ASUS ROG STRIX B760-F Gaming WiFi DDR5 ATX Motherboard
Images
ASUS ROG STRIX B760-F Gaming, Intel B760, LGA1700, DDR5, PCIe 5.0, 3x M.2, 2.5GbE, WiFi 6E, USB 3.2 Gen2, ATX
Scan Code:LN131616
Manufacturer Code:90MB1CT0-M1EAY0
Customer Reviews and Q&A
ROG Strix B760-F Gaming WiFi Intel 13th Generation ATX Motherboard
GET READY FOR THE NEWEST GENERATIONLeap into the future with the ROG Strix B760-F, a fantastic upgrade into 13th Gen with its dominant power solution and best-in-class DDR5 speeds. Its next-gen PCIe 5.0 slot gives overwhelming graphics card throughput for maximum FPS, and you can minimise lag via hyperfast WiFi 6E or 2.5G LAN. All these perks come alongside distinctive rainbow stripes and retro accents so you can show off your gamer pride.
Intel® B760Chipset
LGA 1700CPU Socket
13th Gen Intel®Compatible Processors
ATXForm Factor
Superb Architecture and Power Solution
1ProCool Power Connectors
2Intel® Socket LGA 1700 for 13th/12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
31 x PCIe 5.0 x16 Safeslot (x16) [CPU]
1 x PCIe 3.0 x16 Slot (x4) [Chipset]
2 x PCIe 3.0 x1 Slots [Chipset]
416 + 1 Power Stages
5DDR5 7800+ (OC)
4x DIMM
Dual Channel
61 x M.2 22110 (PCIe 4.0 x4)
2 x M.2 2280 (PCIe 4.0 x4)
All Round Performance
Incredible SpeedsWith a powerful VRM and thick stacked heatsinks, the ROG Strix B760-F is ready for any chip in the Intel 13th Gen lineup. Connected devices can run at incredible speeds as well, thanks to immense PCIe bandwidth.
POWER ARCHITECTURE16 + 1 power stages, each rated to 60A, deliver ample current to drive the most powerful Intel 13th Gen processors through any workload with ease.
ALLOY CHOKES AND DURABLE CAPACITORSHigh-end chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards.
SIX-LAYER PCBA multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability.
DDR5 DOMINATIONROG has a long legacy of flexing the fastest memory performance, and DDR5 is no outlier. Thanks to improved signal routing, now enthusiast-grade kits have been driven far beyond the 7 GT/s mark on the Strix B760-F, and who knows how far future DIMMs can go? Seasoned veterans can test their mettle by tinkering with the extensive array of tuning options in the UEFI.
VRM HEATSINK ARRAYCovering the power solution are two thick heatsinks with strategic airflow channels for increased heat dissipation while powering high-performance Intel 13th Gen processors.
M.2 HEATSINKSHeatsinks cover every slot to help keep onboard NVME SSDs at optimal temperatures for consistent performance and reliability.
CPU FAN HEADERSPositioned near the top of the motherboard, a pair of PWM/DC fan headers give easy access for CPU coolers.
AIO PUMP FAN HEADERA dedicated PWM/DC header connects self-contained water-cooling setups.
4-PIN FAN HEADERSThe Strix B760-F features four chassis fan headers, each supporting auto-detection of PWM or DC fans.
Outshine the Competition
Personalise and gear up with ROG componentsROG Strix motherboards feature ASUS Aura technology, enabling full lighting control and a variety of presets for both onboard RGB LEDs and third-party accessories. Effects can be easily synced across compatible ROG graphics cards, monitors, keyboards, and mice to give your setup a unified look
Create a Fully Customised Gaming Setup
DIY FRIENDLY SLOT Q-RELEASEA physical button unlocks the first PCIe slot's security latch with one press, greatly simplifying the process of detaching a PCIe card from the motherboard when it's time to upgrade to a new GPU or other compatible device.
PCIe PerformanceThe top x16 expansion slot is ready for the future with incredible PCIe 5.0 bandwidth, and it is protected with a SafeSlot retention bracket to support the bulk of the latest graphics cards. Zippy storage options abound with three PCIe 4.0 M.2 slots, all featuring robust heatsinks to maximise performance.
Supreme Networking Capability
WIFI 6EOnboard WiFi 6E technology takes advantage of newly available spectrum in the 6 GHz band to provide up to seven 160 MHz channels for ultrafast throughput and better performance in dense wireless environments.
Intel® 2.5 GB EthernetLow-latency gaming, speedy file transfers, and high-resolution video streaming are among the many perks of onboard Intel® 2.5 Gbps Ethernet.
Fine Quality Components for Exceptional Clarity & Fidelity
Unique Design Features for Powerful AudioROG SupremeFX is a unique blend of hardware and software technologies that provide superior audio. The Strix B760-F implementation features the ALC4080 codec for high-resolution playback up to 32-bit/384 kHz across all channels. Front-panel output is streamed through the integrated Savitech amplifier that can drive high-fidelity acoustics to a wide variety of speakers and headsets.
Full Connectivity
1 - 1x HDMI® Port
2 - 1x Display Port
3 - 6x USB 3.2 Gen 1 Ports
(USB Type-A)
4 - 1x USB 3.2 Gen 2x2 Port
(USB Type-C®)
5 - 1x USB 3.2 Gen 2 Port
(USB Type-A)
6 - Intel® 2.5G Ethernet Port
7 - Clear CMOS Button
8 - BIOS FlashBack™ Button
9 - Wi-Fi 6E
10 - Optical S/PDIF Out Port
11 - 5x Audio Jacks
Control your Rig with Armoury Crate
account management software Armoury Crate is a software utility designed to provide centralised control of supported ROG gaming products. From a single intuitive interface, Armoury Crate puts command of all your Aura gear at your fingertips with the new Aura Creator suite ready. The software also provides control of settings for a growing number of ROG products, making it easier to tune the look and feel of your system. Armoury Crate even offers dedicated product registration and ROG news feeds to help you stay in touch with the ROG gaming community.
