Intel Optane DC 375GB M.2 PCIe SSD/Solid State Drive

Combines Attributes of Memory and Storage

The Intel® Optane™ SSD DC P4800X series is the first product to combine the attributes of memory and storage. With an industry-leading combination of high throughput, low latency, high QoS, and high endurance, this innovative solution is optimised to break through data access bottlenecks by providing a new data storage tier. The DC P4800X/ P4801X accelerate applications with fast caching and fast storage to increase scale per server and reduce transaction costs for latency sensitive workloads. In addition, the Intel® Optane™ DC P4800X enables data centres to deploy bigger and more affordable datasets to gain new insights from large memory pools.

High Throughput for Breakthrough Performance

Realise breakthrough application performance with the Intel® Optane™ DC P4800X/P4801X. It is designed to deliver up to 6x faster performance at low queue depth workloads, exhibiting extremely high throughput for single accesses and super low latency. Where NAND-based SSDs are often measured at a queue depth of 32 (SATA) or 128 (NVMe*) in order to showcase maximum throughput, the Intel® Optane™ DC P4800X/P4801X can reach as many as 550,000 IOPS at a queue depth of 16. This new technology is perfectly suited to accelerate enterprise applications to new, breakthrough levels of performance.

Low Latency: Responsive Under Load

With a new data storage tier created by Intel® Optane™ technology, data centres can consistently realise amazing response times under any workload. With NAND-based SSDs, random write operations require an immense amount of background media management. These tasks can add significant delay to the read operations. The Intel® Optane™ SSD DC P4800X/P4801X maintains consistent read response times regardless of the write throughput applied to the drive. Average read response times remain below <30µs while maintaining a 70/30 mixed read/write bandwidth of 2GB/s.

Predictably Fast Service: QoS

In an environment of fast growing data and ever demanding needs, data centres must deploy solutions that enable predictably fast service. The Intel® Optane™ DC P4800X/ P4801X are ideal for critical applications with demanding latency requirements. Its 99% read response time is up to 63x better than that of a high-endurance NAND SSD under random write workload. Optimised to minimise delays in data access times, the Intel® Optane™ DC P4800X /P4801X results in faster time to insight for decision making.

High Endurance

Endurance affects the life expectancy and costs of enterprise SSDs. The DC P4800X/P4801X is designed for high write environments, and can withstand intense write traffic that is typically demanded of memory. With its extremely high endurance, the life of the DC P4800X/P4801X is extended, making it suitable for write-intensive applications such as online transaction processing, high performance computing, write caching, boot, and logging.

Use Cases for Today’s Data Centre

The Intel® Optane™ DC P4800X provides a new storage tier that breaks through the bottlenecks of traditional NAND storage to accelerate applications and enable more work to get done per server. This unique capability means data centres can explore three key use cases, including caching, fast storage, and extended memory. The DC P4801X can also provide fast logging, caching, boot, or extended memory. Caching and fast storage refer to the tiering and layering that support a better memory-to-storage hierarchy. The Intel® Optane™ SSD facilitates dynamic placement of data that enables fast access to both read and/or write data. In addition, this high performing SSD meets the requirement of an application to accelerate storage access.

An Intel® Optane™ SSD can also extend memory, offering bigger or more affordable memory by participating in a shared memory pool with DRAM at either the OS or application level. Bigger memory dramatically increases the size of ‘working sets’ to enable new insights from data in growing segments such as scientific computing, healthcare, and autonomous driving. More affordable memory means data centres can use Intel® Optane™ SSDs to displace some DRAM.
