Silverstone Gemini 2x 500W Redundant Power Supply

2 x 500W Silverstone Gemini Redundant, Hot Swap, 80PLUS Silver, PSU

Silverstone
Scan code: LN37316 Manufacturer code: SST-ST50GF Request call
£399.98Item currently awaiting an ETA
Pre order
Pay on Scan Finance with a 10% deposit from just £9.99 / month (APR 15.9%)
High End
Delivery options £11.50 By DPD DPD Delivered to your specified address. Receive SMS with one-hour delivery window. £4.79 Collect from local shops UPS and DPD Pickup Collect your parcel from your newsagents, petrol stations and convenience stores. Free Collect Instore Q-Collect Place your order online and collect from our Bolton store with Q-Collect. Weekend, timed and European delivery options are available at checkout Scansure protection Scansure Protect against installation damage for 28 days.More
Product Overview For users with mission-critical systems or file servers, nothing is more important than a power supply with always up reliability and redundancy. With the pervious venerable Gemini ST46GF and ST55GF models as the starting point, SilverStone improves every aspect of the former from specification to user impression. By combining proven industrial grade components and a focus on performance, the amazing dual 500W independent power packs stowed inside a PS/2 frame enable the possibility to enjoy the bullet-proof security of a 24/7 server in just about any case and any system! Features • 500+500W watts 24hour/7day maximum continuous power output
• High efficiency with 80 PLUS Silver certification
• 12V maximum output: 40A
• Active PFC (full range)
• Industry-leading reliability
• 1+1 redundant configuration
• Hot swappable design
• Power fault Alarm signals
• Durable zinc-plated surface
• Convenient pull-out handle bars
• PS2 mini redundant power with 150(5.90”) x 86 (3.38”)x 193(7.59”)
Specifications
Specifications
Size
Edition
Wattage 500 W
80 PLUS Certification 80 PLUS Silver
Max. Efficiency 80 %
Cooling Fan
Fans 2 x 40mm
Internal +12V Rails
Rail 1 +12V 40 A
Rail 2 +12V N/A
Rail 3 +12V N/A
Rail 4 +12V N/A
Rail 5 +12V N/A
Rail 6 +12V N/A
Max. Combined Output +12V N/A
Modular No
Modularity
SLI/CrossFire No
EPS 12V Yes
Motherboard Connector 24 Pin
Connectors
  • 1 x 4pin ATX 12V
  • 6 x 4pin Molex
  • 1 x 6pin PCI-E Power
  • 1 x 8pin CPU +12V
  • 2 x FDD Power
  • 6 x SATA Power
Dimensions 150 x 86 x 193 mm (WxHxD)
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
7 days
RTB Period:
24 months
Manufacturer Contact Details
Manufacturer:
Scan
Reviews
Rated 5 out of 5 by 1 reviewer.
Rated 5 out of 5 by Impressed I found getting hold of a redundant power supply which I could put into a fairly regular PC chassis quite difficult until I stumbled across this. The power supply is quite pricy, but when its loaded into your PC its fairly evident that its definitely more of a professional bit of kit than consumer. The power output seems very good, lots of PSU manufactures rate their power supplies on the absolute maximum they can output, not the amount that they can output comfortably, and many people building their own computers (most specifically gamers) often vastly over specific their power supply requirements. This 500w x2 unit is quite comfortably powering up 2x 8 Core Xeons, 8x 4TB discs and 32GB of registered RAM, even when only a single module is plugged in. Comes with two very chunky IEC cables to get you going as well as some velcro cable ties and screws to mount this into your chassis. Bear in the mind though that this isn't a standard 'ATX' fit, although its a very similar size, the screw holes won't match up, you might need to contact your case manufacturer and ask if they can provide you with a 'PS/2 mini redundant' adapter plate. The power supply its self is fairly noisy, although not ridiculous. This is due to the four 40mm fans between the two power supply modules. I'm sure dismantling the unit and replacing the stock fans with more expensive ones would fix this problem (although it will void your warranty so you do it at your own risk), but this is designed more for 24/7 operation than to sit under your desk at home with a very high MTBF so if its going to live in a server room then your probably not too concerned about that. Its got a fairly standard loom of outputs, including a single PCI-E connector, and single 8pin EPS connector for the CPU (my motherboard required two, which was easily sorted with a cheap molex to 8pin EPS adapter), upon removing one of the power cables whilst the PC is powered up, the PSU will beep loudly to alert you that its lost one of its inputs, and you can press the button on the back to silence it, it also has a small LED on the end of a cable you could poke through you chassis somewhere so you can see visually of any errors also. Overall very impressed, just make sure you get hold of the correct adapter if you want to put this in a standard case! 18 August 2015
