NZXT H9 Flow (2025) Black Dual-Chamber Mid-Tower ATX Airflow Case

Maximise Your Airflow The H9 Flow is a high-performance mid-tower case that delivers high-performance cooling wrapped in a striking aesthetic. Its spacious dual-chamber layout optimizes airflow and simplifies cable management, while wraparound tempered glass panels showcase your build from any angle. Support for dual 420 mm radiators and multiple 140 mm fans, including strategically angled front-right fans, ensures top-tier cooling for even the most demanding hardware.

Showcase Your Style

uninterrupted PanoramaThe H9 Flow features an uninterrupted glass panel showcasing premium components in style and providing the perfect view of the case interior.

Dual-Chamber DesignThe dual chamber design separates components from cables, storage, and the PSU, highlighting a clean and organized aesthetic.

EFFORTLESS CABLE MANAGEMENTExtra-wide channels, tie-down points, and Velcro straps simplify cable routing for a clean build.

BACK-CONNECT MOTHERBOARD SUPPORTFull compatibility with ASUS, Gigabyte, and MSI back-connect motherboards enables a clean, cable-free aesthetic.

Simplified AccessTop, front-right, and side panels can be easily accessed for quick upgrades and maintenance.

SSD DoorA dedicated hinged door holds up to four SSDs for easy access and hassle-free installation.

High Airflow PanelsUltra-fine mesh on the top, front-right, and side panels maximizes airflow while filtering dust.

Integrated Cooling

Whats Included?The H9 Flow includes a formiddable cooling solution boasting 3x F140Q (CV) fans and one F120Q (CV) rear fan.

Maximise Your Cooling Capability

Fan CompatibilityThe H9 Flow has room for 10 fans. With the capacity for
Front: 3 x 120 mm / 3 x 140 mm
Top: 3 x 120 mm / 3 x 140 mm
Bottom: 3 x 120 mm / 3 x 140 mm
Rear: 1x 120mm at the rear

Radiator CompatibilityThe H9 Flow has room for up to 420mm radiator on the top or front, a 360mm radiator on the bottom, and up to a 120mm radiator on the rear.

Specifications

Core Chassis Specifications
Case Edition	H9 Flow (2025)
Case Form Factor	Dual Chamber Mid Tower
Motherboard Form Factor	ATX E-ATX MicroATX Mini-ITX
Back Connect Compatible	Yes

I/O, Bays & Expansion
Front/Side/Top Panel I/O	1 x Headphone/Mic Combo 1 x Power Button 2 x USB 3.2 Gen1 Type-A 1 x USB 3.2 Gen2x2 Type-C
Drive Bays	4 x 2.5" Internal 2 x 2.5"/ 3.5" Internal
Standard Expansion Slots	7
Vertical Expansion Slots

Fans & Filters
Fan Bays	1 x 120mm 9 x 120mm / 9x 140mm
Fans Included	1 x 120mm 3 x 140mm
Fan Controller/Hub
Dust Filters	Bottom Side Top

Liquid Cooling Support
Front Radiator Compatibility
Top Radiator Compatibility	1 x 120/140/240/280/360/420mm
Bottom Radiator Compatibility	1 x 120/140/240/280/360mm
Rear Radiator Compatibility	1 x 120mm
Side Radiator Compatibility	1 x 120/140/240/280/360/420mm

Clearances
Max CPU Cooler Height	165 mm
Max GPU Card Length	(<56 mm fans) 459 / (56 mm thick 420 AIO+fans) 410 mm
Cable Routing Space

Side Panels
Window/s	Yes
Window Configuration	1 x Front 1 x Main Side
Window Construction	Tempered Glass

LED Lighting Functionality
LED Lighting	No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control

Power Supply Compatibility
PSU Included	No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support	ATX
PSU Mounting Location	Top Mount, Rear
Max PSU Length	200 mm

Chassis Physical Specifications
Colour	Black
Chassis Construction Materials	SGCC
Dimensions	315 x 506 x 481 (WxHxD mm)
Weight	12.46 kg (Approx)
Package Type	Retail
Please Note

Additional Information
Scan Code	LN157699
Model Number	CM-H92FB-01
GTIN	5056547207643
