more information about Trystau is loaded.
Additional information about Trystau could not be loaded.
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers

Answer:
Without knowing what CPU and other components you are running I can't give a definitive answer, what I can say is. I had one of these running an intel [email protected]/AMD R9 290X while gaming on ultra settings on BF4. The Nvidia GTX760 is rated for around 170w peak power draw, while the AMD R9 290X I have pulls around 300W peak. So I can't see any reason why this PSU shouldn't be able to power your PC.
Age: 35 to 44
Gender: Male
1 year ago
Customer avatar
by
Manchester, UK
Read all my Q&A

Please wait while more information about welshy46 is loaded.
Additional information about welshy46 could not be loaded.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Answer:
Yes this will be sufficient to run a GTX 760 as I am looking to purchase one of these to run my PC and mine is all AMD.
Age: 17 or under
Gender: Male
1 year, 3 months ago
Customer avatar
by
UK
Read all my Q&A

Please wait while more information about harrybob is loaded.
Additional information about harrybob could not be loaded.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0
Has staff answer

2 answers

why is this psu in non modular

shouldnt it be semi modular ?
Age: 35 to 44
Gender: Male
2 years, 3 months ago
Customer avatar
by
Montrose, Angus, UK
Read all my Q&A

Please wait while more information about Graeme70 is loaded.
Additional information about Graeme70 could not be loaded.
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers

Answer:
This is indeed Semi/Hybrid Modular, we have moved into our Hybrid Modular category.
2 years, 3 months ago
Customer avatar
by
Read all my Q&A

Please wait while more information about ChrisP is loaded.
Additional information about ChrisP could not be loaded.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Answer:
Motherboard 20+4pin, motherboard 2x4 pin and the two pcie 6+2 are fixed all the others are modular. So yes I would regard to as semi modular but I think to be regarded as that the pci cables also have to be detachable as well. Otherwise the nerds out there get there nickers in a twist and ask for a refund of coolermaster.
Age: 25 to 34
Gender: Male
1 year, 7 months ago
Customer avatar
by
england
Read all my Q&A

Please wait while more information about gregtek is loaded.
Additional information about gregtek could not be loaded.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0
